Geocode offline

// Copyright 2023 Esri
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//   https://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import ArcGIS
import SwiftUI

struct GeocodeOfflineView: View {
    /// The view model for the sample.
    @StateObject private var model = Model()

    /// The viewpoint of the map view, initially centered on San Diego, CA, USA.
    @State private var viewpoint = Viewpoint(
        center: Point(x: -13_042_250, y: 3_857_970, spatialReference: .webMercator),
        scale: 2e4
    )

    /// The text in the search bar.
    @State private var searchText = ""

    /// The search text that has been submitted.
    @State private var submittedSearchText: String?

    /// A Boolean value indicating whether the "No results found." alert is showing.
    @State private var resultAlertIsShowing = false

    /// A pre-populated list of example addresses.
    private let exampleAddresses = [
        "910 N Harbor Dr, San Diego, CA 92101",
        "2920 Zoo Dr, San Diego, CA 92101",
        "111 W Harbor Dr, San Diego, CA 92101",
        "868 4th Ave, San Diego, CA 92101",
        "750 A St, San Diego, CA 92101"
    ]

    var body: some View {
        GeocodeMapView(model: model, viewpoint: $viewpoint)
            .searchable(text: $searchText, prompt: "Type in an address")
            .autocorrectionDisabled()
            .onSubmit(of: .search) {
                submittedSearchText = searchText
            }
            .toolbar {
                ToolbarItem(placement: .primaryAction) {
                    Menu {
                        ForEach(exampleAddresses, id: \.self) { address in
                            Button(address) {
                                searchText = address
                                submittedSearchText = address
                            }
                        }
                    } label: {
                        Image(systemName: "chevron.down.circle")
                    }
                }
            }
            .onChange(of: searchText) {
                // Reset the marker when the search text changes.
                model.resetGraphics()
            }
            .task(id: submittedSearchText) {
                // Geocode the text when a search is submitted.
                if let submittedSearchText {
                    if let resultExtent = await model.geocodeSearch(address: submittedSearchText) {
                        // If found, zoom to the extent of the result's location.
                        viewpoint = Viewpoint(boundingGeometry: resultExtent)
                    } else {
                        // If no result was found, inform the user with an alert.
                        resultAlertIsShowing = true
                    }
                }

                submittedSearchText = nil
            }
            .alert("No results found.", isPresented: $resultAlertIsShowing, actions: {})
    }
}

private extension GeocodeOfflineView {
    /// The map view for the sample.
    struct GeocodeMapView: View {
        /// The view model for the sample.
        @ObservedObject var model: Model

        /// The action that ends the current search interaction.
        @Environment(\.dismissSearch) private var dismissSearch

        /// The current viewpoint of the map view.
        @Binding var viewpoint: Viewpoint

        /// The point on the map where the user tapped.
        @State private var tapLocation: Point?

        var body: some View {
            MapView(map: model.map, viewpoint: viewpoint, graphicsOverlays: [model.graphicsOverlay])
                .onViewpointChanged(kind: .centerAndScale) { viewpoint = $0 }
                .callout(placement: $model.calloutPlacement) { _ in
                    Text(model.calloutText)
                        .font(.callout)
                        .padding(8)
                }
                .onSingleTapGesture { _, mapPoint in
                    tapLocation = mapPoint
                }
                .onLongPressAndDragGesture { mapPoint in
                    model.calloutIsOffset = true
                    tapLocation = mapPoint
                } onEnded: {
                    // Reset the callout's offset when the gesture ends.
                    if let tapLocation {
                        model.calloutIsOffset = false
                        model.updateCalloutPlacement(to: tapLocation)
                    }
                    tapLocation = nil
                }
                .task(id: tapLocation) {
                    // Reverse geocode the tap location when it changes.
                    if let tapLocation {
                        dismissSearch()
                        await model.reverseGeocode(mapPoint: tapLocation)
                    }
                }
        }
    }
}

private extension MapView {
    /// Sets a closure to perform when the map view recognizes a long press and drag gesture.
    /// - Parameters:
    ///   - action: The closure to perform when the gesture is recognized.
    ///   - onEnded: The closure to perform when the gesture ends.
    /// - Returns: A new `View` object.
    func onLongPressAndDragGesture(
        perform action: @escaping (Point) -> Void,
        onEnded: @escaping () -> Void
    ) -> some View {
        self
            .onLongPressGesture { _, mapPoint in
                action(mapPoint)
            }
            .gesture(
                LongPressGesture()
                    .simultaneously(with: DragGesture())
                    .onEnded { _ in
                        onEnded()
                    }
            )
    }
}

// Copyright 2023 Esri
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
//
//   https://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import ArcGIS
import Combine
import UIKit

extension GeocodeOfflineView {
    /// The view model for the sample.
    @MainActor
    class Model: ObservableObject {
        // MARK: Properties

        /// A map with a tiled layer of the streets in San Diego, CA, USA.
        let map = {
            // Create a tiled layer using the local tile package.
            let tileCache = TileCache(fileURL: .streetMap)
            let tiledLayer = ArcGISTiledLayer(tileCache: tileCache)

            // Create a map with the tiled layer as base layer.
            return Map(basemap: Basemap(baseLayer: tiledLayer))
        }()

        /// The graphics overlay for the marker graphic.
        let graphicsOverlay = GraphicsOverlay()

        /// The red map marker graphic used to indicate a given location on the map.
        private let markerGraphic = {
            // Create a symbol using the image from the project assets.
            let markerImage = UIImage.redMarker
            let markerSymbol = PictureMarkerSymbol(image: markerImage)

            // Change the symbol's offsets, so it aligns properly to a given point.
            markerSymbol.leaderOffsetY = markerImage.size.height / 2
            markerSymbol.offsetY = markerImage.size.height / 2

            // Create a graphic with the symbol.
            return Graphic(symbol: markerSymbol)
        }()

        /// The locator task used to preform the geocode operations, loaded from a local file.
        private let locatorTask = LocatorTask(name: "SanDiego_StreetAddress", bundle: .main)

        /// The placement of the callout on the map.
        @Published var calloutPlacement: CalloutPlacement?

        /// A Boolean value indicating whether the callout placement is offset, e.g. when the map magnifier is showing.
        @Published var calloutIsOffset = false

        /// The text shown in the callout.
        @Published private(set) var calloutText: String = ""

        init() {
            graphicsOverlay.addGraphic(markerGraphic)
        }

        // MARK: Methods

        /// Geocodes a given address and adds a marker with the corresponding address at the result's location.
        /// - Parameter address: The given text address to geocode.
        /// - Returns: The extent of the result's display location.
        func geocodeSearch(address: String) async -> Envelope? {
            guard let locatorTask else { return nil }

            // Create geocode parameters.
            let geocodeParameters = GeocodeParameters()
            geocodeParameters.addResultAttributeName("Match_addr")
            geocodeParameters.minScore = 75

            // Perform geocode using the locator task with the text address and parameters.
            let geocodeResults = try? await locatorTask.geocode(
                forSearchText: address,
                using: geocodeParameters
            )

            if let result = geocodeResults?.first,
               let displayLocation = result.displayLocation {
                // If a result is found, place a marker at the result's location.
                let resultText = result.attributes["Match_addr"] as? String ?? ""
                updateMarker(to: displayLocation, withText: resultText)

                return displayLocation.extent
            }

            return nil
        }

        /// Reverse geocodes a given location and adds a marker with the corresponding address at the result's location.
        /// - Parameter mapPoint: The point on the map to reverse geocode.
        func reverseGeocode(mapPoint: Point) async {
            guard let locatorTask else { return }

            //  Normalized the map point.
            guard let normalizedPoint = GeometryEngine.normalizeCentralMeridian(
                of: mapPoint
            ) as? Point else { return }

            // Create reverse geocode parameters.
            let reverseGeocodeParameters = ReverseGeocodeParameters()
            reverseGeocodeParameters.addResultAttributeName("*")
            reverseGeocodeParameters.maxResults = 1

            // Perform reverse geocode using the locator task with the point and parameters.
            let geocodeResults = try? await locatorTask.reverseGeocode(
                forLocation: normalizedPoint,
                parameters: reverseGeocodeParameters
            )

            let resultText: String
            if let result = geocodeResults?.first {
                // If a result is found, extract the address from the attributes.
                let cityString = result.attributes["City"] as? String ?? ""
                let streetString = result.attributes["StAddr"] as? String ?? ""
                let stateString = result.attributes["Region"] as? String ?? ""

                resultText = "\(streetString), \(cityString), \(stateString)"
            } else {
                resultText = "No address found"
            }

            // Create a marker at the location with the text.
            updateMarker(to: normalizedPoint, withText: resultText)
        }

        /// Resets the callout and marker graphic, removing them from the map view.
        func resetGraphics() {
            calloutPlacement = nil
            markerGraphic.geometry = nil
        }

        /// Updates the callout placement to a given location.
        /// - Parameter mapPoint: The point on the map to update the callout placement to.
        func updateCalloutPlacement(to mapPoint: Point) {
            if calloutIsOffset {
                // Offset the callout to the top of the magnifier when it is showing.
                let magnifierOffset = CGPoint(x: .zero, y: -140)
                calloutPlacement = .location(mapPoint, offset: magnifierOffset)
            } else {
                calloutPlacement = .geoElement(markerGraphic, tapLocation: mapPoint)
            }
        }

        /// Updates the map marker and its associated callout to a given location.
        /// - Parameters:
        ///   - mapPoint: The point on the map to move the marker graphic to.
        ///   - text: The text to show in the marker's callout.
        private func updateMarker(to mapPoint: Point, withText text: String) {
            markerGraphic.geometry = mapPoint
            calloutText = text
            updateCalloutPlacement(to: mapPoint)
        }
    }
}

private extension URL {
    /// A URL to the local tile package of the streets in San Diego, CA, USA.
    static var streetMap: Self {
        Bundle.main.url(forResource: "streetmap_SD", withExtension: "tpkx")!
    }
}
