Thematic multivariate visualization (3D)

This sample uses the recorded locations of hurricanes to demonstrate how to visualize multiple data attributes in a single renderer using 3D symbols in a SceneView. In this case a PointSymbol3D is used in conjunction with a cone primitive in an ObjectSymbol3DLayer to symbolize wind speed and pressure.

color is used to visualize atmospheric pressure and the height of each cone indicates the wind speed in knots.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
const renderer = {
  type: "simple", // autocasts as new SimpleRenderer()
  symbol: {
    // symbol type required for rendering point geometries
    type: "point-3d", // autocasts as new PointSymbol3D()
    symbolLayers: [
      {
        // renders points as volumetric objects
        type: "object", // autocasts as new ObjectSymbol3DLayer()
        resource: { primitive: "cone" }, // renders points as cones
        width: 50000
      }
    ]
  },
  visualVariables: [
    {
      type: "color",
      field: "PRESSURE", // field containing data for atmospheric pressure
      stops: [{ value: 950, color: "red" }, { value: 1020, color: "blue" }]
    },
    {
      type: "size",
      field: "WINDSPEED", // field containing data for wind speed
      stops: [{ value: 20, size: 60000 }, { value: 150, size: 500000 }],
      axis: "height"
    },
    {
      type: "size",
      axis: "width-and-depth",
      useSymbolValue: true // uses the width value defined in the symbol layer (50,000)
    }
  ]
};

The axis property of the size visual variables indicates how to define the size of each feature. the width-and-depth size variable is used to set a constant diameter to the base of each cone. The height size variable, on the other hand, uses the values of the WINDSPEED field to determine a size between 60 and 500 kilometers in height.
