Edit and sync features

// [WriteFile Name=EditAndSyncFeatures, Category=EditData]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "EditAndSyncFeatures.h"

// ArcGIS Maps SDK headers
#include "ArcGISFeature.h"
#include "ArcGISTiledLayer.h"
#include "Basemap.h"
#include "Envelope.h"
#include "Error.h"
#include "FeatureLayer.h"
#include "GenerateGeodatabaseJob.h"
#include "GenerateGeodatabaseParameters.h"
#include "GenerateLayerOption.h"
#include "Geodatabase.h"
#include "GeodatabaseFeatureTable.h"
#include "GeodatabaseSyncTask.h"
#include "GeometryEngine.h"
#include "IdentifyLayerResult.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapViewTypes.h"
#include "Point.h"
#include "ServiceFeatureTable.h"
#include "SpatialReference.h"
#include "SyncGeodatabaseJob.h"
#include "SyncLayerOption.h"
#include "TaskTypes.h"
#include "TileCache.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>
#include <QStandardPaths>
#include <QUrl>
#include <QUuid>
#include <QtCore/qglobal.h>

using namespace Esri::ArcGISRuntime;

// helper method to get cross platform data path
namespace
{
  QString defaultDataPath()
  {
    QString dataPath;

  #ifdef Q_OS_IOS
    dataPath = QStandardPaths::writableLocation(QStandardPaths::DocumentsLocation);
  #else
    dataPath = QStandardPaths::writableLocation(QStandardPaths::HomeLocation);
  #endif

    return dataPath;
  }
} // namespace

EditAndSyncFeatures::EditAndSyncFeatures(QQuickItem* parent /* = nullptr */):
  QQuickItem(parent),
  m_dataPath(defaultDataPath() + "/ArcGIS/Runtime/Data/")
{
}

EditAndSyncFeatures::~EditAndSyncFeatures()
{
  // unregister geodatabase
  auto f = m_syncTask->unregisterGeodatabaseAsync(m_offlineGdb);
  Q_UNUSED(f)
}

void EditAndSyncFeatures::init()
{
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<EditAndSyncFeatures>("Esri.Samples", 1, 0, "EditAndSyncFeaturesSample");
}

void EditAndSyncFeatures::componentComplete()
{
  QQuickItem::componentComplete();

  // find QML MapView component
  m_mapView = findChild<MapQuickView*>("mapView");
  m_mapView->setWrapAroundMode(WrapAroundMode::Disabled);

  // Create a map using a local tile package
  TileCache* tileCache = new TileCache(m_dataPath + "tpkx/SanFrancisco.tpkx", this);
  ArcGISTiledLayer* tiledLayer = new ArcGISTiledLayer(tileCache, this);
  Basemap* basemap = new Basemap(tiledLayer, this);
  m_map = new Map(basemap, this);

  // add a feature service to the map
  ServiceFeatureTable* featureTable = new ServiceFeatureTable(QUrl(m_featureServiceUrl + QString::number(m_featureLayerId)), this);
  FeatureLayer* featureLayer = new FeatureLayer(featureTable, this);
  m_map->operationalLayers()->append(featureLayer);

  // set an initial viewpoint
  Envelope env(-122.50017, 37.74500, -122.43843, 37.81638, SpatialReference(4326));
  Viewpoint viewpoint(env);
  m_map->setInitialViewpoint(viewpoint);

  // Set map to map view
  m_mapView->setMap(m_map);

  // create the GeodatabaseSyncTask
  m_syncTask = new GeodatabaseSyncTask(QUrl(m_featureServiceUrl), this);

  connectSignals();
}

void EditAndSyncFeatures::connectSignals()
{
  // lambda expression for the mouse clicked signal on the mapview
  connect(m_mapView, &MapQuickView::mouseClicked, this, [this](QMouseEvent& mouseEvent)
  {
    if (m_isOffline)
    {
      if (!m_selectedFeature)
      {
        m_mapView->identifyLayerAsync(m_map->operationalLayers()->first(), mouseEvent.position(), 5, false, 1).then(this, [this](IdentifyLayerResult* identifyResult)
        {
          // once the identify is done
          if (!identifyResult)
            return;

          // clear any existing selection
          FeatureLayer* featureLayer = static_cast<FeatureLayer*>(m_map->operationalLayers()->first());
          featureLayer->clearSelection();
          m_selectedFeature = nullptr;

          if (identifyResult->geoElements().length() > 0)
          {
            GeoElement* geoElement = identifyResult->geoElements().at(0);
            m_selectedFeature = static_cast<ArcGISFeature*>(geoElement);
            featureLayer->selectFeature(m_selectedFeature);
            emit updateInstruction("Tap on map to move feature");
          }
        });
      }
      else
      {
        // connect to feature table signal
        FeatureLayer* featureLayer = static_cast<FeatureLayer*>(m_map->operationalLayers()->at(0));

        // get the point from the mouse point
        const Point mapPoint = m_mapView->screenToLocation(mouseEvent.position().x(), mouseEvent.position().y());
        m_selectedFeature->setGeometry(mapPoint);
        featureLayer->featureTable()->updateFeatureAsync(m_selectedFeature).then(this, [this, featureLayer]()
        {
          featureLayer->clearSelection();
          m_selectedFeature = nullptr;
          emit updateInstruction("Tap the sync button");
          emit showButton();
        });
      }
    }
  });
}

//! [EditAndSyncFeatures parameters generate]
GenerateGeodatabaseParameters EditAndSyncFeatures::getGenerateParameters(Envelope gdbExtent)
{
  // create the parameters
  GenerateGeodatabaseParameters params;
  params.setReturnAttachments(false);
  params.setOutSpatialReference(SpatialReference::webMercator());
  params.setExtent(gdbExtent);

  // set the layer options for 1 layer
  QList<GenerateLayerOption> layerOptions;
  GenerateLayerOption generateLayerOption(m_featureLayerId);
  layerOptions << generateLayerOption;
  params.setLayerOptions(layerOptions);

  return params;
}
//! [EditAndSyncFeatures parameters generate]

//! [EditAndSyncFeatures parameters sync]
SyncGeodatabaseParameters EditAndSyncFeatures::getSyncParameters()
{
  // create the parameters
  SyncGeodatabaseParameters params;
  params.setGeodatabaseSyncDirection(SyncDirection::Bidirectional);

  // set the layer options for 1 layer
  QList<SyncLayerOption> layerOptions;
  SyncLayerOption syncLayerOption(m_featureLayerId);
  layerOptions << syncLayerOption;
  params.setLayerOptions(layerOptions);

  return params;
}
//! [EditAndSyncFeatures parameters sync]

//! [EditAndSyncFeatures generate]
void EditAndSyncFeatures::generateGeodatabaseFromCorners(double xCorner1, double yCorner1, double xCorner2, double yCorner2)
{
  // create an envelope from the QML rectangle corners
  const Point corner1 = m_mapView->screenToLocation(xCorner1, yCorner1);
  const Point corner2 = m_mapView->screenToLocation(xCorner2, yCorner2);
  const Envelope extent(corner1, corner2);
  const Envelope geodatabaseExtent = geometry_cast<Envelope>(GeometryEngine::project(extent, SpatialReference::webMercator()));

  // get the updated parameters
  GenerateGeodatabaseParameters params = getGenerateParameters(geodatabaseExtent);

  // execute the task and obtain the job
  const QString outputGdb = m_temporaryDir.path() + "/Wildfire.geodatabase";
  GenerateGeodatabaseJob* generateJob = m_syncTask->generateGeodatabase(params, outputGdb);

  // connect to the job's status changed signal
  if (generateJob)
  {
    connect(generateJob, &GenerateGeodatabaseJob::statusChanged, this, [this, generateJob](JobStatus jobStatus)
    {
      // connect to the job's status changed signal to know once it is done
      switch (jobStatus) {
      case JobStatus::Failed:
        emit updateStatus("Generate failed");
        emit hideWindow(5000, false);
        break;
      case JobStatus::NotStarted:
        emit updateStatus("Job not started");
        break;
      case JobStatus::Paused:
        emit updateStatus("Job paused");
        break;
      case JobStatus::Started:
        emit updateStatus("In progress...");
        break;
      case JobStatus::Succeeded:
        m_isOffline = true;
        m_offlineGdb = generateJob->result();
        emit isOfflineChanged();
        emit updateStatus("Complete");
        emit hideWindow(1500, true);
        emit updateInstruction("Tap on a feature");
        addOfflineData();
        break;
      default:
        break;
      }
    });

    // start the generate job
    generateJob->start();
  }
  //! [EditAndSyncFeatures generate]
  else
  {
    emit updateStatus("Generate failed");
    emit hideWindow(5000, false);
  }
}

void EditAndSyncFeatures::addOfflineData()
{
  // remove the original online feature layers
  m_map->operationalLayers()->clear();

  // load the geodatabase
  connect(m_offlineGdb, &Geodatabase::doneLoading, this, [this](Error)
  {
    // create a feature layer from each feature table, and add to the map
    const auto tables = m_offlineGdb->geodatabaseFeatureTables();
    for (GeodatabaseFeatureTable* featureTable : tables)
    {
      FeatureLayer* featureLayer = new FeatureLayer(featureTable, this);
      m_map->operationalLayers()->append(featureLayer);
    }
  });
  m_offlineGdb->load();
}

bool EditAndSyncFeatures::isOffline() const
{
  return m_isOffline;
}

//! [EditAndSyncFeatures executeSync]
void EditAndSyncFeatures::executeSync()
{
  // get the updated parameters
  SyncGeodatabaseParameters params = getSyncParameters();

  // execute the task and obtain the job
  SyncGeodatabaseJob* syncJob = m_syncTask->syncGeodatabase(params, m_offlineGdb);

  // connect to the job's status changed signal
  if (syncJob)
  {
    connect(syncJob, &GenerateGeodatabaseJob::statusChanged, this, [this](JobStatus jobStatus)
    {
      // connect to the job's status changed signal to know once it is done
      switch (jobStatus) {
      case JobStatus::Failed:
        emit updateStatus("Sync failed");
        emit hideWindow(5000, false);
        break;
      case JobStatus::NotStarted:
        emit updateStatus("Job not started");
        break;
      case JobStatus::Paused:
        emit updateStatus("Job paused");
        break;
      case JobStatus::Started:
        emit updateStatus("In progress...");
        break;
      case JobStatus::Succeeded:
        m_isOffline = true;
        emit isOfflineChanged();
        emit updateStatus("Complete");
        emit hideWindow(1500, true);
        emit updateInstruction("Tap on a feature");
        break;
      default:
        break;
      }
    });

    // start the sync job
    syncJob->start();
  }
  //! [EditAndSyncFeatures executeSync]
  else
  {
    emit updateStatus("Sync failed");
    emit hideWindow(5000, false);
  }
}

// [WriteFile Name=EditAndSyncFeatures, Category=EditData]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef EDITANDSYNCFEATURES_H
#define EDITANDSYNCFEATURES_H

// ArcGIS Maps SDK headers
#include "GenerateGeodatabaseParameters.h"
#include "SyncGeodatabaseParameters.h"

// Qt headers
#include <QQuickItem>
#include <QString>
#include <QTemporaryDir>
#include <QUrl>

namespace Esri::ArcGISRuntime
{
  class Map;
  class MapQuickView;
  class GeodatabaseSyncTask;
  class Geodatabase;
  class ArcGISFeature;
  class Envelope;
}

class EditAndSyncFeatures : public QQuickItem
{
  Q_OBJECT

  Q_PROPERTY(bool isOffline READ isOffline NOTIFY isOfflineChanged)

public:
  explicit EditAndSyncFeatures(QQuickItem* parent = nullptr);
  ~EditAndSyncFeatures() override;

  void componentComplete() override;
  static void init();
  Q_INVOKABLE void generateGeodatabaseFromCorners(double xCorner1, double yCorner1, double xCorner2, double yCorner2);
  Q_INVOKABLE void executeSync();

signals:
  void updateStatus(QString status);
  void hideWindow(int time, bool success);
  void updateInstruction(QString instruction);
  void isOfflineChanged();
  void showButton();

private:
  void connectSignals();
  Esri::ArcGISRuntime::GenerateGeodatabaseParameters getGenerateParameters(Esri::ArcGISRuntime::Envelope gdbExtent);
  Esri::ArcGISRuntime::SyncGeodatabaseParameters getSyncParameters();
  void addOfflineData();
  bool isOffline() const;

private:
  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::GeodatabaseSyncTask* m_syncTask = nullptr;
  Esri::ArcGISRuntime::Geodatabase* m_offlineGdb = nullptr;
  Esri::ArcGISRuntime::ArcGISFeature* m_selectedFeature = nullptr;
  QString m_dataPath;
  qint64 m_featureLayerId = 0;
  QString m_featureServiceUrl = QStringLiteral("https://sampleserver6.arcgisonline.com/arcgis/rest/services/Sync/WildfireSync/FeatureServer/");
  bool m_isOffline = false;
  QTemporaryDir m_temporaryDir;
};

#endif // EDITANDSYNCFEATURES_H

// [WriteFile Name=EditAndSyncFeatures, Category=EditData]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

EditAndSyncFeaturesSample {
    id: editAndSyncSample
    clip: true
    width: 800
    height: 600

    property string statusText: ""
    property string instructionText: ""
    property var selectedFeature: null

    // add a mapView component
    MapView {
        anchors.fill: parent
        objectName: "mapView"

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    onHideWindow: (time, success) => {
        syncWindow.hideWindow(time);

        if (success) {
            extentRectangle.visible = false;
            syncButton.visible = false;
        }
    }

    onUpdateInstruction: instruction => {
        instructions.visible = true;
        instructionText = instruction;
    }

    onShowButton: syncButton.visible = true;

    onUpdateStatus: status => statusText = status;

    // create an extent rectangle for the output geodatabase
    Rectangle {
        id: extentRectangle
        anchors.centerIn: parent
        width: parent.width - (50)
        height: parent.height - (125)
        color: "transparent"
        border {
            color: "red"
            width: 3
        }
    }

    // Create the button to generate/sync geodatabase
    Rectangle {
        id: syncButton
        property bool pressed: false
        anchors {
            horizontalCenter: parent.horizontalCenter
            bottom: parent.bottom
            bottomMargin: 23
        }

        width: isOffline ? 175 : 200
        height: 35
        color: pressed ? "#959595" : "#D6D6D6"
        radius: 8
        border {
            color: "#585858"
            width: 1
        }

        Row {
            anchors.fill: parent
            spacing: 5
            Image {
                width: 38
                height: width
                source: isOffline ? "qrc:/Samples/EditData/EditAndSyncFeatures/sync.png" : "qrc:/Samples/EditData/EditAndSyncFeatures/download.png"
            }

            Text {
                anchors.verticalCenter: parent.verticalCenter
                text: isOffline ? "Sync Geodatabase" : "Generate Geodatabase"
                font.pixelSize: 14
                color: "#474747"
            }
        }

        MouseArea {
            anchors.fill: parent
            onPressed: syncButton.pressed = true
            onReleased: syncButton.pressed = false
            onClicked: {
                if (isOffline) {
                    instructions.visible = false;
                    editAndSyncSample.executeSync();
                    syncWindow.visible = true;
                } else {
                    editAndSyncSample.generateGeodatabaseFromCorners(extentRectangle.x, extentRectangle.y, (extentRectangle.x + extentRectangle.width), (extentRectangle.y + extentRectangle.height));
                    syncWindow.visible = true;
                }
            }
        }
    }

    // Create a bar to display editing instructions
    Rectangle {
        id: instructions
        anchors {
            top: parent.top
            left: parent.left
            right: parent.right
        }
        height: 25
        color: "gray"
        opacity: 0.9
        visible: false

        Text {
            anchors.centerIn: parent
            text: instructionText
            font.pixelSize: 16
            color: "white"
        }
    }

    // Create a window to display the generate/sync window
    Rectangle {
        id: syncWindow
        anchors.fill: parent
        color: "transparent"
        clip: true
        visible: false

        Rectangle {
            anchors.fill: parent
            color: "#60000000"
        }

        MouseArea {
            anchors.fill: parent
            onClicked: mouse => mouse.accepted = true
            onWheel: wheel => wheel.accepted = true
        }

        Rectangle {
            anchors.centerIn: parent
            width: 125
            height: 100
            color: "lightgrey"
            opacity: 0.8
            radius: 5
            border {
                color: "#4D4D4D"
                width: 1
            }

            Column {
                anchors {
                    fill: parent
                    margins: 10
                }
                spacing: 10

                BusyIndicator {
                    anchors.horizontalCenter: parent.horizontalCenter
                }

                Text {
                    anchors.horizontalCenter: parent.horizontalCenter
                    text: statusText
                    font.pixelSize: 16
                }
            }
        }

        Timer {
            id: hideWindowTimer

            onTriggered: {
                syncWindow.visible = false;
                instructions.visible = true;
                instructionText = "Tap on a feature";
            }
        }

        function hideWindow(time) {
            hideWindowTimer.interval = time;
            hideWindowTimer.restart();
        }
    }
}

// [Legal]
// Copyright 2015 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "EditAndSyncFeatures.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("Edit and Sync Features"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  EditAndSyncFeatures::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

 #if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
 #endif

  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/EditData/EditAndSyncFeatures/EditAndSyncFeatures.qml"));

  view.show();

  return app.exec();
}
