Create and edit geometries

// [WriteFile Name=CreateAndEditGeometries, Category=Geometry]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "CreateAndEditGeometries.h"

// ArcGIS Maps SDK headers
#include "FreehandTool.h"
#include "GeometryEditor.h"
#include "GeometryEditorElement.h"
#include "GeometryEditorTypes.h"
#include "GeometryTypes.h"
#include "Graphic.h"
#include "GraphicListModel.h"
#include "GraphicsOverlay.h"
#include "GraphicsOverlayListModel.h"
#include "IdentifyGraphicsOverlayResult.h"
#include "InteractionConfiguration.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Multipoint.h"
#include "MultipointBuilder.h"
#include "Point.h"
#include "PointCollection.h"
#include "Polygon.h"
#include "PolygonBuilder.h"
#include "Polyline.h"
#include "PolylineBuilder.h"
#include "ReticleVertexTool.h"
#include "ShapeTool.h"
#include "SimpleFillSymbol.h"
#include "SimpleLineSymbol.h"
#include "SimpleMarkerSymbol.h"
#include "SpatialReference.h"
#include "SymbolTypes.h"
#include "VertexTool.h"

// Qt headers
#include <QFuture>
#include <QUuid>

using namespace Esri::ArcGISRuntime;

CreateAndEditGeometries::CreateAndEditGeometries(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISImagery, this))
{
  m_geometryEditor = new GeometryEditor(this);
  m_graphicsOverlay = new GraphicsOverlay(this);
  m_tempGraphicsParent = new QObject(this);

  // Create the tools to toggle between
  m_vertexTool = new VertexTool(this);
  m_freehandTool = new FreehandTool(this);
  m_arrowTool = ShapeTool::create(ShapeToolType::Arrow, this);
  m_ellipseTool = ShapeTool::create(ShapeToolType::Ellipse, this);
  m_rectangleTool = ShapeTool::create(ShapeToolType::Rectangle, this);
  m_triangleTool = ShapeTool::create(ShapeToolType::Triangle, this);
  m_reticleTool = new ReticleVertexTool(this);
}

CreateAndEditGeometries::~CreateAndEditGeometries() = default;

void CreateAndEditGeometries::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<CreateAndEditGeometries>("Esri.Samples", 1, 0, "CreateAndEditGeometriesSample");
}

// Set the view (created in QML)
void CreateAndEditGeometries::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  m_mapView->setViewpointCenterAsync(Point(-9.5920, 53.08230, SpatialReference::wgs84()), 5000);

  m_mapView->graphicsOverlays()->append(m_graphicsOverlay);

  // Set the geometry editor on the map view
  m_mapView->setGeometryEditor(m_geometryEditor);

  emit mapViewChanged();

  createInitialSymbols();
  createInitialGraphics();
  createConnections();
}

// Button methods

void CreateAndEditGeometries::startGeometryEditorWithGeometryType(GeometryEditorMode geometryEditorMode)
{
  switch (geometryEditorMode)
  {
    case GeometryEditorMode::PointMode:
      m_geometryEditor->start(GeometryType::Point);
      break;

    case GeometryEditorMode::MultipointMode:
      m_geometryEditor->start(GeometryType::Multipoint);
      break;

    case GeometryEditorMode::PolylineMode:
      m_geometryEditor->start(GeometryType::Polyline);
      break;

    case GeometryEditorMode::PolygonMode:
      m_geometryEditor->start(GeometryType::Polygon);
      break;

    default:
      break;
  }

  emit geometryEditorStartedChanged();
}

void CreateAndEditGeometries::stopEditing(bool saveGeometry)
{
  // Calling stop on the geometry editor returns the currently drawn geometry
  const Geometry geometry = m_geometryEditor->stop();
  emit geometryEditorStartedChanged();

  // If the user wants to discard edits
  if (!saveGeometry)
  {
    // If the user was editing an existing geometry, show the original graphic and clear the selection
    if (m_editingGraphic)
    {
      m_editingGraphic->setVisible(true);
      m_editingGraphic = nullptr;
    }
    return;
  }

  // If the user wants to stop editing and save the geometry
  // If the user was editing an existing graphic, update its geometry
  if (m_editingGraphic)
  {
    m_editingGraphic->setGeometry(geometry);

    // Show the graphic and clear the selection
    m_editingGraphic->setVisible(true);
    m_editingGraphic = nullptr;

    return;
  }

  // If the user was not editing an existing graphic, create a new graphic with the geometry and a symbol
  // Determine what symbology to use for the graphic
  Symbol* geometrySymbol = nullptr;
  switch (geometry.geometryType())
  {
    case GeometryType::Point:
      geometrySymbol = m_pointSymbol;
      break;

    case GeometryType::Multipoint:
      geometrySymbol = m_multiPointSymbol;
      break;

    case GeometryType::Polyline:
      geometrySymbol = m_lineSymbol;
      break;

    case GeometryType::Polygon:
      geometrySymbol = m_polygonSymbol;
      break;

    default:
      return;
  }

  // Append the new graphic to the graphics overlay
  m_graphicsOverlay->graphics()->append(new Graphic(geometry, geometrySymbol, m_tempGraphicsParent));
}

void CreateAndEditGeometries::setTool(GeometryEditorToolType toolType)
{
  switch (toolType)
  {
    case GeometryEditorToolType::Vertex:
      m_geometryEditor->setTool(m_vertexTool);
      break;

    case GeometryEditorToolType::Freehand:
      m_geometryEditor->setTool(m_freehandTool);
      break;

    case GeometryEditorToolType::Arrow:
      m_geometryEditor->setTool(m_arrowTool);
      break;

    case GeometryEditorToolType::Ellipse:
      m_geometryEditor->setTool(m_ellipseTool);
      break;

    case GeometryEditorToolType::Rectangle:
      m_geometryEditor->setTool(m_rectangleTool);
      break;

    case GeometryEditorToolType::Triangle:
      m_geometryEditor->setTool(m_triangleTool);
      break;

    case GeometryEditorToolType::Reticle:
      m_geometryEditor->setTool(m_reticleTool);

    default:
      break;
  }
}

void CreateAndEditGeometries::clearGraphics()
{
  m_graphicsOverlay->graphics()->clear();

  // Clearing the graphics overlay does not delete the graphics it contains
  // We can delete the graphics' shared parent to easily delete all of them and prevent memory leaks
  delete m_tempGraphicsParent;
  m_tempGraphicsParent = new QObject(this);
}

void CreateAndEditGeometries::undo()
{
  if (m_geometryEditor->canUndo())
    m_geometryEditor->undo();
  emit canUndoOrRedoChanged();
}

void CreateAndEditGeometries::redo()
{
  if (m_geometryEditor->canRedo())
    m_geometryEditor->redo();
  emit canUndoOrRedoChanged();
}

void CreateAndEditGeometries::deleteSelectedElement()
{
  m_geometryEditor->deleteSelectedElement();
  emit canUndoOrRedoChanged();
}

void CreateAndEditGeometries::setScaleMode(ScaleMode scaleMode)
{
  const GeometryEditorScaleMode toolScaleMode = (scaleMode == ScaleMode::UniformScaleMode) ? GeometryEditorScaleMode::Uniform : GeometryEditorScaleMode::Stretch;

  // Set the scale mode on all available tools
  m_vertexTool->configuration()->setScaleMode(toolScaleMode);
  m_freehandTool->configuration()->setScaleMode(toolScaleMode);
  m_arrowTool->configuration()->setScaleMode(toolScaleMode);
  m_ellipseTool->configuration()->setScaleMode(toolScaleMode);
  m_rectangleTool->configuration()->setScaleMode(toolScaleMode);
  m_triangleTool->configuration()->setScaleMode(toolScaleMode);
}

MapQuickView* CreateAndEditGeometries::mapView() const
{
  return m_mapView;
}

// Create slots for asynchronous signals
void CreateAndEditGeometries::createConnections()
{
  // Allow user to edit existing graphics by clicking on them
  connect(m_mapView, &MapQuickView::mouseClicked, this, [this](const QMouseEvent& mouseEvent)
  {
    if (!m_geometryEditor->isStarted())
    {
      m_mapView->identifyGraphicsOverlayAsync(m_graphicsOverlay, mouseEvent.position(), 5 ,false).then(this,
      [this](IdentifyGraphicsOverlayResult* rawResult){
        // Handle editing selected graphics, if any

        auto identifyResult = std::unique_ptr<IdentifyGraphicsOverlayResult>(rawResult);

        // Return if no graphics were identified
        if (identifyResult->graphics().isEmpty())
          return;

        m_editingGraphic = identifyResult->graphics().first();

        // Hide the graphic currently being edited
        m_editingGraphic->setVisible(false);

        // Start the geometry editor with the graphic's geometry. This does not directly affect the graphic.
        m_geometryEditor->start(m_editingGraphic->geometry());

        emit geometryEditorStartedChanged();
      });
    }
    emit canUndoOrRedoChanged();
    emit elementIsSelectedChanged();
  });

  // Enable or disable buttons when mouse is released (ie after a drag operation)
  connect(m_mapView, &MapQuickView::mouseReleased, this, [this](const QMouseEvent&)
  {
    emit canUndoOrRedoChanged();
    emit elementIsSelectedChanged();
  });
}

// State checks to control when buttons are enabled
bool CreateAndEditGeometries::geometryEditorStarted() const
{
  return (m_geometryEditor && m_geometryEditor->isStarted());
}

bool CreateAndEditGeometries::canUndo()
{
  return (m_geometryEditor && m_geometryEditor->canUndo());
}

bool CreateAndEditGeometries::canRedo()
{
  return (m_geometryEditor && m_geometryEditor->canRedo());
}

bool CreateAndEditGeometries::elementIsSelected()
{
  return (m_geometryEditor && m_geometryEditor->selectedElement() && m_geometryEditor->selectedElement()->canDelete());
}

// Create symbols used by all graphics
void CreateAndEditGeometries::createInitialSymbols()
{
  m_pointSymbol = new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Square, QColor(255, 45, 0), 10, this);
  m_multiPointSymbol = new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, QColor(255, 255, 0), 5, this);
  m_lineSymbol = new SimpleLineSymbol(SimpleLineSymbolStyle::Solid, QColor(0, 0, 255), 2, this);
  m_polygonSymbol = new SimpleFillSymbol(SimpleFillSymbolStyle::Solid, QColor(255, 0, 0, 75),
                                         new SimpleLineSymbol(SimpleLineSymbolStyle::Dash, QColor(0, 0, 0), 1.0, this), this);
}

// Create graphics that are present upon sample instantiation
void CreateAndEditGeometries::createInitialGraphics()
{
  // Create a temporary parent to give all the builders so we can easily delete them later
  QObject* tempParent = new QObject(this);

  // Create point geometry
  const Point house(-9.59309629, 53.0830063, SpatialReference::wgs84());

  // Create multipoint geometry
  MultipointBuilder* multipointBuilder = new MultipointBuilder(SpatialReference::wgs84(), tempParent);
  PointCollection* pointCollection = new PointCollection(SpatialReference::wgs84(), tempParent);
  pointCollection->addPoints(
        {
          Point(-9.59386587, 53.08289651), Point(-9.59330546, 53.08256400),
          Point(-9.59326997, 53.08304595), Point(-9.59250034, 53.08286101),
          Point(-9.59286835, 53.08311506), Point(-9.59370896, 53.08234917),
          Point(-9.59341755, 53.08286662), Point(-9.59246485, 53.08294507),
          Point(-9.59241815, 53.08284607), Point(-9.59307943, 53.08234731)
        });
  multipointBuilder->setPoints(pointCollection);
  const Multipoint outbuildings(multipointBuilder->toMultipoint());

  // Create polyline geometries
  PolylineBuilder* polylineBuilder = new PolylineBuilder(SpatialReference::wgs84(), tempParent);
  polylineBuilder->addPoints(
        {
          Point(-9.59486423, 53.08169453), Point(-9.5947812, 53.081754310),
          Point(-9.59475464, 53.08189379), Point(-9.59494393, 53.08213622),
          Point(-9.59464173, 53.08240521), Point(-9.59413694, 53.08260115),
          Point(-9.59357903, 53.08292660), Point(-9.59335984, 53.08311589),
          Point(-9.59318051, 53.08316903), Point(-9.59301779, 53.08322216),
          Point(-9.59264252, 53.08370038), Point(-9.59250636, 53.08383986)
        });

  const Polyline road1(polylineBuilder->toPolyline());
  delete polylineBuilder;

  polylineBuilder = new PolylineBuilder(SpatialReference::wgs84(), tempParent);
  polylineBuilder->addPoints(
        {
          Point(-9.59400079, 53.08136244), Point(-9.59395761, 53.08149528),
          Point(-9.59368862, 53.08170450), Point(-9.59358235, 53.08219267),
          Point(-9.59331667, 53.08290335), Point(-9.59314398, 53.08314246),
          Point(-9.59306760, 53.08330519), Point(-9.59303439, 53.08351109),
          Point(-9.59301447, 53.08363728), Point(-9.59293809, 53.08387307)
        });

  const Polyline road2(polylineBuilder->toPolyline());

  // Create polygon geometry
  PolygonBuilder* polygonBuilder = new PolygonBuilder(SpatialReference::wgs84(), tempParent);
  polygonBuilder->addPoints(
        {
          Point(-9.59350122, 53.08320723), Point(-9.59345177, 53.08333534),
          Point(-9.59309789, 53.08327198), Point(-9.59300344, 53.08317992),
          Point(-9.59221827, 53.08304034), Point(-9.59220706, 53.08287782),
          Point(-9.59229486, 53.08280871), Point(-9.59236398, 53.08268915),
          Point(-9.59255263, 53.08256769), Point(-9.59265165, 53.08237906),
          Point(-9.59287552, 53.08241478), Point(-9.59292812, 53.08230120),
          Point(-9.59322940, 53.08235022), Point(-9.59342188, 53.08260009),
          Point(-9.59354382, 53.08238728), Point(-9.59365852, 53.08203535),
          Point(-9.59408443, 53.08210446), Point(-9.59448232, 53.08224456),
          Point(-9.59436090, 53.08243697), Point(-9.59458319, 53.08245939),
          Point(-9.59439639, 53.08264619), Point(-9.59433288, 53.08279750),
          Point(-9.59404707, 53.08323649), Point(-9.59350122, 53.08320723)
        });

  const Polygon boundary(polygonBuilder->toPolygon());

  // Delete the builders' parent to clean up all objects used in creating the graphics
  delete tempParent;

  // Create graphics with the geometries
  m_graphicsOverlay->graphics()->append(
        {
          new Graphic(boundary, m_polygonSymbol, m_tempGraphicsParent),
          new Graphic(road2, m_lineSymbol, m_tempGraphicsParent),
          new Graphic(road1, m_lineSymbol, m_tempGraphicsParent),
          new Graphic(outbuildings, m_multiPointSymbol, m_tempGraphicsParent),
          new Graphic(house, m_pointSymbol, m_tempGraphicsParent)
        });
}

// [WriteFile Name=CreateAndEditGeometries, Category=Geometry]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef CREATEANDEDITGEOMETRIES_H
#define CREATEANDEDITGEOMETRIES_H

// Qt headers
#include <QObject>

namespace Esri::ArcGISRuntime
{
  class GeometryEditor;
  class Graphic;
  class GraphicsOverlay;
  class FreehandTool;
  class Map;
  class MapQuickView;
  class ShapeTool;
  class SimpleMarkerSymbol;
  class SimpleLineSymbol;
  class SimpleFillSymbol;
  class VertexTool;
  class ReticleVertexTool;
}

Q_MOC_INCLUDE("MapQuickView.h");

class CreateAndEditGeometries : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(bool geometryEditorStarted READ geometryEditorStarted NOTIFY geometryEditorStartedChanged)
  Q_PROPERTY(bool canUndo READ canUndo NOTIFY canUndoOrRedoChanged)
  Q_PROPERTY(bool canRedo READ canRedo NOTIFY canUndoOrRedoChanged)
  Q_PROPERTY(bool elementIsSelected READ elementIsSelected NOTIFY elementIsSelectedChanged)

public:
  explicit CreateAndEditGeometries(QObject* parent = nullptr);
  ~CreateAndEditGeometries() override;

  enum class GeometryEditorMode {
    PointMode,
    MultipointMode,
    PolylineMode,
    PolygonMode
  };

  Q_ENUM(GeometryEditorMode)

  enum class ScaleMode {
    StretchScaleMode,
    UniformScaleMode
  };

  Q_ENUM(ScaleMode)

  enum class GeometryEditorToolType {
    Freehand,
    Vertex,
    Arrow,
    Ellipse,
    Rectangle,
    Triangle,
    Reticle
  };

  Q_ENUM(GeometryEditorToolType)

  static void init();

  Q_INVOKABLE void startGeometryEditorWithGeometryType(GeometryEditorMode geometryEditorMode);
  Q_INVOKABLE void stopEditing(bool saveGeometry);
  Q_INVOKABLE void setTool(GeometryEditorToolType toolType);
  Q_INVOKABLE void clearGraphics();
  Q_INVOKABLE void undo();
  Q_INVOKABLE void redo();
  Q_INVOKABLE void deleteSelectedElement();
  Q_INVOKABLE void setScaleMode(ScaleMode scaleMode);

signals:
  void mapViewChanged();
  void geometryEditorStartedChanged();
  void canUndoOrRedoChanged();
  void elementIsSelectedChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);
  bool geometryEditorStarted() const;
  bool canUndo();
  bool canRedo();
  bool elementIsSelected();

  void createInitialSymbols();
  void createInitialGraphics();
  void createConnections();

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;

  Esri::ArcGISRuntime::GraphicsOverlay* m_graphicsOverlay = nullptr;
  Esri::ArcGISRuntime::Graphic* m_editingGraphic = nullptr;

  Esri::ArcGISRuntime::SimpleMarkerSymbol* m_pointSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleMarkerSymbol* m_multiPointSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleLineSymbol* m_lineSymbol = nullptr;
  Esri::ArcGISRuntime::SimpleFillSymbol* m_polygonSymbol = nullptr;

  Esri::ArcGISRuntime::GeometryEditor* m_geometryEditor = nullptr;

  // Tools
  Esri::ArcGISRuntime::VertexTool* m_vertexTool = nullptr;
  Esri::ArcGISRuntime::FreehandTool* m_freehandTool = nullptr;
  Esri::ArcGISRuntime::ShapeTool* m_arrowTool = nullptr;
  Esri::ArcGISRuntime::ShapeTool* m_ellipseTool = nullptr;
  Esri::ArcGISRuntime::ShapeTool* m_rectangleTool = nullptr;
  Esri::ArcGISRuntime::ShapeTool* m_triangleTool = nullptr;
  Esri::ArcGISRuntime::ReticleVertexTool* m_reticleTool = nullptr;

  QObject* m_tempGraphicsParent = nullptr;
};

#endif // CREATEANDEDITGEOMETRIES_H

// [WriteFile Name=CreateAndEditGeometries, Category=Geometry]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import QtQuick.Layouts
import Esri.Samples

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set and keep the focus on MapView to enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    CreateAndEditGeometriesSample {
        id: model
        mapView: view

        onGeometryEditorStartedChanged: {
            // Uncheck UI buttons when the geometry editor stops
            if (!geometryEditorStarted) {
                pointButton.checked = false;
                multiPointButton.checked = false;
                lineButton.checked = false;
                polygonButton.checked = false;
            }
        }
    }

    // Prevent mouse interaction from propagating to the MapView
    MouseArea {
        anchors.fill: control
        onPressed: mouse => mouse.accepted = true;
        onWheel: wheel => wheel.accepted = true;
    }

    Control {
        id: control
        anchors.right: parent.right
        padding: 5
        width: 140

        background: Rectangle {
            color: "black"
            opacity: .5
        }

        contentItem: ColumnLayout {
            id: columns
            anchors {
                verticalCenter: parent.verticalCenter
                horizontalCenter: parent.horizontalCenter
            }

            GridLayout {
                id: geometryColumn
                Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                columns: 2

                Text {
                    id: geometryHeader
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    Layout.columnSpan: 2
                    text: "Create"
                    color: "white"
                    font.pixelSize: 16
                    font.bold: true
                }

                GeometryEditorButton {
                    id: pointButton
                    buttonName: qsTr("Point")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/point-32.png"
                    checkable: true
                    enabled: !model.geometryEditorStarted
                    onClicked: {
                        toolCombo.currentIndex = 0;
                        toolCombo.enabled = false;
                        model.startGeometryEditorWithGeometryType(CreateAndEditGeometriesSample.PointMode);
                    }
                }

                GeometryEditorButton {
                    id: multiPointButton
                    buttonName: qsTr("Multipoint")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/multipoint-32.png"
                    checkable: true
                    enabled: !model.geometryEditorStarted
                    onClicked: {
                        toolCombo.currentIndex = 0;
                        toolCombo.enabled = false;
                        model.startGeometryEditorWithGeometryType(CreateAndEditGeometriesSample.MultipointMode);
                    }
                }

                GeometryEditorButton {
                    id: lineButton
                    buttonName: qsTr("Line")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/line-32.png"
                    checkable: true
                    enabled: !model.geometryEditorStarted
                    onClicked: {
                        model.startGeometryEditorWithGeometryType(CreateAndEditGeometriesSample.PolylineMode);
                    }
                }

                GeometryEditorButton {
                    id: polygonButton
                    buttonName: qsTr("Polygon")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/polygon-32.png"
                    checkable: true
                    enabled: !model.geometryEditorStarted
                    onClicked: {
                        model.startGeometryEditorWithGeometryType(CreateAndEditGeometriesSample.PolygonMode);
                    }
                }

                ComboBox {
                    id: toolCombo
                    model: [qsTr("Vertex Tool"), qsTr("Freehand Tool"), qsTr("Arrow Shape Tool"), qsTr("Ellipse Shape Tool"),
                           ("Rectangle Shape Tool"), qsTr("Triangle Shape Tool"), qsTr("Reticle Tool")]
                    Layout.columnSpan: 2
                    Layout.fillWidth: true

                    Rectangle {
                        anchors.fill: parent
                        radius: 10
                        // Make the rectangle visible if a dropdown indicator exists
                        // An indicator only exists if a theme is set
                        visible: parent.indicator
                        border.width: 1
                    }

                    onCurrentIndexChanged: {
                        switch (currentIndex) {
                        case 0: // Vertex Tool
                            model.setTool(CreateAndEditGeometriesSample.Vertex);
                            break;
                        case 1: // Freehand Tool
                            model.setTool(CreateAndEditGeometriesSample.Freehand);
                            break;
                        case 2: // ShapeTool with arrow shape type
                            model.setTool(CreateAndEditGeometriesSample.Arrow);
                            break;
                        case 3: // ShapeTool with ellipse shape type
                            model.setTool(CreateAndEditGeometriesSample.Ellipse);
                            break;
                        case 4: // ShapeTool with rectangle shape type
                            model.setTool(CreateAndEditGeometriesSample.Rectangle);
                            break;
                        case 5: // ShapeTool with triangle shape type
                            model.setTool(CreateAndEditGeometriesSample.Triangle);
                            break;
                        case 6: // Reticle Vertex Tool
                            model.setTool(CreateAndEditGeometriesSample.Reticle);
                            break;
                        default:
                            model.setTool(CreateAndEditGeometriesSample.Vertex);
                        }
                    }
                }
            }

            ComboBox {
                id: scaleModeDropdown
                Layout.columnSpan: 2
                Layout.fillWidth: true

                Rectangle {
                    anchors.fill: parent
                    radius: 10
                    // Make the rectangle visible if a dropdown indicator exists
                    // An indicator only exists if a theme is set
                    visible: parent.indicator
                    border.width: 1
                }

                model: ["Stretch Scale", "Uniform Scale"]
                enabled: true
                onCurrentIndexChanged: {
                    switch (currentIndex) {
                    case 0:
                        model.setScaleMode(CreateAndEditGeometriesSample.StretchScaleMode);
                        break;
                    case 1:
                        model.setScaleMode(CreateAndEditGeometriesSample.UniformScaleMode);
                        break;
                    default:
                        break;
                    }
                }

            }

            GridLayout {
                id: editingColumn
                Layout.fillWidth: true
                Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                columns: 2

                Text {
                    id: editingHeader
                    Layout.alignment: Qt.AlignHCenter | Qt.AlignVCenter
                    Layout.columnSpan: 2
                    text: qsTr("Edit")
                    color: "white"
                    font.pixelSize: 16
                    font.bold: true
                }

                GeometryEditorButton {
                    id: undoButton
                    buttonName: qsTr("Undo")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/undo-32.png"
                    enabled: model.geometryEditorStarted && model.canUndo
                    onClicked: model.undo();
                }

                GeometryEditorButton {
                    id: redoButton
                    buttonName: qsTr("Redo")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/redo-32.png"
                    enabled: model.geometryEditorStarted && model.canRedo
                    onClicked: model.redo();
                }

                GeometryEditorButton {
                    id: deleteVertexButton
                    buttonName: qsTr("Delete selected element")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/erase-32.png"
                    Layout.columnSpan: 2
                    enabled: model.geometryEditorStarted && model.elementIsSelected
                    onClicked: model.deleteSelectedElement();
                }

                GeometryEditorButton {
                    id: saveEditsButton
                    buttonName: qsTr("Stop and save edits")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/check-circle-32.png"
                    Layout.columnSpan: 2
                    enabled: model.geometryEditorStarted
                    onClicked: {
                        toolCombo.enabled = true;
                        model.stopEditing(true);
                    }
                }

                GeometryEditorButton {
                    id: discardEditsButton
                    buttonName: qsTr("Stop and discard edits")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/circle-disallowed-32.png"
                    Layout.columnSpan: 2
                    enabled: model.geometryEditorStarted
                    onClicked: {
                        toolCombo.enabled = true;
                        model.stopEditing(false);
                    }
                }

                GeometryEditorButton {
                    id: clearGraphicsButton
                    buttonName: qsTr("Delete all geometries")
                    iconPath: "qrc:/Samples/Geometry/CreateAndEditGeometries/iconAssets/trash-32.png"
                    Layout.columnSpan: 2
                    enabled: !model.geometryEditorStarted
                    onClicked: model.clearGraphics();
                }
            }
        }
    }
}

// [WriteFile Name=CreateAndEditGeometries, Category=Geometry]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import QtQuick.Layouts

// This component defines each of the buttons in the Geometry Editor control UI

RoundButton {
    id: geometryEditorButton

    property string buttonName: ""
    property string iconPath: ""

    Layout.fillWidth: true

    // Set the focus policy so that the buttons do not take focus from the MapView
    focusPolicy: Qt.NoFocus

    radius: 5

    Rectangle {
        anchors.fill: parent
        radius: parent.radius
        opacity: parent.enabled || parent.checked ? 1 : 0.3
        color: geometryEditorButton.down ? "#d0d0d0" : "#e0e0e0"
    }

    Image {
        id: imgComponent
        anchors {
            horizontalCenter: parent.horizontalCenter
            verticalCenter: parent.verticalCenter
            verticalCenterOffset: -textComponent.height/2
        }
        source: iconPath
        width: 20
        fillMode: Image.PreserveAspectFit
    }

    Text {
        id: textComponent
        anchors {
            top: imgComponent.bottom
            horizontalCenter: parent.horizontalCenter
        }
        text: buttonName
        font.pixelSize: 8
    }
}

// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "CreateAndEditGeometries.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("CreateAndEditGeometries"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  CreateAndEditGeometries::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  // Set the source
  engine.load(QUrl("qrc:/Samples/Geometry/CreateAndEditGeometries/main.qml"));

  return app.exec();
}

// Copyright 2023 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    CreateAndEditGeometries {
        anchors.fill: parent
    }
}
