Scene layer selection

// [WriteFile Name=SceneLayerSelection, Category=Scenes]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "SceneLayerSelection.h"

// ArcGIS Maps SDK headers
#include "ArcGISSceneLayer.h"
#include "ArcGISTiledElevationSource.h"
#include "Basemap.h"
#include "Camera.h"
#include "ElevationSourceListModel.h"
#include "Feature.h"
#include "IdentifyLayerResult.h"
#include "LayerListModel.h"
#include "MapTypes.h"
#include "Point.h"
#include "Scene.h"
#include "SceneQuickView.h"
#include "SpatialReference.h"
#include "Surface.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>
#include <QUuid>

using namespace Esri::ArcGISRuntime;

SceneLayerSelection::SceneLayerSelection(QQuickItem* parent /* = nullptr */):
  QQuickItem(parent)
{
}

void SceneLayerSelection::init()
{
  // Register classes for QML
  qmlRegisterType<SceneQuickView>("Esri.Samples", 1, 0, "SceneView");
  qmlRegisterType<SceneLayerSelection>("Esri.Samples", 1, 0, "SceneLayerSelectionSample");
}

void SceneLayerSelection::componentComplete()
{
  QQuickItem::componentComplete();

  m_sceneView = findChild<SceneQuickView*>("sceneView");

  // Create a scene with the topographic basemap
  Scene* scene = new Scene(BasemapStyle::ArcGISTopographic, this);

  // add a surface
  Surface* surface = new Surface(this);
  surface->elevationSources()->append(
        new ArcGISTiledElevationSource(
          QUrl("https://elevation3d.arcgis.com/arcgis/rest/services/WorldElevation3D/Terrain3D/ImageServer"),
          this));
  scene->setBaseSurface(surface);

  // add a scene layer
  m_sceneLayer = new ArcGISSceneLayer(QUrl("https://tiles.arcgis.com/tiles/P3ePLMYs2RVChkJx/arcgis/rest/services/Buildings_Brest/SceneServer/layers/0"), this);
  scene->operationalLayers()->append(m_sceneLayer);

  // Set an initial viewpoint
  Point pt(-4.49779155626782, 48.38282454039932, 62.013264927081764, SpatialReference(4326));
  Camera camera(pt, 41.64729875588979, 71.2017391571523, 2.194677223e-314);
  Viewpoint initViewpoint(pt, camera);
  scene->setInitialViewpoint(initViewpoint);

  // connect signals
  connectSignals();

  // set the scene on the scene view
  m_sceneView->setArcGISScene(scene);
}

void SceneLayerSelection::connectSignals()
{
  // when the scene is clicked, identify the clicked feature and select it
  connect(m_sceneView, &SceneQuickView::mouseClicked, this, [this](QMouseEvent& mouseEvent)
  {
    // clear any previous selection
    m_sceneLayer->clearSelection();

    // identify from the click
    m_sceneView->identifyLayerAsync(m_sceneLayer, mouseEvent.position(), 10, false).then(this,
    [this](IdentifyLayerResult* result)
    {
      // get the results
      QList<GeoElement*> geoElements = result->geoElements();

      // make sure we have at least 1 GeoElement
      if (geoElements.isEmpty())
        return;

      // get the first GeoElement
      GeoElement* geoElement = geoElements.first();

      // cast the GeoElement to a Feature
      Feature* feature = static_cast<Feature*>(geoElement);

      // select the Feature in the SceneLayer
      if (feature)
      {
        feature->setParent(this);
        m_sceneLayer->selectFeature(feature);
      }
    });
  });
}

// [WriteFile Name=SceneLayerSelection, Category=Scenes]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef SCENELAYERSELECTION_H
#define SCENELAYERSELECTION_H

// Qt headers
#include <QQuickItem>

namespace Esri::ArcGISRuntime
{
class SceneQuickView;
class ArcGISSceneLayer;
}

class SceneLayerSelection : public QQuickItem
{
  Q_OBJECT

public:
  explicit SceneLayerSelection(QQuickItem* parent = nullptr);
  ~SceneLayerSelection() override = default;

  void componentComplete() override;
  static void init();

private:
  Esri::ArcGISRuntime::SceneQuickView* m_sceneView = nullptr;
  Esri::ArcGISRuntime::ArcGISSceneLayer* m_sceneLayer = nullptr;
  void connectSignals();
};

#endif // SCENELAYERSELECTION_H

// [WriteFile Name=SceneLayerSelection, Category=Scenes]
// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

SceneLayerSelectionSample {
    id: rootRectangle
    clip: true
    width: 800
    height: 600

    SceneView {
        objectName: "sceneView"
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on SceneView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }
}

// [Legal]
// Copyright 2018 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "SceneLayerSelection.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>
#include <QSurfaceFormat>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
#if defined(Q_OS_LINUX) && !defined(Q_OS_ANDROID)
  // Linux requires 3.2 OpenGL Context
  // in order to instance 3D symbols
  QSurfaceFormat fmt = QSurfaceFormat::defaultFormat();
  fmt.setVersion(3, 2);
  QSurfaceFormat::setDefaultFormat(fmt);
#endif

  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("SceneLayerSelection"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  SceneLayerSelection::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

#if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
#endif

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));
  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/Scenes/SceneLayerSelection/SceneLayerSelection.qml"));

  view.show();

  return app.exec();
}
