Change viewpoint

/*
 * Copyright 2022 Esri.
 *
 * Licensed under the Apache License, Version 2.0 (the "License");
 * you may not use this file except in compliance with the License.
 * You may obtain a copy of the License at
 *
 * http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS,
 * WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
 * See the License for the specific language governing permissions and
 * limitations under the License.
 */
module com.esri.samples.change_viewpoint {
  // require ArcGIS Maps SDK for Java module
  requires com.esri.arcgisruntime;

  // handle SLF4J http://www.slf4j.org/codes.html#StaticLoggerBinder
  requires org.slf4j.nop;

  // require JavaFX modules that the application uses
  requires javafx.graphics;
  requires javafx.controls;

  exports com.esri.samples.change_viewpoint;
}

/*
 * Copyright 2017 Esri.
 *
 * Licensed under the Apache License, Version 2.0 (the "License"); you may not
 * use this file except in compliance with the License. You may obtain a copy of
 * the License at
 *
 * http://www.apache.org/licenses/LICENSE-2.0
 *
 * Unless required by applicable law or agreed to in writing, software
 * distributed under the License is distributed on an "AS IS" BASIS, WITHOUT
 * WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied. See the
 * License for the specific language governing permissions and limitations under
 * the License.
 */

package com.esri.samples.change_viewpoint;

import javafx.application.Application;
import javafx.geometry.Insets;
import javafx.geometry.Pos;
import javafx.scene.Scene;
import javafx.scene.control.Button;
import javafx.scene.layout.Background;
import javafx.scene.layout.BackgroundFill;
import javafx.scene.layout.CornerRadii;
import javafx.scene.layout.StackPane;
import javafx.scene.layout.VBox;
import javafx.scene.paint.Paint;
import javafx.stage.Stage;

import com.esri.arcgisruntime.ArcGISRuntimeEnvironment;
import com.esri.arcgisruntime.geometry.Point;
import com.esri.arcgisruntime.geometry.PointCollection;
import com.esri.arcgisruntime.geometry.Polyline;
import com.esri.arcgisruntime.geometry.SpatialReference;
import com.esri.arcgisruntime.geometry.SpatialReferences;
import com.esri.arcgisruntime.mapping.ArcGISMap;
import com.esri.arcgisruntime.mapping.BasemapStyle;
import com.esri.arcgisruntime.mapping.Viewpoint;
import com.esri.arcgisruntime.mapping.view.MapView;

public class ChangeViewpointSample extends Application {

  private MapView mapView;
  private SpatialReference spatialReference;

  private static final int SCALE = 5000;

  @Override
  public void start(Stage stage) {

    try {
      // create stack pane and application scene
      StackPane stackPane = new StackPane();
      Scene scene = new Scene(stackPane);
      scene.getStylesheets().add(getClass().getResource("/change_viewpoint/style.css").toExternalForm());

      // set title, size, and add scene to stage
      stage.setTitle("Change Viewpoint Sample");
      stage.setWidth(800);
      stage.setHeight(700);
      stage.setScene(scene);
      stage.show();

      // authentication with an API key or named user is required to access basemaps and other location services
      String yourAPIKey = System.getProperty("apiKey");
      ArcGISRuntimeEnvironment.setApiKey(yourAPIKey);

      // create a control panel
      VBox controlsVBox = new VBox(6);
      controlsVBox.setBackground(new Background(new BackgroundFill(Paint.valueOf("rgba(0,0,0,0.3)"), CornerRadii.EMPTY,
          Insets.EMPTY)));
      controlsVBox.setPadding(new Insets(10.0));
      controlsVBox.setMaxSize(260, 120);
      controlsVBox.getStyleClass().add("panel-region");

      // create buttons for interaction
      Button animateButton = new Button("LONDON (Animate)");
      Button centerButton = new Button("WATERLOO (Center and Scaled)");
      Button geometryButton = new Button("WESTMINSTER (Geometry)");
      animateButton.setMaxWidth(Double.MAX_VALUE);
      centerButton.setMaxWidth(Double.MAX_VALUE);
      geometryButton.setMaxWidth(Double.MAX_VALUE);

      animateButton.setOnAction(e -> {
        // create the London location point
        Point londonPoint = new Point(-14093, 6711377, spatialReference);
        // create the viewpoint with the London point and scale
        Viewpoint viewpoint = new Viewpoint(londonPoint, SCALE);
        // set the map views's viewpoint to London with a seven second duration
        mapView.setViewpointAsync(viewpoint, 7);
      });

      centerButton.setOnAction(e -> {
        // create the Waterloo location point
        Point waterlooPoint = new Point(-12153, 6710527, spatialReference);
        // set the map views's viewpoint centered on Waterloo and scaled
        mapView.setViewpointCenterAsync(waterlooPoint, SCALE);
      });

      geometryButton.setOnAction(e -> {
        // create a collection of points around Westminster
        PointCollection westminsterPoints = new PointCollection(spatialReference);
        westminsterPoints.add(new Point(-13823, 6710390));
        westminsterPoints.add(new Point(-13823, 6710150));
        westminsterPoints.add(new Point(-14680, 6710390));
        westminsterPoints.add(new Point(-14680, 6710150));

        Polyline geometry = new Polyline(westminsterPoints);

        // set the map views's viewpoint to Westminster
        mapView.setViewpointGeometryAsync(geometry);
      });

      // add controls to the user interface panel
      controlsVBox.getChildren().addAll(animateButton, centerButton, geometryButton);

      // create a map with the imagery basemap style
      ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_IMAGERY);

      // create a map view and set the map to it
      mapView = new MapView();
      mapView.setMap(map);

      // create spatial reference for all points
      spatialReference = SpatialReferences.getWebMercator();
      // create point for starting location
      Point startPoint = new Point(-14093, 6711377, spatialReference);

      // set viewpoint of map view to starting point and scaled
      mapView.setViewpointCenterAsync(startPoint, SCALE);

      // add map view and control panel to stack pane
      stackPane.getChildren().addAll(mapView, controlsVBox);
      StackPane.setAlignment(controlsVBox, Pos.TOP_LEFT);
      StackPane.setMargin(controlsVBox, new Insets(10, 0, 0, 10));
    } catch (Exception e) {
      // on any error, print the stack trace
      e.printStackTrace();
    }
  }

  /**
   * Stops and releases all resources used in application.
   */
  @Override
  public void stop() {

    // release resources when the application closes
    if (mapView != null) {
      mapView.dispose();
    }
  }

  /**
   * Opens and runs application.
   *
   * @param args arguments passed to this application
   */
  public static void main(String[] args) {

    Application.launch(args);
  }

}
