Show popup

// [WriteFile Name=ShowPopup, Category=DisplayInformation]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "ShowPopup.h"

// ArcGIS Maps SDK headers
#include "Error.h"
#include "Feature.h"
#include "FeatureLayer.h"
#include "IdentifyLayerResult.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Popup.h"

// Qt headers
#include <QUuid>

using namespace Esri::ArcGISRuntime;

ShowPopup::ShowPopup(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(QUrl("https://runtime.maps.arcgis.com/home/webmap/viewer.html?webmap=e4c6eb667e6c43b896691f10cc2f1580"), this))
{
}

ShowPopup::~ShowPopup() = default;

void ShowPopup::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<ShowPopup>("Esri.Samples", 1, 0, "ShowPopupSample");
}

MapQuickView* ShowPopup::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void ShowPopup::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  // once map is set, connect to MapQuickView mouse clicked signal
  connect(m_mapView, &MapQuickView::mouseClicked, this, &ShowPopup::onMouseClicked);

  emit mapViewChanged();
}

void ShowPopup::onIdentifyLayerCompleted(const QUuid&, IdentifyLayerResult* rawIdentifyResult)
{
  emit taskRunningChanged();
  auto identifyResult = std::unique_ptr<IdentifyLayerResult>(rawIdentifyResult);

  // Invalid identify result
  if (!identifyResult)
    return;

  if (!identifyResult->error().isEmpty())
  {
    qDebug() << "Identify error occurred: " << identifyResult->error().message();
    return;
  }

  m_featureLayer->clearSelection();
  if (!identifyResult->popups().isEmpty())
  {
    GeoElement* geoElement = identifyResult->geoElements().first();
    Feature* feature = static_cast<Feature*>(geoElement);
    m_featureLayer->selectFeature(feature);

    m_popup = new Popup(geoElement, this);
    emit popupChanged();
  }
}

void ShowPopup::onMouseClicked(QMouseEvent& mouseEvent)
{
  if (m_map->loadStatus() != LoadStatus::Loaded)
    return;

  Layer* layer = m_map->operationalLayers()->at(0);
  if (layer->layerType() == LayerType::FeatureLayer)
  {
    m_featureLayer = static_cast<FeatureLayer*>(layer);
  }

  constexpr double tolerance = 12;
  constexpr bool returnPopupsOnly = false;
  constexpr int maximumResults = 10;

  m_future = m_mapView->identifyLayerAsync(m_featureLayer, mouseEvent.position(), tolerance, returnPopupsOnly, maximumResults);
  m_future.then(this, [this](IdentifyLayerResult* result)
  {
    onIdentifyLayerCompleted(QUuid(),result);
  });

  if (!m_future.isValid())
    qWarning() << "Future not valid.";

  emit taskRunningChanged();
}

bool ShowPopup::taskRunning() const
{
  return m_future.isRunning();
}

void ShowPopup::clearSelection() const
{
  m_featureLayer->clearSelection();
}

// [WriteFile Name=ShowPopup, Category=DisplayInformation]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef SHOWPOPUP_H
#define SHOWPOPUP_H

// Qt headers
#include <QFuture>
#include <QMouseEvent>
#include <QObject>
#include <QQmlListProperty>
#include <QUuid>

namespace Esri::ArcGISRuntime
{
class FeatureLayer;
class GeoElement;
class IdentifyLayerResult;
class Map;
class MapQuickView;
class Popup;
}

Q_MOC_INCLUDE("MapQuickView.h")
Q_MOC_INCLUDE("Popup.h")

class ShowPopup : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(Esri::ArcGISRuntime::Popup* popup MEMBER m_popup NOTIFY popupChanged)
  Q_PROPERTY(bool taskRunning READ taskRunning NOTIFY taskRunningChanged)

public:
  explicit ShowPopup(QObject* parent = nullptr);
  ~ShowPopup();

  static void init();

  Q_INVOKABLE void clearSelection() const;

signals:
  void mapViewChanged();
  void popupChanged();
  void taskRunningChanged();

private slots:
  void onMouseClicked(QMouseEvent& mouseEvent);
  void onIdentifyLayerCompleted(const QUuid&, Esri::ArcGISRuntime::IdentifyLayerResult* rawIdentifyResult);

private:
  bool taskRunning() const;
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::Popup* m_popup = nullptr;
  Esri::ArcGISRuntime::FeatureLayer* m_featureLayer = nullptr;

  QFuture<Esri::ArcGISRuntime::IdentifyLayerResult*> m_future;
};

#endif // SHOWPOPUP_H

// [WriteFile Name=ShowPopup, Category=DisplayInformation]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples
import Esri.ArcGISRuntime.Toolkit

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    PopupView {
        id: popupView
        anchors {
            top: parent.top
            bottom: parent.bottom
            right: parent.right
        }
        popup: model.popup

        visible: false

        onVisibleChanged: {
            if (!visible)
                model.clearSelection();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    ShowPopupSample {
        id: model
        mapView: view

        onPopupChanged: popupView.visible = true
    }

    BusyIndicator {
        anchors.centerIn: parent
        running: model.taskRunning
    }
}

// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "ShowPopup.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Other headers
#include "Esri/ArcGISRuntime/Toolkit/register.h"

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("ShowPopup"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  ShowPopup::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  Esri::ArcGISRuntime::Toolkit::registerComponents(engine);

  // Set the source
  engine.load(QUrl("qrc:/Samples/DisplayInformation/ShowPopup/main.qml"));

  return app.exec();
}

// Copyright 2020 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    id: appWindow
    visible: true
    width: 800
    height: 600

    ShowPopup {
        anchors.fill: parent
    }
}
