Create mobile geodatabase

// [WriteFile Name=CreateMobileGeodatabase, Category=Features]
// [Legal]
// Copyright 2022 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "CreateMobileGeodatabase.h"
#include "FeatureListModel.h"

// ArcGIS Maps SDK headers
#include "FeatureIterator.h"
#include "FeatureLayer.h"
#include "FeatureQueryResult.h"
#include "FieldDescription.h"
#include "FieldDescriptionListModel.h"
#include "Geodatabase.h"
#include "GeodatabaseFeatureTable.h"
#include "GeometryTypes.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Point.h"
#include "QueryParameters.h"
#include "ServiceTypes.h"
#include "SpatialReference.h"
#include "TableDescription.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>

using namespace Esri::ArcGISRuntime;

CreateMobileGeodatabase::CreateMobileGeodatabase(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISTopographic, this))
{
  // The FeatureListModel is a helper class created specifically for this sample to display all features in the table view
  m_featureListModel = new FeatureListModel(this);
}

CreateMobileGeodatabase::~CreateMobileGeodatabase() = default;

void CreateMobileGeodatabase::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<CreateMobileGeodatabase>("Esri.Samples", 1, 0, "CreateMobileGeodatabaseSample");
}

MapQuickView* CreateMobileGeodatabase::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void CreateMobileGeodatabase::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);
  m_mapView->setViewpointAsync(Viewpoint(39.3238, -77.7332, 10'000));

  connect(m_mapView, &MapQuickView::mouseClicked, this, &CreateMobileGeodatabase::addFeature);

  emit mapViewChanged();
}

// Create a Geodatabase in an empty directory
void CreateMobileGeodatabase::createGeodatabase()
{
  m_gdbFilePath = QString{m_tempDir.path() + "/LocationHistory_%1.geodatabase"}.arg(QDateTime::currentSecsSinceEpoch() % 1000);
  emit gdbFilePathChanged();

  // We cannot overwrite an existing geodatabase
  if (QFile::exists(m_gdbFilePath))
    return;

  // Use static Geodatabase::createAsync with an empty file path
  Geodatabase::createAsync(m_gdbFilePath, this).then(this, [this](Geodatabase* geodatabase)
  {
    m_gdb = geodatabase;
    createTable();
  });
}

// Create a GeodatabaseFeatureTable from the new Geodatabase with a TableDescription
void CreateMobileGeodatabase::createTable()
{
  m_gdbOpen = true;
  emit gdbOpenChanged();

  // Create a TableDescription to define the GeodatabaseFeatureTable's attributes and fields
  TableDescription* tableDescription = new TableDescription("LocationHistory", SpatialReference::wgs84(), GeometryType::Point, this);
  tableDescription->setHasAttachments(false);
  tableDescription->setHasM(false);
  tableDescription->setHasZ(false);
  tableDescription->fieldDescriptions()->append(new FieldDescription("oid", FieldType::OID));
  tableDescription->fieldDescriptions()->append(new FieldDescription("collection_timestamp", FieldType::Date));

  m_gdb->createTableAsync(tableDescription, this).then(this, [this](GeodatabaseFeatureTable* gdbFeatureTableResult)
  {
    m_featureTable = gdbFeatureTableResult;

    FeatureLayer* featureLayer = new FeatureLayer(m_featureTable, this);
    m_map->operationalLayers()->append(featureLayer);
  });
}

// Close the Geodatabase so that it can be safely shared
void CreateMobileGeodatabase::closeGdb()
{
  if (!m_gdb)
    return;

  m_gdb->close();
  m_gdbOpen = false;

  m_map->operationalLayers()->clear();
  m_featureListModel->clear();

  m_featureCount = 0;

  emit gdbOpenChanged();
  emit featureCountChanged();
}

void CreateMobileGeodatabase::addFeature(QMouseEvent& mouseEvent)
{
  if (!m_featureTable)
    return;

  const Point mousePoint = m_mapView->screenToLocation(mouseEvent.position().x(), mouseEvent.position().y());
  QVariantMap attributes = {};
  attributes.insert("collection_timestamp", QDateTime::currentDateTime());
  Feature* feature = m_featureTable->createFeature(attributes, mousePoint, this);

  m_featureTable->addFeatureAsync(feature).then(this, [this, feature]()
  {
    m_featureListModel->addFeature(feature);
    emit featureListModelChanged();

    m_featureCount = static_cast<int>(m_featureTable->numberOfFeatures());
    emit featureCountChanged();
  });
}

void CreateMobileGeodatabase::deleteFeatures()
{
  QueryParameters params;
  params.setWhereClause("1=1");

  m_featureTable->queryFeaturesAsync(params).then(this, [this](FeatureQueryResult* rawQueryResult)
  {
    // Cast the FeatureQueryResult to a unique pointer to delete it when it goes out of scope
    auto queryResults = std::unique_ptr<FeatureQueryResult>(rawQueryResult);
    FeatureIterator resultIterator = queryResults->iterator();

    auto deleteFeaturesFuture = m_featureTable->deleteFeaturesAsync(resultIterator.features());
    Q_UNUSED(deleteFeaturesFuture)
    m_featureCount = 0;
    emit featureCountChanged();
  });
}

void CreateMobileGeodatabase::clearFeatures()
{
  if (m_featureTable->numberOfFeatures() > 0)
    deleteFeatures();

  m_featureListModel->clear();
}

FeatureListModel* CreateMobileGeodatabase::featureListModel() const
{
  return m_featureListModel;
}

QString CreateMobileGeodatabase::gdbFilePath() const
{
  return m_gdbFilePath;
}

int CreateMobileGeodatabase::featureCount() const
{
  return m_featureCount;
}

bool CreateMobileGeodatabase::gdbOpen() const
{
  return m_gdbOpen;
}

// [WriteFile Name=CreateMobileGeodatabase, Category=Features]
// [Legal]
// Copyright 2022 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef CREATEMOBILEGEODATABASE_H
#define CREATEMOBILEGEODATABASE_H

// sample headers
#include "FeatureListModel.h"

// Qt headers
#include <QMouseEvent>
#include <QObject>
#include <QTemporaryDir>

namespace Esri::ArcGISRuntime
{
class FeatureTable;
class Geodatabase;
class Map;
class MapQuickView;
}

Q_MOC_INCLUDE("MapQuickView.h")

class CreateMobileGeodatabase : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(FeatureListModel* featureListModel READ featureListModel NOTIFY featureListModelChanged)
  Q_PROPERTY(QString gdbFilePath READ gdbFilePath NOTIFY gdbFilePathChanged)
  Q_PROPERTY(bool gdbOpen READ gdbOpen NOTIFY gdbOpenChanged)
  Q_PROPERTY(int featureCount READ featureCount NOTIFY featureCountChanged)

public:
  explicit CreateMobileGeodatabase(QObject* parent = nullptr);
  ~CreateMobileGeodatabase();

  static void init();

  Q_INVOKABLE void createGeodatabase();
  Q_INVOKABLE void clearFeatures();
  Q_INVOKABLE void closeGdb();

signals:
  void mapViewChanged();
  void featureListModelChanged();
  void gdbFilePathChanged();
  void gdbOpenChanged();
  void featureCountChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  FeatureListModel* featureListModel() const;
  QString gdbFilePath() const;
  int featureCount() const;
  bool gdbOpen() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);
  void createTable();
  void addFeature(QMouseEvent& mouseEvent);
  void deleteFeatures();

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::FeatureTable* m_featureTable = nullptr;
  Esri::ArcGISRuntime::Geodatabase* m_gdb = nullptr;
  FeatureListModel* m_featureListModel = nullptr;
  QString m_gdbFilePath;
  bool m_gdbOpen = false;
  int m_featureCount = 0;
  QTemporaryDir m_tempDir;
};

#endif // CREATEMOBILEGEODATABASE_H

// [WriteFile Name=CreateMobileGeodatabase, Category=Features]
// [Legal]
// Copyright 2022 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import QtQuick.Layouts
import Qt.labs.platform
import Esri.Samples

Item {
    id: rootItem
    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set and keep the focus on MapView to enable keyboard navigation
            forceActiveFocus();
        }
    }

    CreateMobileGeodatabaseSample {
        id: model
        mapView: view
    }

    Rectangle {
        id: buttonListRectangle
        anchors {
            top: parent.top
            right: parent.right
            topMargin: 10
            rightMargin: 10
        }

        width: 250
        height: buttonColumn.height + 20
        color: "#ffffff"

        // Prevent mouse interaction from propagating to the MapView
        MouseArea {
            anchors.fill: parent
            onPressed: mouse => mouse.accepted = true;
            onWheel: wheel => wheel.accepted = true;
        }

        Column {
            id: buttonColumn
            anchors {
                top: parent.top
                left: parent.left
                right: parent.right
                topMargin: 10
                leftMargin: 10
                rightMargin: 10
            }
            height: children.height
            spacing: 5

            onHeightChanged: {
                buttonListRectangle.height = height + 20
            }

            Button {
                id: createGdbButton
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: qsTr("Create new .geodatabase")
                enabled: !model.gdbOpen
                onClicked: {
                    model.createGeodatabase();
                }
            }

            Button {
                id: viewGdbTableButton
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: qsTr("View feature table")
                enabled: model.gdbOpen
                onClicked: {
                    featureTableDisplay.visible = true;
                    buttonListRectangle.visible = false;
                }
            }
            Button {
                id: clearFeaturesButton
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: qsTr("Clear features")
                enabled: model.gdbOpen
                onClicked: {
                    model.clearFeatures();
                }
            }


            Button {
                id: closeGdbButton
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: qsTr("Close .geodatabase")
                enabled: model.gdbOpen
                onClicked: {
                    model.closeGdb();
                    gdbClosedNoticeRectangle.visible = true;
                    buttonListRectangle.visible = false;
                }
            }

            Text {
                id: fileNameText
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: model.gdbFilePath ? "Created new geodatabase:\n" + model.gdbFilePath.split("/").pop() : "Geodatabase path not found"
                font.pixelSize: 12
                wrapMode: Text.WrapAnywhere
                visible: model.gdbOpen
            }

            Text {
                id: featureCountText
                anchors {
                    left: parent.left
                    right: parent.right
                    leftMargin: 0
                    rightMargin: 0
                }
                text: "Number of features: " + model.featureCount + (model.featureCount === 0 ? "\n(Click or tap on the map to add new features)" : "")
                font.pixelSize: 12
                wrapMode: Text.WordWrap
                visible: model.gdbOpen
            }
        }
    }

    Rectangle {
        id: gdbClosedNoticeRectangle
        anchors.centerIn: parent
        width: parent.width * 0.75
        height: gdbInfoColumn.height + 20
        color: "white"
        border.color: "black"
        clip: true
        visible: false

        // Prevent mouse interaction from propagating to the MapView
        MouseArea {
            anchors.fill: parent
            onPressed: mouse => mouse.accepted = true;
            onWheel: wheel => wheel.accepted = true;
        }

        Column {
            id: gdbInfoColumn
            anchors {
                centerIn: parent
                margins: 10
            }
            spacing: 10
            width: parent.width - 20
            height: children.height

            Text {
                id: gdbNameText
                width: parent.width
                text: "Closed and saved geodatabase to the temporary path:"
                wrapMode: Text.WordWrap
            }
            TextEdit {
                id: gdbPathText
                width: parent.width
                readOnly: true
                activeFocusOnPress: false
                selectByMouse: true
                text: model.gdbFilePath
                wrapMode: Text.WrapAnywhere
            }
            Button {
                id: gdbInfoClose
                anchors.horizontalCenter: parent.horizontalCenter
                text: "Ok"
                onClicked: {
                    gdbClosedNoticeRectangle.visible = false;
                    buttonListRectangle.visible = true;
                }
            }
        }
    }

    Rectangle {
        id: featureTableDisplay
        anchors {
            verticalCenter: parent.verticalCenter
            horizontalCenter: parent.horizontalCenter
        }
        width: parent.width - parent.width * 0.2
        height: parent.height - parent.height * 0.3
        color: "#80808080"
        visible: false

        // Prevent mouse interaction from propagating to the MapView
        MouseArea {
            anchors.fill: parent
            onPressed: mouse => mouse.accepted = true;
            onWheel: wheel => wheel.accepted = true;
        }

        ListView {
            id: tableView
            anchors {
                fill: parent
                margins: 10
            }
            ScrollBar.vertical: ScrollBar {
                active: true
            }
            clip: true

            header: Row {
                height: 40
                width: tableView.width
                Rectangle {
                    color: "grey"
                    border.color: "black"
                    width: parent.width * 0.2
                    height: parent.height
                    Text {
                        anchors.centerIn: parent
                        text: "Object ID"
                        color: "white"
                        font.bold: true

                    }
                }
                Rectangle {
                    color: "grey"
                    border.color: "black"
                    width: parent.width * 0.8
                    height: parent.height
                    Text {
                        anchors.centerIn: parent
                        text: "Timestamp"
                        color: "white"
                        font.bold: true
                    }
                }
            }

            model: model.featureListModel
            delegate: Row {
                height: 40
                width: tableView.width
                Rectangle {
                    color: "white"
                    border.color: "black"
                    width: parent.width * 0.2
                    height: parent.height
                    Text {
                        anchors.centerIn: parent
                        text: featureOidRole

                    }
                }
                Rectangle {
                    color: "white"
                    border.color: "black"
                    width: parent.width * 0.8
                    height: parent.height
                    Text {
                        anchors.centerIn: parent
                        text: featureTimestampRole
                    }
                }
            }
        }
    }

    Rectangle {
        id: closeTableButtonRectangle
        anchors {
            top: parent.top
            right: parent.right
            topMargin: 10
            rightMargin: 10
        }
        width: closeTableButton.width + 10
        height: closeTableButton.height + 10
        color: "#ffffff"
        visible: featureTableDisplay.visible

        // Prevent mouse interaction from propagating to the MapView
        MouseArea {
            anchors.fill: parent
            onPressed: mouse => mouse.accepted = true;
            onWheel: wheel => wheel.accepted = true;
        }

        Button {
            id: closeTableButton
            anchors.centerIn: parent

            text: "Close table view"

            onClicked: {
                featureTableDisplay.visible = false;
                buttonListRectangle.visible = true;
            }
        }
    }
}

// [WriteFile Name=FeatureListModel, Category=Features]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "FeatureListModel.h"

// ArcGIS Maps SDK headers
#include "AttributeListModel.h"
#include "Feature.h"

using namespace Esri::ArcGISRuntime;

FeatureListModel::FeatureListModel(QObject* parent /* = nullptr */) :
  QAbstractListModel(parent)
{
}

void FeatureListModel::addFeature(Feature* feature)
{
  beginInsertRows(QModelIndex(), rowCount(), rowCount());
  m_features << feature;
  endInsertRows();
}

int FeatureListModel::rowCount(const QModelIndex& parent) const
{
  Q_UNUSED(parent);
  return m_features.count();
}

QVariant FeatureListModel::data(const QModelIndex& index, int role) const
{
  if (index.row() < 0 || index.row() >= m_features.count())
    return QVariant();

  const Feature* feature = m_features[index.row()];

  if (role == FeatureOidRole)
    return feature->attributes()->attributeValue("oid");
  else if (role == FeatureTimestampRole)
    return feature->attributes()->attributeValue("collection_timestamp");

  return QVariant();
}

QHash<int, QByteArray> FeatureListModel::roleNames() const
{
  QHash<int, QByteArray> roles;
  roles[FeatureOidRole] = "featureOidRole";
  roles[FeatureTimestampRole] = "featureTimestampRole";
  return roles;
}

void FeatureListModel::clear()
{
  beginResetModel();
  m_features.clear();
  endResetModel();
}

// [Legal]
// Copyright 2024 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef FEATURELISTMODEL_H
#define FEATURELISTMODEL_H

// Qt headers
#include <QAbstractListModel>

namespace Esri::ArcGISRuntime
{
class Feature;
}

class FeatureListModel : public QAbstractListModel
{
  Q_OBJECT

public:
  enum SampleFeatureRoles
  {
    FeatureOidRole,
    FeatureTimestampRole
  };

  explicit FeatureListModel(QObject* parent = nullptr);
  ~FeatureListModel() override = default;

  void addFeature(Esri::ArcGISRuntime::Feature* feature);
  int rowCount(const QModelIndex& parent = QModelIndex()) const override;
  QVariant data(const QModelIndex& index, int role = Qt::DisplayRole) const override;
  void clear();
  int size() const { return m_features.size(); }

protected:
  QHash<int, QByteArray> roleNames() const override;

private:
  QList<Esri::ArcGISRuntime::Feature*> m_features;
};

#endif // FEATURELISTMODEL_H

// [Legal]
// Copyright 2022 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "CreateMobileGeodatabase.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("CreateMobileGeodatabase"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  CreateMobileGeodatabase::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  // Set the source
  engine.load(QUrl("qrc:/Samples/Features/CreateMobileGeodatabase/main.qml"));

  return app.exec();
}

// Copyright 2022 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    CreateMobileGeodatabase {
        anchors.fill: parent
    }
}
