<arcgis-scene id="viewElement" item-id="ea0dff6e8e3b442a9fe37560ee16f830">
<arcgis-zoom slot="top-left"> </arcgis-zoom>
<arcgis-navigation-toggle slot="top-left"> </arcgis-navigation-toggle>
<arcgis-compass slot="top-left"> </arcgis-compass>
<calcite-card id="viewshedControls" slot="top-right">
<calcite-button id="placeButton">Place viewshed</calcite-button>
<calcite-button id="cancelButton" style="display: none">Cancel </calcite-button>
<div id="promptText" style="display: none">
>Start the analysis by clicking in the scene to place the observer point and set the
<calcite-label layout="inline-space-between" id="limitFOV">
Limit maximum field of view
<calcite-switch checked id="limitFOVSwitch"></calcite-switch>
<div id="previewContainer" slot="bottom-right">
<arcgis-scene id="previewElement" hide-attribution> </arcgis-scene>
const [Camera, promiseUtils, reactiveUtils, SpatialReference, Viewshed, ViewshedAnalysis] =
"@arcgis/core/Camera.js",
"@arcgis/core/core/promiseUtils.js",
"@arcgis/core/core/reactiveUtils.js",
"@arcgis/core/geometry/SpatialReference.js",
"@arcgis/core/analysis/Viewshed.js",
"@arcgis/core/analysis/ViewshedAnalysis.js",
/**********************************************
* Component and view setup
*********************************************/
const viewElement = document.getElementById("viewElement");
const previewElement = document.querySelector("#previewElement");
const previewContainer = document.getElementById("previewContainer");
await viewElement.viewOnReady();
previewElement.map = viewElement.map;
await previewElement.viewOnReady();
/**********************************************
* Create the analysis and a viewshed
*********************************************/
// Initialize viewshed analysis and add it to the view.
const viewshedAnalysis = new ViewshedAnalysis();
viewElement.analyses.add(viewshedAnalysis);
// Create the viewshed shape programmatically and add it to the analysis.
const programmaticViewshed = new Viewshed({
spatialReference: SpatialReference.WebMercator,
farDistance: 900, // In meters
tilt: 84, // Tilt of 0 looks down, tilt of 90 looks parallel to the ground, tilt of 180 looks up to the sky
heading: 63, // Counted clockwise from North
horizontalFieldOfView: 85,
viewshedAnalysis.viewsheds.add(programmaticViewshed);
// Access the viewshed's analysis view.
const analysisView = await viewElement.whenAnalysisView(viewshedAnalysis);
// Make the analysis interactive and select the programmatic viewshed.
analysisView.interactive = true;
analysisView.selectedViewshed = programmaticViewshed;
/**********************************************
* Viewshed controls UI element
*********************************************/
// Add interactivity to the custom UI component's buttons.
const placeButton = document.getElementById("placeButton");
const cancelButton = document.getElementById("cancelButton");
const promptText = document.getElementById("promptText");
// Controller for aborting the viewshed place operation.
let abortController = null;
placeButton.addEventListener("click", () => startPlacing());
// "Cancel" button stops the viewshed placement process and updates the UI accordingly.
cancelButton.addEventListener("click", () => stopPlacing());
/**********************************************
*********************************************/
// Include a switch to the controls panel to limit the maximum field of view of the selected viewshed.
const horizontalLimit = 120;
const verticalLimit = 90;
const limitFOVSwitch = document.getElementById("limitFOVSwitch");
limitFOVSwitch.addEventListener("calciteSwitchChange", checkFOV);
reactiveUtils.watch(() => {
const viewshed = analysisView?.selectedViewshed;
return viewshed ? [viewshed.horizontalFieldOfView, viewshed.verticalFieldOfView] : null;
/**********************************************
* Preview camera at the selected viewshed's observer
*********************************************/
initializePreview(programmaticViewshed, analysisView);
// Show the preview only if a viewshed is selected.
() => analysisView?.selectedViewshed,
previewContainer.style.display = selectedViewshed ? "flex" : "none";
limitFOVSwitch.disabled = selectedViewshed ? false : true;
/**********************************************
*********************************************/
async function startPlacing() {
// Stop any pending placement operation.
// Create a new abort controller for the new operation.
abortController = new AbortController();
const { signal } = abortController;
// Update the UI to reflect that the placement process has started.
// Pass the controller as an argument to the interactive place method.
await analysisView.place({ signal: abortController.signal });
// This is used to handle the case when the viewshed placement is aborted.
if (!promiseUtils.isAbortError(error)) {
if (abortController && abortController.signal === signal) {
// Stop any pending viewshed placement operation with the abortController.
abortController?.abort();
// Update the UI component according to whether there is a pending operation.
const placing = abortController != null;
placeButton.style.display = placing ? "none" : "flex";
cancelButton.style.display = placing ? "flex" : "none";
promptText.style.display = placing ? "flex" : "none";
// Limit the selected viewshed's field of view, in case the switch is enabled.
const viewshed = analysisView?.selectedViewshed;
if (!viewshed || !limitFOVSwitch.checked) {
if (viewshed.horizontalFieldOfView > horizontalLimit) {
viewshed.horizontalFieldOfView = horizontalLimit;
if (viewshed.verticalFieldOfView > verticalLimit) {
viewshed.verticalFieldOfView = verticalLimit;
* Initializes the preview of the viewshed analysis.
function initializePreview(programmaticViewshed, analysisView) {
// Once the component is loaded, adjust more of its settings and change its camera to reflect the viewshed observer setup.
previewElement.camera = getCameraFromViewshed(programmaticViewshed);
previewElement.environment = viewElement.environment;
// Have the preview's camera update dependent on the selected viewshed.
const viewshed = analysisView.selectedViewshed;
return viewshed ? getCameraFromViewshed(viewshed) : null;
previewElement.camera = camera;
function getCameraFromViewshed(viewshed) {
position: viewshed.observer,
heading: viewshed.heading,
// Calculate camera's diagonal field of view angle.
fov: getDiagonal(viewshed.verticalFieldOfView, viewshed.horizontalFieldOfView),
function getDiagonal(a, b) {
return Math.sqrt(a ** 2 + b ** 2);
