Display device location with NMEA data sources

// [WriteFile Name=DisplayDeviceLocationWithNmeaDataSources, Category=Maps]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "DisplayDeviceLocationWithNmeaDataSources.h"

// ArcGIS Maps SDK headers
#include "LocationDisplay.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "MapViewTypes.h"
#include "NmeaLocationDataSource.h"
#include "Point.h"
#include "SpatialReference.h"

// Qt headers
#include <QFile>
#include <QFuture>
#include <QTimer>

using namespace Esri::ArcGISRuntime;

DisplayDeviceLocationWithNmeaDataSources::DisplayDeviceLocationWithNmeaDataSources(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISNavigation, this)),
  m_timer(new QTimer(this))
{
}

DisplayDeviceLocationWithNmeaDataSources::~DisplayDeviceLocationWithNmeaDataSources() = default;

void DisplayDeviceLocationWithNmeaDataSources::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<DisplayDeviceLocationWithNmeaDataSources>("Esri.Samples", 1, 0, "DisplayDeviceLocationWithNmeaDataSourcesSample");
}

MapQuickView* DisplayDeviceLocationWithNmeaDataSources::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void DisplayDeviceLocationWithNmeaDataSources::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  m_mapView->setViewpointCenterAsync(Point(-117.191, 34.0306, SpatialReference::wgs84()), 100'000);

  // Create a new NMEA location data source
  m_nmeaLocationDataSource = new NmeaLocationDataSource(SpatialReference::wgs84(), this);
  m_mapView->locationDisplay()->setDataSource(m_nmeaLocationDataSource);
  m_mapView->locationDisplay()->setAutoPanMode(LocationDisplayAutoPanMode::Recenter);

  emit mapViewChanged();
}

void DisplayDeviceLocationWithNmeaDataSources::start()
{
  // Enable receiving NMEA location data from external device
  m_nmeaLocationDataSource->start();

  // Display the user's location
  m_mapView->locationDisplay()->start();

  // Load simulated NMEA sentences for sample
  if (m_mockNmeaSentences.isEmpty())
  {
    const QString filePath = ":/Samples/Maps/DisplayDeviceLocationWithNmeaDataSources/redlands.nmea";
    if(!loadMockDataFile(filePath))
    {
      qDebug() << "Unable to load file at path:" << filePath;
      m_nmeaSimulationActive = false;
      emit nmeaSimulationActiveChanged();

      return;
    }
  }

  // Simulate pushing data to the NMEA location data source
  connect(m_timer, &QTimer::timeout, this, [this]()
  {
    const QByteArray line = m_mockNmeaSentences.at(m_mockDataIterator);

    // In a non-simulated scenario, incoming NMEA sentences from a serial port or bluetooth device would be pushed to the location data source in real time
    // NMEA sentences can be pushed individually or in multiple lines separated by line breaks
    // Sentences pass information such as direction, velocity, and location and are grouped together to provide detailed information about a user's position
    m_nmeaLocationDataSource->pushData(line);

    ++m_mockDataIterator;
    if (m_mockDataIterator >= m_mockNmeaSentences.size())
      m_mockDataIterator = 0;
  });

  m_mockDataIterator = 0;
  m_timer->start(1000);
}

void DisplayDeviceLocationWithNmeaDataSources::reset()
{
  // Disable simulated data
  m_timer->stop();
  disconnect(m_timer, &QTimer::timeout, nullptr, nullptr);

  // Stop displaying user's location
  m_mapView->locationDisplay()->stop();

  // Stop receiving location data
  m_nmeaLocationDataSource->stop();
}

bool DisplayDeviceLocationWithNmeaDataSources::loadMockDataFile(const QString& filePath)
{

  // Load simulated NMEA sentences to display for sample
  QFile mockDataFile(filePath);

  if(!mockDataFile.exists())
    return false;

  mockDataFile.open(QIODevice::ReadOnly);

  while (!mockDataFile.atEnd()) {
    QByteArray line = mockDataFile.readLine();

    // In this simulated data stream, blocks of NMEA sentences start with $GPGGA (which provides the device's position)
    if (line.startsWith("$GPGGA"))
      m_mockNmeaSentences.append(line);

    // Additional sentences that provide information such as direction and velocity follow and are separated by line breaks
    else
      m_mockNmeaSentences.last() += line;
  }

  mockDataFile.close();
  return true;
}

// [WriteFile Name=DisplayDeviceLocationWithNmeaDataSources, Category=Maps]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef DISPLAYDEVICELOCATIONWITHNMEADATASOURCES_H
#define DISPLAYDEVICELOCATIONWITHNMEADATASOURCES_H

// Qt headers
#include <QByteArray>
#include <QFile>
#include <QObject>
#include <QTimer>

namespace Esri::ArcGISRuntime
{
class Map;
class MapQuickView;
class NmeaLocationDataSource;
}

Q_MOC_INCLUDE("MapQuickView.h")

class DisplayDeviceLocationWithNmeaDataSources : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(bool nmeaSimulationActive MEMBER m_nmeaSimulationActive NOTIFY nmeaSimulationActiveChanged)

public:
  explicit DisplayDeviceLocationWithNmeaDataSources(QObject* parent = nullptr);
  ~DisplayDeviceLocationWithNmeaDataSources();

  static void init();

  Q_INVOKABLE void start();
  Q_INVOKABLE void reset();

signals:
  void mapViewChanged();
  void nmeaSimulationActiveChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);
  bool loadMockDataFile(const QString& filePath);

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::NmeaLocationDataSource* m_nmeaLocationDataSource = nullptr;
  QList<QByteArray> m_mockNmeaSentences;
  int m_mockDataIterator;
  QTimer* m_timer = nullptr;
  bool m_nmeaSimulationActive = false;
};

#endif // DISPLAYDEVICELOCATIONWITHNMEADATASOURCES_H

// [WriteFile Name=DisplayDeviceLocationWithNmeaDataSources, Category=Maps]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    DisplayDeviceLocationWithNmeaDataSourcesSample {
        id: model
        mapView: view
    }

    Button {
        id: button
        anchors {
            horizontalCenter: parent.horizontalCenter
            bottom: parent.bottom
            margins: 25
        }
        width: 200
        text: model.nmeaSimulationActive ? "RESET" : "START"
        onClicked: {
            model.nmeaSimulationActive = !model.nmeaSimulationActive;
            if (model.nmeaSimulationActive)
                model.start();
            else
                model.reset();
        }
    }
}

// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "DisplayDeviceLocationWithNmeaDataSources.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("DisplayDeviceLocationWithNmeaDataSources"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  DisplayDeviceLocationWithNmeaDataSources::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  // Set the source
  engine.load(QUrl("qrc:/Samples/Maps/DisplayDeviceLocationWithNmeaDataSources/main.qml"));

  return app.exec();
}

// Copyright 2021 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    DisplayDeviceLocationWithNmeaDataSources {
        anchors.fill: parent
    }
}
