Geodesic operations

// [WriteFile Name=GeodesicOperations, Category=Geometry]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "GeodesicOperations.h"

// ArcGIS Maps SDK headers
#include "AngularUnit.h"
#include "GeodeticDistanceResult.h"
#include "GeometryEngine.h"
#include "Graphic.h"
#include "GraphicListModel.h"
#include "GraphicsOverlay.h"
#include "GraphicsOverlayListModel.h"
#include "LinearUnit.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Point.h"
#include "PolylineBuilder.h"
#include "SimpleLineSymbol.h"
#include "SimpleMarkerSymbol.h"
#include "SpatialReference.h"
#include "SymbolTypes.h"

using namespace Esri::ArcGISRuntime;

GeodesicOperations::GeodesicOperations(QQuickItem* parent /* = nullptr */):
  QQuickItem(parent)
{
}

void GeodesicOperations::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<GeodesicOperations>("Esri.Samples", 1, 0, "GeodesicOperationsSample");
}

void GeodesicOperations::componentComplete()
{
  QQuickItem::componentComplete();

  // find QML MapView component
  m_mapView = findChild<MapQuickView*>("mapView");

  // Create a map using the imagery basemap
  m_map = new Map(BasemapStyle::ArcGISImageryStandard, this);

  // Set map to map view
  m_mapView->setMap(m_map);

  // Create a GraphicsOverlay
  GraphicsOverlay* graphicsOverlay = new GraphicsOverlay(this);
  m_mapView->graphicsOverlays()->append(graphicsOverlay);

  // Create Graphic Symbols
  SimpleMarkerSymbol* markerSymbol = new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, QColor("blue"), 10.0f /*size*/, this);
  SimpleLineSymbol* pathSymbol = new SimpleLineSymbol(SimpleLineSymbolStyle::Dash, QColor("blue"), 5.0f /*width*/, this);

  // Create NYC graphic
  const Point nycPoint(-73.7781, 40.6413, SpatialReference(4326));
  m_nycGraphic = new Graphic(nycPoint, markerSymbol, this);
  graphicsOverlay->graphics()->append(m_nycGraphic);

  // Create destination graphic
  m_destinationGraphic = new Graphic(this);
  m_destinationGraphic->setSymbol(markerSymbol);
  graphicsOverlay->graphics()->append(m_destinationGraphic);

  // Create path graphic
  m_pathGraphic = new Graphic(this);
  m_pathGraphic->setSymbol(pathSymbol);
  graphicsOverlay->graphics()->append(m_pathGraphic);

  // connect to mouse clicked signal
  connect(m_mapView, &MapQuickView::mouseClicked, this, [this, nycPoint](QMouseEvent& mouseEvent)
  {
    // re-project the point to match the NYC graphic
    const Point clickedPoint = m_mapView->screenToLocation(mouseEvent.position().x(), mouseEvent.position().y());
    const Point destination = geometry_cast<Point>(GeometryEngine::project(clickedPoint, m_nycGraphic->geometry().spatialReference()));

    // update the destination graphic
    m_destinationGraphic->setGeometry(destination);

    // create line with start/end points
    const QList<Point> points = {nycPoint, destination};
    const Polyline polyline = pointsToPolyline(points);

    // densify the path as a geodesic curve and show it with the path graphic
    constexpr double maxSegmentLength = 1.0;
    const LinearUnit linearUnitOfMeasurementKm = LinearUnit::kilometers();
    const AngularUnit angularUnitOfMeasurementRads = AngularUnit::radians();
    constexpr GeodeticCurveType curveType = GeodeticCurveType::Geodesic;
    const Geometry pathGeometry = GeometryEngine::densifyGeodetic(polyline, maxSegmentLength, linearUnitOfMeasurementKm, curveType);

    // update the graphic
    m_pathGraphic->setGeometry(pathGeometry);

    // calculate the path's geodetic length
    const GeodeticDistanceResult result = GeometryEngine::distanceGeodetic(nycPoint, destination, linearUnitOfMeasurementKm, angularUnitOfMeasurementRads, curveType);
    m_distanceText = QString::number(result.distance());
    emit distanceTextChanged();
  });
}

// helper function to create a new Polyline from a list of points
Polyline GeodesicOperations::pointsToPolyline(const QList<Point>& points)
{
  PolylineBuilder polylineBuilder(SpatialReference(4326));
  for (const Point& point : points)
    polylineBuilder.addPoint(point);

  return polylineBuilder.toPolyline();
}

QString GeodesicOperations::distanceText() const
{
  return m_distanceText;
}

// [WriteFile Name=GeodesicOperations, Category=Geometry]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef GEODESICOPERATIONS_H
#define GEODESICOPERATIONS_H

// ArcGIS Maps SDK headers
#include "Point.h"
#include "Polyline.h"

// Qt headers
#include <QQuickItem>

namespace Esri::ArcGISRuntime
{
class Map;
class MapQuickView;
class Graphic;
}

class GeodesicOperations : public QQuickItem
{
  Q_OBJECT

  Q_PROPERTY(QString distanceText READ distanceText NOTIFY distanceTextChanged)

public:
  explicit GeodesicOperations(QQuickItem* parent = nullptr);
  ~GeodesicOperations() override = default;

  void componentComplete() override;
  static void init();

signals:
  void distanceTextChanged();

private:
  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::Graphic* m_nycGraphic = nullptr;
  Esri::ArcGISRuntime::Graphic* m_pathGraphic = nullptr;
  Esri::ArcGISRuntime::Graphic* m_destinationGraphic = nullptr;
  QString m_distanceText;

private:
  Esri::ArcGISRuntime::Polyline pointsToPolyline(const QList<Esri::ArcGISRuntime::Point>& points);
  QString distanceText() const;
};

#endif // GEODESICOPERATIONS_H

// [WriteFile Name=GeodesicOperations, Category=Geometry]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

GeodesicOperationsSample {
    id: rootRectangle
    clip: true
    width: 800
    height: 600

    // add a mapView component
    MapView {
        anchors.fill: parent
        objectName: "mapView"

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // display text for geodesic length
    Text {
        anchors {
            left: parent.left
            top: parent.top
            margins: 10
        }

        text: "%1 kilometers".arg(distanceText)
        visible: distanceText.length > 0
        font.pixelSize: 20
        color: "white"
    }
}

// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "GeodesicOperations.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("GeodesicOperations"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  GeodesicOperations::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

#if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
#endif

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));
  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/Geometry/GeodesicOperations/GeodesicOperations.qml"));

  view.show();

  return app.exec();
}
