Feature layer (dictionary renderer)

// [WriteFile Name=FeatureLayerDictionaryRenderer, Category=Features]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "FeatureLayerDictionaryRenderer.h"

// ArcGIS Maps SDK headers
#include "DictionaryRenderer.h"
#include "DictionarySymbolStyle.h"
#include "Envelope.h"
#include "FeatureLayer.h"
#include "Geodatabase.h"
#include "GeodatabaseFeatureTable.h"
#include "GeometryEngine.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"

// Qt headers
#include <QFuture>
#include <QStandardPaths>
#include <QtCore/qglobal.h>

using namespace Esri::ArcGISRuntime;

// helper method to get cross platform data path
namespace
{
  QString defaultDataPath()
  {
    QString dataPath;

  #ifdef Q_OS_IOS
    dataPath = QStandardPaths::writableLocation(QStandardPaths::DocumentsLocation);
  #else
    dataPath = QStandardPaths::writableLocation(QStandardPaths::HomeLocation);
  #endif

    return dataPath;
  }
} // namespace

FeatureLayerDictionaryRenderer::FeatureLayerDictionaryRenderer(QQuickItem* parent) :
  QQuickItem(parent),
  m_dataPath(defaultDataPath() + "/ArcGIS/Runtime/Data")
{
}

FeatureLayerDictionaryRenderer::~FeatureLayerDictionaryRenderer() = default;

void FeatureLayerDictionaryRenderer::init()
{
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<FeatureLayerDictionaryRenderer>("Esri.Samples", 1, 0, "FeatureLayerDictionaryRendererSample");
}

void FeatureLayerDictionaryRenderer::componentComplete()
{
  QQuickItem::componentComplete();

  m_mapView = findChild<MapQuickView*>("mapView");
  // Create a map using the topo basemap
  Map* map = new Map(BasemapStyle::ArcGISTopographic, this);
  // set map on the map view
  m_mapView->setMap(map);

  m_geodatabase = new Geodatabase(m_dataPath + "/geodatabase/militaryoverlay.geodatabase", this);

  connect(m_geodatabase, &Geodatabase::loadStatusChanged, this, [this](LoadStatus gdbLoadStatus)
  {
    if (gdbLoadStatus == LoadStatus::Loaded)
    {
      /**
             * If the field names in your data don't match the contents of DictionarySymbolStyle::symbologyFieldNames(),
             * you must add key-value pairs to a QMap<QString, QString> and include this QMap when calling the
             * DictionaryRenderer constructor. The keys and values are like this:
             *
             *   "dictionaryFieldName1": "myFieldName1"
             *   "dictionaryFieldName2": "myFieldName2"
             *
             * The same principle applies to DictionarySymbolStyle::textFieldNames() for text attributes that appear
             * as part of military symbols.
             *
             * The following commented-out code demonstrates one way to do it, in a scenario where the dictionary
             * expects the field name "identity" but the database table contains the field "affiliation" instead,
             * and where the dictionary expects the field name "uniquedesignation" but the database table contains
             * the field "uniqueId" instead.
             */
      //            QMap<QString, QString> symbologyFieldOverrides;
      //            QMap<QString, QString> textFieldOverrides;
      //            symbologyFieldOverrides["identity"] = "affiliation";
      //            textFieldOverrides["uniquedesignation"] = "uniqueId";

      //! [Create Dictionary Symbol Style Cpp]
      const QString specType = QStringLiteral("mil2525d");
      const QString stylePath = m_dataPath + "/styles/arcade_style/mil2525d.stylx";
      DictionarySymbolStyle* dictionarySymbolStyle = DictionarySymbolStyle::createFromFile(stylePath, this);
      //! [Create Dictionary Symbol Style Cpp]

      Q_UNUSED(specType)

      const auto tables = m_geodatabase->geodatabaseFeatureTables();
      for (GeodatabaseFeatureTable* table : tables)
      {
        //! [Apply Dictionary Renderer Feature Layer Cpp]
        // Create a layer and set the feature table
        FeatureLayer* layer = new FeatureLayer(table, this);

        // Create a dictionary renderer and apply to the layer
        DictionaryRenderer* renderer = new DictionaryRenderer(dictionarySymbolStyle, this);
        layer->setRenderer(renderer);
        //! [Apply Dictionary Renderer Feature Layer Cpp]

        // Check to see if all layers have loaded
        connect(layer, &FeatureLayer::loadStatusChanged, this, [this](LoadStatus layerLoadStatus)
        {
          if (layerLoadStatus == LoadStatus::Loaded)
          {
            m_loadedLayerCount++;

            if (m_loadedLayerCount == m_geodatabase->geodatabaseFeatureTables().length())
            {
              /**
               * If we get here, all the layers loaded. Union the extents and set
               * the viewpoint.
               */
              LayerListModel* layers = m_mapView->map()->operationalLayers();
              if (layers->size() > 0)
              {
                Envelope bbox = layers->at(0)->fullExtent();
                for (int j = 1; j < layers->size(); j++)
                {
                  bbox = GeometryEngine::unionOf(bbox, layers->at(j)->fullExtent());
                }
                m_mapView->setViewpointGeometryAsync(bbox, 100);
              }

              emit allLayersLoaded();
            }
          }
        }, Qt::DirectConnection);

        /**
                 * Add the layer to the map. Inserting at index 0 puts the layer below previously added
                 * layers.
                 */
        m_mapView->map()->operationalLayers()->insert(0, layer);
      }
    }
  });
  m_geodatabase->load();
}

// [WriteFile Name=FeatureLayerDictionaryRenderer, Category=Features]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef FEATURELAYERDICTIONARYRENDERER_H
#define FEATURELAYERDICTIONARYRENDERER_H

// Qt headers
#include <QQuickItem>

namespace Esri::ArcGISRuntime
{
  class Geodatabase;
  class MapQuickView;
}

class FeatureLayerDictionaryRenderer : public QQuickItem
{
  Q_OBJECT

public:
  explicit FeatureLayerDictionaryRenderer(QQuickItem* parent = nullptr);
  ~FeatureLayerDictionaryRenderer() override;

  void componentComplete() override;
  static void init();

signals:
  void allLayersLoaded();

private:
  QString m_dataPath;
  int m_loadedLayerCount = 0;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::Geodatabase* m_geodatabase = nullptr;
};

#endif // FEATURELAYERDICTIONARYRENDERER_H

// [WriteFile Name=FeatureLayerDictionaryRenderer, Category=Features]
// [Legal]
// Copyright 2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

FeatureLayerDictionaryRendererSample {
    id: featureLayerDictionaryRendererSample
    width: 800
    height: 600

    // Create MapView here, and create its Map in C++ code
    MapView {
        objectName: "mapView"
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    ProgressBar {
        id: progressBar_loading
        anchors {
            horizontalCenter: parent.horizontalCenter
            bottom: parent.bottom
            margins: 5
        }
        indeterminate: true
    }

    onAllLayersLoaded: {
        progressBar_loading.visible = false;
    }
}

// [Legal]
// Copyright 2015-2016 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "FeatureLayerDictionaryRenderer.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("FeatureLayerDictionaryRenderer"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }
  // Initialize the sample
  FeatureLayerDictionaryRenderer::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

 #if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
 #endif

  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/Features/FeatureLayerDictionaryRenderer/FeatureLayerDictionaryRenderer.qml"));

  view.show();

  return app.exec();
}
