Realistic lighting and shadows

// [WriteFile Name=RealisticLightingAndShadows, Category=Scenes]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "RealisticLightingAndShadows.h"

// ArcGIS Maps SDK headers
#include "ArcGISSceneLayer.h"
#include "ArcGISTiledElevationSource.h"
#include "Camera.h"
#include "ElevationSourceListModel.h"
#include "LayerListModel.h"
#include "MapTypes.h"
#include "Scene.h"
#include "SceneQuickView.h"
#include "SceneViewTypes.h"
#include "Surface.h"

// Qt headers
#include <QDate>
#include <QDateTime>
#include <QFuture>
#include <QTime>
#include <QTimeZone>
#include <QUrl>

// STL headers
#include <cmath>

using namespace Esri::ArcGISRuntime;

RealisticLightingAndShadows::RealisticLightingAndShadows(QObject* parent /* = nullptr */):
  QObject(parent),
  m_scene(new Scene(BasemapStyle::ArcGISTopographic, this))
{
  // create a new elevation source from Terrain3D REST service
  ArcGISTiledElevationSource* elevationSource = new ArcGISTiledElevationSource(
        QUrl("https://elevation3d.arcgis.com/arcgis/rest/services/WorldElevation3D/Terrain3D/ImageServer"), this);

  // add the elevation source to the scene to display elevation
  m_scene->baseSurface()->elevationSources()->append(elevationSource);

  // add 3D building shells with a scene layer
  ArcGISSceneLayer* scenelayer = new ArcGISSceneLayer(
        QUrl("https://tiles.arcgis.com/tiles/P3ePLMYs2RVChkJx/arcgis/rest/services/DevA_BuildingShells/SceneServer/layers/0"), this);

  m_scene->operationalLayers()->append(scenelayer);
}

RealisticLightingAndShadows::~RealisticLightingAndShadows() = default;

void RealisticLightingAndShadows::init()
{
  // Register classes for QML
  qmlRegisterType<SceneQuickView>("Esri.Samples", 1, 0, "SceneView");
  qmlRegisterType<RealisticLightingAndShadows>("Esri.Samples", 1, 0, "RealisticLightingAndShadowsSample");
}

SceneQuickView* RealisticLightingAndShadows::sceneView() const
{
  return m_sceneView;
}

// Set the view (created in QML)
void RealisticLightingAndShadows::setSceneView(SceneQuickView* sceneView)
{
  if (!sceneView || sceneView == m_sceneView)
    return;

  m_sceneView = sceneView;
  m_sceneView->setArcGISScene(m_scene);

  // add camera and set scene viewpoint
  const Camera camera(45.54605153789073, -122.69033380511073, 941.0002111233771, 162.58544227544266, 60.0,0.0);
  m_sceneView->setViewpointCameraAsync(camera, 0);

  // set atmosphere effect to realistic
  m_sceneView->setAtmosphereEffect(AtmosphereEffect::Realistic);

  // set the sun time to the calendar
  setSunTimeFromValue(8.5);

  // add sun lighting
  m_sceneView->setSunLighting(LightingMode::LightAndShadows);

  emit sceneViewChanged();
}

void RealisticLightingAndShadows::setSunTimeFromValue(double sunTimeValue)
{
  if (!m_sceneView)
    return;

  // convert a double from 0.0 to 23.99 into hours and minutes
  double remainder = std::fmod(sunTimeValue, 1);
  int minute = remainder * 60;
  int hour = sunTimeValue - remainder;

  const QTime selectedTime = QTime(hour, minute);

  // set a calendar with a date, time, and timezone
  const QDateTime sunTime(QDate(2018, 8, 10), selectedTime, QTimeZone(-25200));
  // To represent the PST time zone during daylight savings time (-7 hours), we use the number of seconds of offset.
  // 3600 seconds/hour * -7 hours = -25,200 seconds.

  // set the sun time to the calendar
  m_sceneView->setSunTime(sunTime);

  // trigger the time in the settings column to update
  emit sunTimeChanged(selectedTime.toString("h:mm ap"));
}

void RealisticLightingAndShadows::setLightingMode(int lightingModeValue)
{
  if (!m_sceneView)
    return;

  if (lightingModeValue == 0)
  {
    m_sceneView->setSunLighting(LightingMode::NoLight);
  }
  else if (lightingModeValue == 1)
  {
    m_sceneView->setSunLighting(LightingMode::Light);
  }
  else
  {
    m_sceneView->setSunLighting(LightingMode::LightAndShadows);
  }
}

// [WriteFile Name=RealisticLightingAndShadows, Category=Scenes]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef REALISTICLIGHTINGANDSHADOWS_H
#define REALISTICLIGHTINGANDSHADOWS_H

// Qt headers
#include <QObject>

namespace Esri::ArcGISRuntime
{
class Scene;
class SceneQuickView;
}

Q_MOC_INCLUDE("SceneQuickView.h")

class RealisticLightingAndShadows : public QObject
{
    Q_OBJECT

    Q_PROPERTY(Esri::ArcGISRuntime::SceneQuickView* sceneView READ sceneView WRITE setSceneView NOTIFY sceneViewChanged)

public:
    explicit RealisticLightingAndShadows(QObject* parent = nullptr);
    ~RealisticLightingAndShadows();

    static void init();

    Q_INVOKABLE void setSunTimeFromValue(const double sunTimeValue);
    Q_INVOKABLE void setLightingMode(const int lightingModeValue);

signals:
    void sceneViewChanged();
    void sunTimeChanged(const QString& sunTimeText);

private:
    Esri::ArcGISRuntime::SceneQuickView* sceneView() const;
    void setSceneView(Esri::ArcGISRuntime::SceneQuickView* sceneView);

    Esri::ArcGISRuntime::Scene* m_scene = nullptr;
    Esri::ArcGISRuntime::SceneQuickView* m_sceneView = nullptr;
};

#endif // REALISTICLIGHTINGANDSHADOWS_H

// [WriteFile Name=RealisticLightingAndShadows, Category=Scenes]
// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

Item {

    SceneView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on SceneView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the scene etc. and supply the view
    RealisticLightingAndShadowsSample {
        id: model
        sceneView: view
        onSunTimeChanged: sunTimeText => timeValue.text = "August 10, 2018, " + sunTimeText

    }
    Rectangle {
        anchors {
            top: parent.top
            right: parent.right
            margins: 5
        }
        width: childrenRect.width
        height: childrenRect.height
        color: "#ffffff"
        opacity: 0.7
        Column {
            id: settingsColumn
            spacing: 5
            padding: 15
            Text {
                id: timeValue
                anchors.horizontalCenter: parent.horizontalCenter
                font.pixelSize: 16
                // text is set from C++ instance
            }

            ComboBox {
                id: sunLightingSelection
                anchors.horizontalCenter: parent.horizontalCenter
                width: 200
                model: [
                    "No Light",
                    "Light",
                    "Light and Shadows"
                ]
                currentIndex: 2
                onCurrentIndexChanged: {
                    model.setLightingMode(currentIndex);
                }
            }
            Slider {
                id: sunTimeSlider
                anchors.horizontalCenter: parent.horizontalCenter
                opacity: 0.7
                from: 0; to: 23.99
                value: 8.5
                onValueChanged: {
                    model.setSunTimeFromValue(sunTimeSlider.value);
                }
            }
        }
    }
}

// [Legal]
// Copyright 2020 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "RealisticLightingAndShadows.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>
#include <QSurfaceFormat>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
#if defined(Q_OS_LINUX) && !defined(Q_OS_ANDROID)
    // Linux requires 3.2 OpenGL Context
    // in order to instance 3D symbols
    QSurfaceFormat fmt = QSurfaceFormat::defaultFormat();
    fmt.setVersion(3, 2);
    QSurfaceFormat::setDefaultFormat(fmt);
#endif

  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("RealisticLightingAndShadows"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

    // Initialize the sample
    RealisticLightingAndShadows::init();

    // Initialize application view
    QQmlApplicationEngine engine;
    // Add the import Path
    engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
    engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

#ifdef ARCGIS_TOOLKIT_IMPORT_PATH_2
    engine.addImportPath(ARCGIS_TOOLKIT_IMPORT_PATH_2);
#endif

    // Set the source
    engine.load(QUrl("qrc:/Samples/Scenes/RealisticLightingAndShadows/main.qml"));

    return app.exec();
}

// Copyright 2020 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    RealisticLightingAndShadows {
        anchors.fill: parent
    }
}
