Trace utility network

// [WriteFile Name=TraceUtilityNetwork, Category=UtilityNetwork]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "TraceUtilityNetwork.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"
#include "ArcGISFeature.h"
#include "AttributeListModel.h"
#include "Authentication/AuthenticationManager.h"
#include "Authentication/ArcGISAuthenticationChallenge.h"
#include "Authentication/TokenCredential.h"
#include "Envelope.h"
#include "Error.h"
#include "ErrorException.h"
#include "FeatureLayer.h"
#include "FeatureQueryResult.h"
#include "GeometryEngine.h"
#include "Graphic.h"
#include "GraphicListModel.h"
#include "GraphicsOverlay.h"
#include "GraphicsOverlayListModel.h"
#include "IdentifyLayerResult.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Polyline.h"
#include "QueryParameters.h"
#include "ServiceFeatureTable.h"
#include "ServiceGeodatabase.h"
#include "SimpleLineSymbol.h"
#include "SimpleMarkerSymbol.h"
#include "SpatialReference.h"
#include "SymbolTypes.h"
#include "UniqueValue.h"
#include "UniqueValueListModel.h"
#include "UniqueValueRenderer.h"
#include "UtilityAssetGroup.h"
#include "UtilityAssetType.h"
#include "UtilityDomainNetwork.h"
#include "UtilityElement.h"
#include "UtilityElementTraceResult.h"
#include "UtilityNetwork.h"
#include "UtilityNetworkDefinition.h"
#include "UtilityNetworkListModel.h"
#include "UtilityNetworkSource.h"
#include "UtilityNetworkTypes.h"
#include "UtilityTerminalConfiguration.h"
#include "UtilityTier.h"
#include "UtilityTraceParameters.h"
#include "UtilityTraceResultListModel.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>

// Other headers
#include "TaskCanceler.h"

using namespace Esri::ArcGISRuntime;
using namespace Esri::ArcGISRuntime::Authentication;

TraceUtilityNetwork::TraceUtilityNetwork(QObject* parent /* = nullptr */):
  ArcGISAuthenticationChallengeHandler(parent),
  m_map(new Map(QUrl("https://sampleserver7.arcgisonline.com/portal/home/item.html?id=be0e4637620a453584118107931f718b"), this)),
  m_startingSymbol(new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Cross, QColor(Qt::green), 20, this)),
  m_barrierSymbol(new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::X, QColor(Qt::red), 20, this)),
  m_mediumVoltageSymbol(new SimpleLineSymbol(SimpleLineSymbolStyle::Solid, QColor(Qt::darkCyan), 3, this)),
  m_lowVoltageSymbol(new SimpleLineSymbol(SimpleLineSymbolStyle::Dash, QColor(Qt::darkCyan), 3, this)),
  m_serviceGeodatabase(new ServiceGeodatabase(m_serviceUrl, this)),
  m_graphicParent(new QObject()),
  m_taskCanceler(std::make_unique<TaskCanceler>())
{
  ArcGISRuntimeEnvironment::authenticationManager()->setArcGISAuthenticationChallengeHandler(this);

  m_map->setInitialViewpoint(Viewpoint(Envelope(-9813547.35557238, 5129980.36635111, -9813185.0602376, 5130215.41254146, SpatialReference::webMercator())));

  connect(m_map, &Map::doneLoading, this, &TraceUtilityNetwork::loadUtilityNetwork);
}

void TraceUtilityNetwork::createFeatureLayers()
{
  setBusyIndicator(false);

  // Get the feature table from the 4th table (index = 3) in the serviceGeodatabase
  m_serviceGeodatabase = m_utilityNetwork->serviceGeodatabase();
  m_lineFeatureTable = m_serviceGeodatabase->table(3);
  m_lineLayer = qobject_cast<FeatureLayer*>(m_lineFeatureTable->layer());
}

void TraceUtilityNetwork::createRenderers()
{
  // create unique renderer
  m_uniqueValueRenderer = new UniqueValueRenderer(this);
  m_uniqueValueRenderer->setFieldNames(QStringList("ASSETGROUP"));
  UniqueValue* mediumVoltageUniqueValue = createUniqueValue(QString("Medium Voltage"), m_mediumVoltageSymbol, 5);
  UniqueValue* lowVoltageUniqueValue = createUniqueValue(QString("Low Voltage"), m_lowVoltageSymbol, 3);

  // append to UniqueValueRenderer
  m_uniqueValueRenderer->uniqueValues()->append(mediumVoltageUniqueValue);
  m_uniqueValueRenderer->uniqueValues()->append(lowVoltageUniqueValue);

  // set unique value renderer to the line layer
  m_lineLayer->setRenderer(m_uniqueValueRenderer);
}

void TraceUtilityNetwork::loadUtilityNetwork(const Error& error)
{
  if (hasErrorOccurred(error))
    return;

  m_utilityNetwork = m_map->utilityNetworks()->first();
  m_utilityNetwork->load();

  // Create graphics overlay and append to mapview
  m_graphicsOverlay = new GraphicsOverlay(this);
  m_mapView->graphicsOverlays()->append(m_graphicsOverlay);

  connect(m_utilityNetwork, &UtilityNetwork::errorOccurred, this, &TraceUtilityNetwork::hasErrorOccurred);

  connect(m_utilityNetwork, &UtilityNetwork::doneLoading, this, [this](const Error& error)
  {
    if (hasErrorOccurred(error))
      return;

    createFeatureLayers();
    createRenderers();
    connectSignals();
  });

  setBusyIndicator(true);
}

bool TraceUtilityNetwork::hasErrorOccurred(const Error& error)
{
  if (error.isEmpty())
    return false;

  m_dialogText = QString(error.message() + " - " + error.additionalMessage());
  emit dialogVisibleChanged();
  return true;
}

void TraceUtilityNetwork::onTaskFailed_(const Esri::ArcGISRuntime::ErrorException& exception)
{
  m_dialogText = QString(exception.error().message() + " - " + exception.error().additionalMessage());
  emit dialogVisibleChanged();
}

void TraceUtilityNetwork::connectSignals()
{
  // identify layers on mouse click
  connect(m_mapView, &MapQuickView::mouseClicked, this, [this](QMouseEvent& mouseEvent)
  {
    if (m_map->loadStatus() != LoadStatus::Loaded)
      return;

    constexpr double tolerance = 10.0;
    constexpr bool returnPopups = false;
    m_clickPoint = m_mapView->screenToLocation(mouseEvent.position().x(), mouseEvent.position().y());
    m_taskCanceler->addTask(m_mapView->identifyLayersAsync(mouseEvent.position(), tolerance, returnPopups).then(this, [this](const QList<IdentifyLayerResult*>& results)
    {
      onIdentifyLayersCompleted_(results);
    }));
  });
}

TraceUtilityNetwork::~TraceUtilityNetwork() = default;

void TraceUtilityNetwork::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<TraceUtilityNetwork>("Esri.Samples", 1, 0, "TraceUtilityNetworkSample");
}

MapQuickView* TraceUtilityNetwork::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void TraceUtilityNetwork::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  emit mapViewChanged();
}

void TraceUtilityNetwork::multiTerminalIndex(int index)
{
  if (m_terminals.isEmpty())
    return;

  if (!m_feature)
    return;

  UtilityElement* element = m_utilityNetwork->createElementWithArcGISFeature(m_feature, m_terminals[index]);
  updateTraceParams(element);
}

void TraceUtilityNetwork::updateTraceParams(UtilityElement* element)
{
  if (m_startingLocationsEnabled)
  {
    m_startingLocations.append(element);
    Graphic* traceLocation = new Graphic(m_clickPoint, m_startingSymbol, m_graphicParent.get());
    m_graphicsOverlay->graphics()->append(traceLocation);
  }
  else
  {
    m_barriers.append(element);
    Graphic* traceLocation = new Graphic(m_clickPoint, m_barrierSymbol, m_graphicParent.get());
    m_graphicsOverlay->graphics()->append(traceLocation);
  }
}

void TraceUtilityNetwork::trace(int index)
{
  setBusyIndicator(true);

  delete m_traceParams;

  switch (index)
  {
    case 0:
      m_traceParams = new UtilityTraceParameters(UtilityTraceType::Connected, {}, this);
      break;
    case 1:
      m_traceParams = new UtilityTraceParameters(UtilityTraceType::Subnetwork, {}, this);
      break;
    case 2:
      m_traceParams = new UtilityTraceParameters(UtilityTraceType::Upstream, {}, this);
      break;
    case 3:
      m_traceParams = new UtilityTraceParameters(UtilityTraceType::Downstream, {}, this);
      break;
    default:
      return;
  }

  if (m_mediumVoltageTier)
    m_traceParams->setTraceConfiguration(m_mediumVoltageTier->defaultTraceConfiguration());

  m_traceParams->setStartingLocations(m_startingLocations);
  m_traceParams->setBarriers(m_barriers);
  // Perform a connected trace on the utility network
  m_taskCanceler->addTask(m_utilityNetwork->traceAsync(m_traceParams).then(this, [this](QList<UtilityTraceResult*>)
  {
    onTraceCompleted_();
  }).onFailed([this](const ErrorException& exception)
  {
    onTaskFailed_(exception);
  }));
}

void TraceUtilityNetwork::reset()
{
  m_startingLocations.clear();
  m_barriers.clear();
  if (m_traceParams)
  {
    m_traceParams->setStartingLocations(m_startingLocations);
    m_traceParams->setBarriers(m_barriers);
  }

  m_graphicsOverlay->graphics()->clear();
  m_graphicParent.reset(new QObject());

  for (Layer* layer : *m_map->operationalLayers())
  {
    FeatureLayer* featureLayer = dynamic_cast<FeatureLayer*>(layer);
    if (!featureLayer)
      return;

    featureLayer->clearSelection();
  }
}

void TraceUtilityNetwork::onIdentifyLayersCompleted_(const QList<IdentifyLayerResult*>& results)
{
  if (results.isEmpty())
  {
    m_dialogText = QString("Could not identify location.");
    emit dialogTextChanged();
    m_dialogVisible = true;
    emit dialogVisibleChanged();
    return;
  }

  // Get domain network
  const UtilityDomainNetwork* domainNetwork = m_utilityNetwork->definition()->domainNetwork("ElectricDistribution");
  m_mediumVoltageTier = domainNetwork->tier("Medium Voltage Radial");

  const IdentifyLayerResult* result = results[0];
  m_feature = static_cast<ArcGISFeature*>(std::as_const(result)->geoElements()[0]);
  UtilityElement* element = nullptr;
  const UtilityNetworkSource* networkSource = m_utilityNetwork->definition()->networkSource(m_feature->featureTable()->tableName());

  if (networkSource->sourceType() == UtilityNetworkSourceType::Junction)
  {
    m_junctionSelected = true;
    emit junctionSelectedChanged();

    const QString assetGroupFieldName = static_cast<ArcGISFeatureTable*>(m_feature->featureTable())->subtypeField();
    const int assetGroupCode = m_feature->attributes()->attributeValue(assetGroupFieldName).toInt();
    UtilityAssetGroup* assetGroup = nullptr;

    const auto groups = networkSource->assetGroups();
    for (UtilityAssetGroup* group : groups)
    {
      if (group->code() == assetGroupCode)
      {
        assetGroup = group;
        break;
      }
    }
    if (!assetGroup)
      return;

    const int assetTypeCode = m_feature->attributes()->attributeValue("assettype").toInt();

    UtilityAssetType* assetType = nullptr;
    const auto types = assetGroup->assetTypes();
    for (UtilityAssetType* type : types)
    {
      if (type->code() == assetTypeCode)
      {
        assetType = type;
        break;
      }
    }

    if (!assetType)
      return;

    m_terminals = assetType->terminalConfiguration()->terminals();

    if (m_terminals.size() > 1)
    {
      m_terminalDialogVisisble = true;
      emit terminalDialogVisisbleChanged();
      return;
    }
    else if (m_terminals.size() == 1)
      element = m_utilityNetwork->createElementWithArcGISFeature(m_feature, m_terminals[0]);
    else
      return;

  }
  else if (networkSource->sourceType() == UtilityNetworkSourceType::Edge)
  {
    m_junctionSelected = false;
    emit junctionSelectedChanged();

    element = m_utilityNetwork->createElementWithArcGISFeature(m_feature, nullptr, this);

    // Compute how far tapped location is along the edge feature.
    if (m_feature->geometry().geometryType() == GeometryType::Polyline)
    {
      const Polyline line = geometry_cast<Polyline>(GeometryEngine::removeZ(m_feature->geometry()));
      // Set how far the element is along the edge.
      element->setFractionAlongEdge(GeometryEngine::fractionAlong(line, m_clickPoint, -1));
      m_fractionAlongEdge = element->fractionAlongEdge();
      emit fractionAlongEdgeChanged();
    }
  }
  else
  {
    return;
  }

  updateTraceParams(element);
}

void TraceUtilityNetwork::onTraceCompleted_()
{
  m_dialogVisible = true;
  emit dialogVisibleChanged();

  if (m_utilityNetwork->traceResult()->isEmpty())
  {
    setBusyIndicator(false);
    return;
  }

  m_dialogText = QString("Trace completed.");
  emit dialogTextChanged();

  UtilityTraceResult* result = m_utilityNetwork->traceResult()->at(0);

  const QList<UtilityElement*> elements = static_cast<UtilityElementTraceResult*>(result)->elements(this);

  QueryParameters lineParams;
  QList<qint64> lineObjIds;

  for (UtilityElement* item : elements)
  {
    if (item->networkSource()->name() == "Electric Distribution Line")
      lineObjIds.append(item->objectId());
  }

  lineParams.setObjectIds(lineObjIds);

  m_taskCanceler->addTask(m_lineLayer->selectFeaturesAsync(lineParams, SelectionMode::Add).then(this, [this](FeatureQueryResult*)
  {
    setBusyIndicator(false);
  }));
}

UniqueValue* TraceUtilityNetwork::createUniqueValue(const QString& label, Esri::ArcGISRuntime::Symbol* fillSymbol, int value)
{
  // add state's attribute value for field "STATE_ABBR" to QVariantList
  QVariantList labelValue;
  labelValue.append(value);

  // set value for a State to be rendered. (label, description, attribute value list, symbol, parent)
  UniqueValue* uniqueValue = new UniqueValue(label, "", labelValue, fillSymbol, this);

  // return Unique value created
  return uniqueValue;
}

void TraceUtilityNetwork::setBusyIndicator(bool status)
{
  m_busy = status;
  emit busyChanged();

  return;
}

void TraceUtilityNetwork::handleArcGISAuthenticationChallenge(ArcGISAuthenticationChallenge* challenge)
{
  TokenCredential::createWithChallengeAsync(challenge, "viewer01", "I68VGU^nMurF", {}, this).then(this, [challenge](TokenCredential* tokenCredential)
  {
    challenge->continueWithCredential(tokenCredential);
  }).onFailed(this, [challenge](const ErrorException& e)
  {
    challenge->continueWithError(e.error());
  });
}

// [WriteFile Name=TraceUtilityNetwork, Category=UtilityNetwork]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef TraceUtilityNetwork_H
#define TraceUtilityNetwork_H

// ArcGIS Maps SDK headers
#include "Authentication/ArcGISAuthenticationChallengeHandler.h"
#include "Point.h"

// Qt headers
#include <QUrl>
#include <QUuid>

namespace Esri::ArcGISRuntime
{
class ArcGISFeature;
class Error;
class ErrorException;
class FeatureLayer;
class GraphicsOverlay;
class IdentifyLayerResult;
class Map;
class MapQuickView;
class ServiceFeatureTable;
class ServiceGeodatabase;
class SimpleFillSymbol;
class SimpleLineSymbol;
class SimpleMarkerSymbol;
class Symbol;
class UniqueValue;
class UniqueValueRenderer;
class UtilityElement;
class UtilityNetwork;
class UtilityTerminal;
class UtilityTier;
class UtilityTraceParameters;
}

namespace Esri::ArcGISRuntime::Authentication
{
  class ArcGISAuthenticationChallenge;
}


Q_MOC_INCLUDE("MapQuickView.h")
Q_MOC_INCLUDE("IdentifyLayerResult.h")

class TaskCanceler;

class TraceUtilityNetwork : public Esri::ArcGISRuntime::Authentication::ArcGISAuthenticationChallengeHandler
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(bool terminalDialogVisisble MEMBER m_terminalDialogVisisble NOTIFY terminalDialogVisisbleChanged)
  Q_PROPERTY(bool dialogVisible MEMBER m_dialogVisible NOTIFY dialogVisibleChanged)
  Q_PROPERTY(QString dialogText MEMBER m_dialogText NOTIFY dialogTextChanged)
  Q_PROPERTY(bool startingLocationsEnabled MEMBER m_startingLocationsEnabled NOTIFY startingLocationsChanged)
  Q_PROPERTY(double fractionAlongEdge MEMBER m_fractionAlongEdge NOTIFY fractionAlongEdgeChanged)
  Q_PROPERTY(bool busy MEMBER m_busy NOTIFY busyChanged)
  Q_PROPERTY(bool junctionSelected MEMBER m_junctionSelected NOTIFY junctionSelectedChanged)

public:
  explicit TraceUtilityNetwork(QObject* parent = nullptr);
  ~TraceUtilityNetwork();

  static void init();

  Q_INVOKABLE void multiTerminalIndex(int index);
  Q_INVOKABLE void trace(int index);
  Q_INVOKABLE void reset();

signals:
  void mapViewChanged();
  void terminalDialogVisisbleChanged();
  void dialogVisibleChanged();
  void dialogTextChanged();
  void startingLocationsChanged();
  void fractionAlongEdgeChanged();
  void junctionSelectedChanged();
  void busyChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);
  void connectSignals();
  void updateTraceParams(Esri::ArcGISRuntime::UtilityElement* element);
  Esri::ArcGISRuntime::UniqueValue* createUniqueValue(const QString& label, Esri::ArcGISRuntime::Symbol* fillSymbol, int value);
  void createFeatureLayers();
  void createRenderers();
  void loadUtilityNetwork(const Esri::ArcGISRuntime::Error& error);
  bool hasErrorOccurred(const Esri::ArcGISRuntime::Error& error);
  void setBusyIndicator(bool status);
  void onIdentifyLayersCompleted_(const QList<Esri::ArcGISRuntime::IdentifyLayerResult*>& results);
  void onTraceCompleted_();
  void onTaskFailed_(const Esri::ArcGISRuntime::ErrorException& exception);

  void handleArcGISAuthenticationChallenge(Esri::ArcGISRuntime::Authentication::ArcGISAuthenticationChallenge* challenge) override;

  const QUrl m_serviceUrl = QUrl("https://sampleserver7.arcgisonline.com/server/rest/services/UtilityNetwork/NapervilleElectric/FeatureServer");

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::FeatureLayer* m_lineLayer = nullptr;
  Esri::ArcGISRuntime::ServiceFeatureTable* m_deviceFeatureTable = nullptr;
  Esri::ArcGISRuntime::ServiceFeatureTable* m_lineFeatureTable = nullptr;
  Esri::ArcGISRuntime::SimpleMarkerSymbol* m_startingSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleMarkerSymbol* m_barrierSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleLineSymbol* m_mediumVoltageSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleLineSymbol* m_lowVoltageSymbol = nullptr;
  Esri::ArcGISRuntime::GraphicsOverlay* m_graphicsOverlay = nullptr;
  Esri::ArcGISRuntime::ServiceGeodatabase* m_serviceGeodatabase = nullptr;
  Esri::ArcGISRuntime::UtilityNetwork* m_utilityNetwork = nullptr;
  Esri::ArcGISRuntime::UtilityTraceParameters* m_traceParams = nullptr;
  Esri::ArcGISRuntime::ArcGISFeature* m_feature = nullptr;
  Esri::ArcGISRuntime::UtilityTier * m_mediumVoltageTier = nullptr;
  Esri::ArcGISRuntime::UniqueValueRenderer* m_uniqueValueRenderer = nullptr;

  bool m_terminalDialogVisisble = false;
  bool m_dialogVisible = false;
  bool m_startingLocationsEnabled = true;
  bool m_busy = false;
  bool m_junctionSelected = false;
  double m_fractionAlongEdge = 0.0;
  QString m_dialogText;
  Esri::ArcGISRuntime::Point m_clickPoint;
  QList<Esri::ArcGISRuntime::UtilityElement*> m_startingLocations;
  QList<Esri::ArcGISRuntime::UtilityElement*> m_barriers;
  QList<Esri::ArcGISRuntime::UtilityTerminal*> m_terminals;
  QScopedPointer<QObject> m_graphicParent;
  std::unique_ptr<TaskCanceler> m_taskCanceler;
};

#endif // TraceUtilityNetwork_H

// [WriteFile Name=TraceUtilityNetwork, Category=UtilityNetwork]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import QtQuick.Layouts
import Esri.Samples

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    TraceUtilityNetworkSample {
        id: model
        mapView: view
    }

    Dialog {
        modal: true
        standardButtons: Dialog.Ok | Dialog.Cancel
        x: (parent.width - width) / 2
        y: (parent.height - height) / 2
        visible: model.terminalDialogVisisble

        ColumnLayout {
            Text {
                text: qsTr("Select the terminal for this junction.")
                Layout.alignment: Qt.AlignHCenter
            }

            ComboBox {
                id: terminalSelection
                model: ["High", "Low"]
                Layout.alignment: Qt.AlignHCenter
            }
        }

        onAccepted: model.multiTerminalIndex(terminalSelection.currentIndex);
    }

    Dialog {
        modal: true
        standardButtons: Dialog.Ok
        x: (parent.width - width) / 2
        y: (parent.height - height) / 2
        visible: model.dialogVisible

        Text {
            text: model.dialogText
            anchors.centerIn: parent
        }
    }

    BusyIndicator {
        id: busy
        anchors.centerIn: parent
        visible: model.busy
    }

    Rectangle {
        id: backBox
        anchors {
            left: parent.left
            top: parent.top
            margins: 3
        }
        width: childrenRect.width
        height: childrenRect.height
        color: "lightgrey"
        opacity: 0.8
        radius: 5

        // catch mouse signals from propagating to parent
        MouseArea {
            anchors.fill: parent
            onClicked: mouse => mouse.accepted = true
            onWheel: wheel => wheel.accepted = true
        }

        Column {

            GridLayout {
                columns: 2
                rows: 3
                flow: GridLayout.LeftToRight
                RadioButton {
                    id: startingLocBtn
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    checked: true
                    text: qsTr("Add starting location(s)")
                    onToggled: model.startingLocationsEnabled = checked;
                }

                RadioButton {
                    id: barriersBtn
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    text: qsTr("Add barrier(s)")
                    onToggled: model.startingLocationsEnabled = !checked;
                }

                Text {
                    text: qsTr("Trace Type:")
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                }

                ComboBox {
                    id: traceTypes
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    model: ["Connected", "Subnetwork", "Upstream", "Downstream"]
                }

                Button {
                    id: resetBtn
                    text: qsTr("Reset")
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    enabled: !busy.visible
                    onClicked: model.reset();
                }

                Button {
                    id: traceBtn
                    text: qsTr("Trace")
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    enabled: !busy.visible
                    onClicked: model.trace(traceTypes.currentIndex);
                }
            }

            Text {
                // Displays fraction along edge or if a junction is selected
                text: model.junctionSelected ? qsTr("Junction selected") : qsTr("Fraction along edge: %1".arg(model.fractionAlongEdge.toFixed(6)))
                anchors.horizontalCenter: parent.horizontalCenter
            }

        }
    }
}

// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "TraceUtilityNetwork.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("TraceUtilityNetwork"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  TraceUtilityNetwork::init();

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

#if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
#endif

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));
  // Add the Runtime and Extras path
  engine.addImportPath(arcGISRuntimeImportPath);

  // Set the source
  engine.load(QUrl("qrc:/Samples/UtilityNetwork/TraceUtilityNetwork/main.qml"));

  return app.exec();
}

// Copyright 2019 ESRI
//
// All rights reserved under the copyright laws of the United States
// and applicable international laws, treaties, and conventions.
//
// You may freely redistribute and use this sample code, with or
// without modification, provided you include the original copyright
// notice and use restrictions.
//
// See the Sample code usage restrictions document for further information.
//

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    TraceUtilityNetwork {
        anchors.fill: parent
    }
}
