Search dictionary symbol style

// [WriteFile Name=SearchDictionarySymbolStyle, Category=Search]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "SearchDictionarySymbolStyle.h"

// ArcGIS Maps SDK headers
#include "DictionarySymbolStyle.h"
#include "SymbolStyleSearchParameters.h"
#include "SymbolStyleSearchResultListModel.h"

// Qt headers
#include <QFuture>
#include <QStandardPaths>
#include <QtCore/qglobal.h>

using namespace Esri::ArcGISRuntime;

// helper method to get cross platform data path
namespace
{
  QString defaultDataPath()
  {
    QString dataPath;

  #ifdef Q_OS_IOS
    dataPath = QStandardPaths::writableLocation(QStandardPaths::DocumentsLocation);
  #else
    dataPath = QStandardPaths::writableLocation(QStandardPaths::HomeLocation);
  #endif

    return dataPath;
  }
} // namespace

using namespace Esri::ArcGISRuntime;

SearchDictionarySymbolStyle::SearchDictionarySymbolStyle(QQuickItem* parent) :
  QQuickItem(parent)
{
}

SearchDictionarySymbolStyle::~SearchDictionarySymbolStyle() = default;

void SearchDictionarySymbolStyle::init()
{
  qmlRegisterType<SearchDictionarySymbolStyle>("Esri.Samples", 1, 0, "SearchDictionarySymbolStyleSample");
  qmlRegisterUncreatableType<QAbstractListModel>("Esri.Samples", 1, 0, "AbstractListModel", "AbstractListModel is uncreateable");
}

void SearchDictionarySymbolStyle::componentComplete()
{
  QQuickItem::componentComplete();

  //Get the data path
  QString datapath = defaultDataPath() + "/ArcGIS/Runtime/Data/styles/arcade_style/mil2525d.stylx";

  //Create the dictionary from datapath (added since 100.6)
  m_dictionarySymbolStyle = DictionarySymbolStyle::createFromFile(datapath, this);
}

QAbstractListModel* SearchDictionarySymbolStyle::searchResultsListModel() const
{
  return m_searchResults;
}

void SearchDictionarySymbolStyle::search(const QStringList& namesSearchParam, const QStringList& tagsSearchParam,
                                         const QStringList& classesSearchParam,const QStringList& categoriesSearchParam,
                                         const QStringList& keysSearchParam)
{
  //Create search parameters and search with the parameters
  SymbolStyleSearchParameters searchParameters;
  searchParameters.setCategories(categoriesSearchParam);
  searchParameters.setKeys(keysSearchParam);
  searchParameters.setNames(namesSearchParam);
  searchParameters.setSymbolClasses(classesSearchParam);
  searchParameters.setTags(tagsSearchParam);
  m_dictionarySymbolStyle->searchSymbolsAsync(searchParameters).then(this, [this](SymbolStyleSearchResultListModel* results)
  {
    m_searchResults = results;
    emit searchResultsListModelChanged();
    emit searchCompleted(results->size());
  });
}

// [WriteFile Name=SearchDictionarySymbolStyle, Category=Search]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef SEARCHDICTIONARYSYMBOLSTYLE_H
#define SEARCHDICTIONARYSYMBOLSTYLE_H

// Qt headers
#include <QAbstractListModel>
#include <QQuickItem>
#include <QUuid>

namespace Esri::ArcGISRuntime
{
    class DictionarySymbolStyle;
}

class SearchDictionarySymbolStyle : public QQuickItem
{
  Q_OBJECT

  Q_PROPERTY(QAbstractListModel* searchResultsListModel READ searchResultsListModel NOTIFY searchResultsListModelChanged)

public:
  explicit SearchDictionarySymbolStyle(QQuickItem* parent = nullptr);
  ~SearchDictionarySymbolStyle() override;

  enum class FieldEnum {
    FieldNames,
    FieldTags,
    FieldClasses,
    FieldCategories,
    FieldKeys
  };
  Q_ENUM(FieldEnum)

  void componentComplete() override;
  static void init();
  Q_INVOKABLE void search(const QStringList& namesSearchParam, const QStringList& tagsSearchParam,
                          const QStringList& classesSearchParam,const QStringList& categoriesSearchParam,
                          const QStringList& keysSearchParam);

  QAbstractListModel* searchResultsListModel() const;

signals:
  void searchCompleted(int count);
  void searchResultsListModelChanged();

private:
  Esri::ArcGISRuntime::DictionarySymbolStyle* m_dictionarySymbolStyle = nullptr;
  QAbstractListModel* m_searchResults = nullptr;
};

#endif // SEARCHDICTIONARYSYMBOLSTYLE_H

// [WriteFile Name=SearchDictionarySymbolStyle, Category=Search]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import QtQuick.Layouts
import Esri.Samples

SearchDictionarySymbolStyleSample {
    id: searchDictionarySymbolStyleSample
    width: 800
    height: 600

    readonly property double fontSize: 16
    readonly property var repeaterModel: ["Names", "Tags", "Symbol Classes", "Categories", "Keys"]
    readonly property var hintsModel: ["Fire", "Sustainment Points", "3", "Control Measure", "25212300_6"]
    property var searchParamList: [[],[],[],[],[]]

    ColumnLayout {
        id: topRectangle
        anchors {
            fill: parent
            margins: 9
        }

        Column {
            id: fieldColumn
            visible: !hideSearch.checked
            enabled: visible
            Layout.fillWidth: true
            Layout.margins: 8

            Repeater {
                id: repeater
                model: repeaterModel

                Rectangle {
                    width: parent.width
                    height: childrenRect.height
                    color: "lightgrey"
                    border.color: "darkgrey"
                    radius: 2
                    clip: true

                    GridLayout {
                        anchors {
                            left: parent.left
                            right: parent.right
                            margins: 3
                        }
                        columns: 3
                        rowSpacing: 0
                        Text {
                            text: repeaterModel[index]
                            font.bold: true
                            verticalAlignment: Text.AlignVCenter
                            horizontalAlignment: Text.AlignLeft
                            wrapMode: Text.WordWrap
                        }

                        TextField {
                            id: categoryEntry
                            Layout.fillWidth: true
                            placeholderText: repeaterModel[index] +" (e.g. "+ hintsModel[index] +")"
                            selectByMouse: true
                            validator: RegularExpressionValidator{ regularExpression: /^\s*[\da-zA-Z_][\da-zA-Z\s_]*$/ }
                            onAccepted: addCategoryButtonMouseArea.clicked(true);
                        }

                        Rectangle {
                            id: addCategoryButton
                            height: childrenRect.height
                            width: height
                            color: "transparent"
                            Image {
                                source: parent.enabled ? "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_addencircled_light.png"
                                                       : "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_addencircled_dark.png"
                            }
                            enabled: categoryEntry.text.length > 0

                            MouseArea {
                                id: addCategoryButtonMouseArea
                                anchors.fill: parent
                                onClicked: {
                                    if (categoryEntry.text.length === 0)
                                        return;

                                    const tmp = searchParamList;
                                    tmp[index].push(categoryEntry.text);

                                    searchParamList = tmp;
                                    categoryEntry.text = "";
                                }
                            }
                        }

                        Label {
                            id: categoryList
                            Layout.fillWidth: true
                            Layout.column: 1
                            Layout.row: 1
                            text: searchParamList[index].length > 0 ? searchParamList[index].join() : ""
                        }

                        Rectangle {
                            height: childrenRect.height
                            width: height
                            color: "transparent"
                            Image {
                                source: parent.enabled ? "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_closeclear_light.png" :
                                                         "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_closeclear_dark.png"
                            }
                            enabled: categoryList.text.length > 0

                            MouseArea {
                                anchors.fill: parent
                                onClicked: {
                                    categoryEntry.text = "";
                                    const tmp = searchParamList;
                                    tmp[index] = [];

                                    searchParamList = tmp;
                                }
                            }
                        }
                    }
                }
            }
        }

        Row {
            spacing: 10

            Button {
                id: seachBtn
                width: childrenRect.width
                Image {
                    id: searchImage
                    anchors {
                        top: parent.top
                        bottom: parent.bottom
                        margins: 3
                    }
                    source: "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_find_light.png"
                }

                Text {
                    anchors {
                        left: searchImage.right
                        verticalCenter: parent.verticalCenter
                        margins: 3
                    }
                    text: searchParamList[0].length === 0 &&
                          searchParamList[1].length === 0 &&
                          searchParamList[2].length === 0 &&
                          searchParamList[3].length === 0 &&
                          searchParamList[4].length === 0 ?
                              "List All" : "Search"
                }

                onClicked: {
                    //start the search
                    resultView.visible = false;

                    searchDictionarySymbolStyleSample.search(searchParamList[SearchDictionarySymbolStyleSample.FieldNames],
                                                             searchParamList[SearchDictionarySymbolStyleSample.FieldTags],
                                                             searchParamList[SearchDictionarySymbolStyleSample.FieldClasses],
                                                             searchParamList[SearchDictionarySymbolStyleSample.FieldCategories],
                                                             searchParamList[SearchDictionarySymbolStyleSample.FieldKeys]);
                }
            }

            Button {
                text: "Clear"
                onClicked: {
                    //Set the results visibility to false
                    resultView.visible = false;
                    //Reset the search parameters
                    searchParamList = [[],[],[],[],[]];
                }
            }

            Button {
                id: hideSearch
                checked: false
                checkable: true
                Image {
                    anchors {
                        top: parent.top
                        bottom: parent.bottom
                        horizontalCenter: parent.horizontalCenter
                        margins: 3
                    }
                    source: parent.checked ? "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_collapsed_light.png" :
                                             "qrc:/Samples/Search/SearchDictionarySymbolStyle/ic_menu_expanded_light.png"
                }
            }
        }

        Text {
            id: resultText
            visible: resultView.visible
            text: "Result(s) found: " + resultView.count
            font.pixelSize: fontSize
        }

        Rectangle {
            id: bottomRectangle
            Layout.fillHeight: true
            Layout.fillWidth: true

            //Listview of results returned from Dictionary
            ListView {
                id: resultView
                anchors {
                    fill: parent
                    margins: 10
                }
                spacing: 20

                clip: true
                model: searchResultsListModel

                delegate: Component {
                    Row {
                        anchors {
                            margins: 20
                        }
                        width: resultView.width
                        spacing: 10

                        Image {
                            source: symbolUrl
                        }

                        Column {
                            width: parent.width
                            spacing: 10

                            Text {
                                id: nameText
                                text: "<b>Name:</b> " + name
                                font.pixelSize: fontSize
                                width: parent.width
                                wrapMode: Text.WrapAtWordBoundaryOrAnywhere
                            }

                            Text {
                                text: "<b>Tags:</b> " + tags
                                font.pixelSize: fontSize
                                width: nameText.width
                                wrapMode: Text.WrapAtWordBoundaryOrAnywhere
                            }

                            Text {
                                text: "<b>SymbolClass:</b> " + symbolClass
                                font.pixelSize: fontSize
                                width: nameText.width
                                wrapMode: Text.WrapAtWordBoundaryOrAnywhere
                            }

                            Text {
                                text: "<b>Category:</b> " + category
                                font.pixelSize: fontSize
                                width: nameText.width
                                wrapMode: Text.WrapAtWordBoundaryOrAnywhere
                            }

                            Text {
                                text: "<b>Key:</b> " + key
                                font.pixelSize: fontSize
                                width: nameText.width
                                wrapMode: Text.WrapAtWordBoundaryOrAnywhere
                            }
                        }
                    }
                }
            }
        }
    }

    //Search completed
    onSearchCompleted: count => {
        seachBtn.enabled = true;
        resultView.visible = true;

        //Update the number of results retuned
        resultText.text = "Result(s) found: " + count
    }
}

// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "SearchDictionarySymbolStyle.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>
#include <QSettings>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("SearchDictionarySymbolStyle"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  SearchDictionarySymbolStyle::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

 #if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
 #endif

  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/Search/SearchDictionarySymbolStyle/SearchDictionarySymbolStyle.qml"));

  view.show();

  return app.exec();
}
