Local Server map image layer

// [WriteFile Name=LocalServerMapImageLayer, Category=LocalServer]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "LocalServerMapImageLayer.h"

// ArcGIS Maps SDK headers
#include "ArcGISMapImageLayer.h"
#include "Basemap.h"
#include "Envelope.h"
#include "LayerListModel.h"
#include "LocalMapService.h"
#include "LocalServer.h"
#include "LocalServerTypes.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "MapViewTypes.h"
#include "Viewpoint.h"

// Qt headers
#include <QDir>
#include <QFuture>
#include <QTemporaryDir>

using namespace Esri::ArcGISRuntime;

LocalServerMapImageLayer::LocalServerMapImageLayer(QQuickItem* parent) :
  QQuickItem(parent)
{
  // Create a temporary directory for the local server if one has not already been created
  if (!LocalServer::appDataPath().isEmpty() && !LocalServer::tempDataPath().isEmpty())
    return;

  // create temp/data path
  const QString tempPath = LocalServerMapImageLayer::shortestTempPath() + "/EsriQtTemp";

  // create the directory
  m_tempDir = std::make_unique<QTemporaryDir>(tempPath);

  // set the temp & app data path for the local server
  LocalServer::instance()->setTempDataPath(m_tempDir->path());
  LocalServer::instance()->setAppDataPath(m_tempDir->path());
}

LocalServerMapImageLayer::~LocalServerMapImageLayer() = default;

void LocalServerMapImageLayer::init()
{
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<LocalServerMapImageLayer>("Esri.Samples", 1, 0, "LocalServerMapImageLayerSample");
}

void LocalServerMapImageLayer::componentComplete()
{
  QQuickItem::componentComplete();

  // find QML MapView component
  m_mapView = findChild<MapQuickView*>("mapView");
  m_mapView->setWrapAroundMode(WrapAroundMode::Disabled);

  // Create a map using the topographic BaseMap
  m_map = new Map(BasemapStyle::ArcGISTopographic, this);

  // Set map to map view
  m_mapView->setMap(m_map);

  QString dataPath = QDir::homePath() + "/ArcGIS/Runtime/Data";

  // create a map service
  m_localMapService = new LocalMapService(dataPath + "/mpkx/RelationshipID.mpkx", this);

  if (LocalServer::instance()->isInstallValid())
  {
    connectSignals();
    if (LocalServer::status() == LocalServerStatus::Started)
      m_localMapService->start();
    else
      LocalServer::start();
  }
}

void LocalServerMapImageLayer::connectSignals()
{
  // local server status
  connect(LocalServer::instance(), &LocalServer::statusChanged, this, [this]()
  {
    if (LocalServer::status() == LocalServerStatus::Started)
    {
      // start the service
      m_localMapService->start();
    }
  });

  // local map service status
  connect(m_localMapService, &LocalMapService::statusChanged, this, [this]()
  {
    if (m_localMapService->status() == LocalServerStatus::Started)
    {
      ArcGISMapImageLayer* mapImageLayer = new ArcGISMapImageLayer(QUrl(m_localMapService->url()), this);

      connect(mapImageLayer, &ArcGISMapImageLayer::loadStatusChanged, this, [this, mapImageLayer](LoadStatus status)
      {
        if (status == LoadStatus::Loaded)
        {
          m_mapView->setViewpointAsync(Viewpoint(mapImageLayer->fullExtent()));
        }
      });
      m_map->operationalLayers()->append(mapImageLayer);
    }
  });
}

QString LocalServerMapImageLayer::shortestTempPath()
{
  // get tmp and home paths
  const QString tmpPath = QDir::tempPath();
  const QString homePath = QDir::homePath();

  // return whichever is shorter, temp or home path
  if (homePath.length() > tmpPath.length())
    return tmpPath;
  else
    return homePath;
}

// [WriteFile Name=LocalServerMapImageLayer, Category=LocalServer]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef LOCAL_SERVER_MAPIMAGELAYER_H
#define LOCAL_SERVER_MAPIMAGELAYER_H

// Qt headers
#include <QQuickItem>

namespace Esri::ArcGISRuntime
{
  class Map;
  class MapQuickView;
  class LocalServer;
  class LocalMapService;
}

class QTemporaryDir;

class LocalServerMapImageLayer : public QQuickItem
{
  Q_OBJECT

public:
  explicit LocalServerMapImageLayer(QQuickItem* parent = nullptr);
  ~LocalServerMapImageLayer() override;

  void componentComplete() override;
  static void init();

private:
  void connectSignals();
  QString shortestTempPath();

private:
  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::LocalMapService* m_localMapService = nullptr;
  std::unique_ptr<QTemporaryDir> m_tempDir;
};

#endif // LOCAL_SERVER_MAPIMAGELAYER_H

// [WriteFile Name=LocalServerMapImageLayer, Category=LocalServer]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import Esri.Samples

LocalServerMapImageLayerSample {
    id: localServerMapImageLayerSample
    width: 800
    height: 600

    // Create MapQuickView here, and create its Map etc. in C++ code
    MapView {
        anchors.fill: parent
        objectName: "mapView"
        // set focus to enable keyboard navigation
        focus: true

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }
}

// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "LocalServerMapImageLayer.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>
#include <QSettings>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("LocalServerMapImageLayer"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  LocalServerMapImageLayer::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

 #if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
 #endif

  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/LocalServer/LocalServerMapImageLayer/LocalServerMapImageLayer.qml"));

  view.show();

  return app.exec();
}
