Data Collections and GeoEnrichment coverage
As described earlier, a data collection is a preassembled list of attributes that will be used to enrich the input features. Collection attributes can describe various types of information, such as demographic characteristics and geographic context of the locations or areas submitted as input features.
Some data collections (such as default) can be used in all supported countries. Other data collections may only be available in one or a collection of countries. Data Browser can be used to examine the entire global listing of variables, and associated datasets for each country.
List Countries with GeoEnrichment Data
The get_countries() method can be used to query the countries for which GeoEnrichment data is available, and it returns a list of Country objects with which you can further query for properties. This list can also be viewed here.
from arcgis.gis import GIS
from arcgis.geoenrichment import Country, enrich, get_countries# Create a GIS Connection
gis = GIS(profile='your_online_profile')countries = get_countries()
print("Number of countries for which GeoEnrichment data is available: " + str(len(countries)))
#print a few countries for a sample
countries[0:10]Number of countries for which GeoEnrichment data is available: 177
| iso2 | iso3 | name | alt_name | datasets | default_dataset | continent | hierarchies | default_hierarchy | |
|---|---|---|---|---|---|---|---|---|---|
| 0 | AL | ALB | Albania | ALBANIA | [ALB_MBR_2024] | ALB_MBR_2024 | Europe | [census] | census |
| 1 | DZ | DZA | Algeria | ALGERIA | [DZA_MBR_2025] | DZA_MBR_2025 | Africa | [census] | census |
| 2 | AD | AND | Andorra | ANDORRA | [AND_MBR_2024] | AND_MBR_2024 | Europe | [census] | census |
| 3 | AO | AGO | Angola | ANGOLA | [AGO_MBR_2025] | AGO_MBR_2025 | Africa | [census] | census |
| 4 | AI | AIA | Anguilla | ANGUILLA | [AIA_MBR_2025] | AIA_MBR_2025 | North America | [census] | census |
| 5 | AR | ARG | Argentina | ARGENTINA | [ARG_MBR_2024] | ARG_MBR_2024 | South America | [census] | census |
| 6 | AM | ARM | Armenia | ARMENIA | [ARM_MBR_2024] | ARM_MBR_2024 | Europe | [census] | census |
| 7 | AW | ABW | Aruba | ARUBA | [ABW_MBR_2025] | ABW_MBR_2025 | North America | [census] | census |
| 8 | AU | AUS | Australia | AUSTRALIA | [AUS_ABS_2021, AUS_MBR_2024] | AUS_ABS_2021 | Oceania | [AUS_ABS, census] | AUS_ABS |
| 9 | AT | AUT | Austria | AUSTRIA | [AUT_MBR_2024] | AUT_MBR_2024 | Europe | [census] | census |
Data Collections for U.S.
The data_collections property of a Country object lists its available data collections and analysis variables under each data collection as a Pandas dataframe.
In order to discover the data collections for a particular country, you may first access the reference variable to it using the country.get() method, and then fetch the data collections from country.data_collections property. Once we know the data collection we would like to use, we can look at analysisVariables available in that data collection.
# Get US as a country
usa = Country.get('US')
type(usa)arcgis.geoenrichment.enrichment.Country
usa_df = usa.data_collections
# print a few rows of the DataFrame
usa_df.head()| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| 1yearincrements | 1yearincrements.AGE0_CY | 2025 Population Age <1 | 2025 Age: 1 Year Increments (Esri) | 2025 |
| 1yearincrements | 1yearincrements.AGE1_CY | 2025 Population Age 1 | 2025 Age: 1 Year Increments (Esri) | 2025 |
| 1yearincrements | 1yearincrements.AGE2_CY | 2025 Population Age 2 | 2025 Age: 1 Year Increments (Esri) | 2025 |
| 1yearincrements | 1yearincrements.AGE3_CY | 2025 Population Age 3 | 2025 Age: 1 Year Increments (Esri) | 2025 |
| 1yearincrements | 1yearincrements.AGE4_CY | 2025 Population Age 4 | 2025 Age: 1 Year Increments (Esri) | 2025 |
usa_df.shape(21033, 4)
Unique Data Collections for U.S.
Each data collection and analysis variable has a unique ID. When calling the enrich() method (explained earlier in this guide) these analysis variables can be passed in the data_collections and analysis_variables parameters.
As an example, here we see a subset of the data collections for US showing 2 different data collections and multiple analysis variables for each collection.
usa_df.iloc[500:600,:]| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| 1yearincrements | 1yearincrements.FAGE75_FY | 2030 Females Age 75 | 2030 Age: 1 Year Increments (Esri) | 2030 |
| 1yearincrements | 1yearincrements.FAGE76_FY | 2030 Females Age 76 | 2030 Age: 1 Year Increments (Esri) | 2030 |
| 1yearincrements | 1yearincrements.FAGE77_FY | 2030 Females Age 77 | 2030 Age: 1 Year Increments (Esri) | 2030 |
| 1yearincrements | 1yearincrements.FAGE78_FY | 2030 Females Age 78 | 2030 Age: 1 Year Increments (Esri) | 2030 |
| 1yearincrements | 1yearincrements.FAGE79_FY | 2030 Females Age 79 | 2030 Age: 1 Year Increments (Esri) | 2030 |
| ... | ... | ... | ... | ... |
| 1yearincrements | 1yearincrements.AGE18C20 | 2020 Population Age 18 | 2020 Age: 1 Year Increments (U.S. Census) | 2020 |
| 1yearincrements | 1yearincrements.AGE19C20 | 2020 Population Age 19 | 2020 Age: 1 Year Increments (U.S. Census) | 2020 |
| 1yearincrements | 1yearincrements.AGE20C20 | 2020 Population Age 20 | 2020 Age: 1 Year Increments (U.S. Census) | 2020 |
| 1yearincrements | 1yearincrements.AGE21C20 | 2020 Population Age 21 | 2020 Age: 1 Year Increments (U.S. Census) | 2020 |
| 1yearincrements | 1yearincrements.MLU20POP20 | 2020 Male Pop <20 | 2020 Age: 1 Year Increments (U.S. Census) | 2020 |
100 rows × 4 columns
The table above shows 2 different data collections (1yearincrements and 5yearincrements). Since these are Age data collections, the analysisVariables for these collections are similar. vintage shows the year that the demographic data represents. For example, a vintage of 2020 means that the data represents the year 2020.
Let's get a list of unique data collections that are available for U.S.
usa_df.index.nunique()121
United States has 150 unique data collections. Here are the first 10 data collections.
list(usa_df.index.unique())[:10]['1yearincrements', '5yearincrements', 'Age', 'agebyracebysex', 'agebyracebysex2010', 'agebyracebysex2020', 'AgeDependency', 'AtRisk', 'AutomobilesAutomotiveProducts', 'BabyProductsToysGames']
Looking at fieldCategory is a great way to clearly understand what the data collection is about. fieldCategory combines vintage, datacollectionID columns along with the year and data collection. However, to query a data collection its unique ID (dataCollectionID) must be used.
Let's look at the fieldCategory column for a few data collections in US.
usa_df.fieldCategory.unique()[:10]array(['2025 Age: 1 Year Increments (Esri)',
'2030 Age: 1 Year Increments (Esri)',
'2010 Age: 1 Year Increments (U.S. Census)',
'2020 Age: 1 Year Increments (U.S. Census)',
'2025 Age: 5 Year Increments (Esri)',
'2030 Age: 5 Year Increments (Esri)',
'2010 Age: 5 Year Increments (U.S. Census)',
'2019-2023 Age: 5 Year Increments (ACS)',
'2020 Age: 5 Year Increments (U.S. Census)',
'2025 Age by Sex by Race (Esri)'], dtype=object)Data Collections by Socio-demographic Factors
You can filter the data_collections to get collections for a specific factor using Pandas expressions. Let's loook at data collections for different socio-demographic factors such as Age, Population, Income.
Data Collections for Age
Age_Collections = usa_df['fieldCategory'].str.contains('Age', na=False)
usa_df[Age_Collections].fieldCategory.unique()array(['2025 Age: 1 Year Increments (Esri)',
'2030 Age: 1 Year Increments (Esri)',
'2010 Age: 1 Year Increments (U.S. Census)',
'2020 Age: 1 Year Increments (U.S. Census)',
'2025 Age: 5 Year Increments (Esri)',
'2030 Age: 5 Year Increments (Esri)',
'2010 Age: 5 Year Increments (U.S. Census)',
'2019-2023 Age: 5 Year Increments (ACS)',
'2020 Age: 5 Year Increments (U.S. Census)',
'2025 Age by Sex by Race (Esri)', '2030 Age by Sex by Race (Esri)',
'2010 Age by Sex by Race (U.S. Census)',
'2020 Age by Sex by Race (U.S. Census)',
'2025 Age Dependency (Esri)', '2030 Age Dependency (Esri)',
'2025 Disposable Income by Age (Esri)',
'2010 Households by Age of Householder (U.S. Census)',
'2019-2023 Households by Type and Size and Age (ACS)',
'2010 Housing by Age of Householder (U.S. Census)',
'2020 Housing by Age of Householder (U.S. Census)',
'2025 Income by Age (Esri)', '2030 Income by Age (Esri)',
'2019-2023 Income by Age (ACS)', 'Age: 5 Year Increments',
'2025 Net Worth by Age (Esri)',
'2019-2023 Females by Age of Children and Employment Status (ACS)'],
dtype=object)Data Collections for Population
Pop_Collections = usa_df['fieldCategory'].str.contains('Population', na=False)
usa_df[Pop_Collections].fieldCategory.unique()array(['2010 Population (U.S. Census)', '2020 Population (U.S. Census)',
'2019-2023 Population by Language Spoken at Home (ACS)',
'2025 Daytime Population (Esri)',
'2025 Population by Generation (Esri)',
'2030 Population by Generation (Esri)',
'2020 Group Quarters Population (U.S. Census)',
'2010 Group Quarters Population (U.S. Census)',
'2020 Hispanic Population of Two or More Races (U.S. Census)',
'2020 Hispanic Population <18 Years by Race (U.S. Census)',
'2020 Hispanic Population 18+ Years by Race (U.S. Census)',
'2020 Hispanic Population 18+ Years of Two or More Races (U.S. Census)',
'2025 Population Time Series (Esri)',
'2010 Population by Relationship and Household Type (U.S. Census)',
'2019-2023 Population by Relationship and Household Type (ACS)',
'2020 Population by Relationship and Household Type (U.S. Census)',
'2025 Tapestry (Population)',
'2020 Non Hispanic Population 18+ Years by Race (U.S. Census)',
'2020 Non Hispanic Population 18+ Years of Two or More Races (U.S. Census)',
'2020 Non Hispanic Population <18 Years by Race (U.S. Census)',
'2020 Non Hispanic Population of Two or More Races (U.S. Census)',
'2025 Population (Esri)',
'2020 Population of Two or More Races (U.S. Census)',
'2020 Population <18 Years by Race (U.S. Census)',
'2020 Population 18+ Years by Race (U.S. Census)',
'2020 Population 18+ Years of Two or More Races (U.S. Census)',
'2025 Urbanicity (Population)'], dtype=object)Data Collections for Income
Income_Collections = usa_df['fieldCategory'].str.contains('Income', na=False)
Income_Collections.index.unique()Index(['1yearincrements', '5yearincrements', 'Age', 'agebyracebysex',
'agebyracebysex2010', 'agebyracebysex2020', 'AgeDependency', 'AtRisk',
'AutomobilesAutomotiveProducts', 'BabyProductsToysGames',
...
'unitsinstructure', 'urbanicity', 'UrbanicityLandarea', 'vacant',
'vehiclesavailable', 'veterans', 'Wealth', 'women', 'yearbuilt',
'yearmovedin'],
dtype='object', name='dataCollectionID', length=121)As mentioned earlier, using a data_collection's unique ID (dataCollectionID) is the best way to further query a data collection. Let's look at the dataCollectionID for various Income data collections.
usa_df[Income_Collections].index.unique()Index(['AtRisk', 'basicFactsForMobileApps', 'disposableincome',
'foodstampsSNAP', 'Health', 'householdincome', 'households',
'incomebyage', 'KeyUSFacts', 'Policy', 'population', 'Wealth'],
dtype='object', name='dataCollectionID')Analysis variables for Data Collections
Once we know the data collection we would like to use, we can look at all the unique variables available in that data collection using its unique ID. Let's discover analysisVariables for some of the data collections.
Analysis variables for Age data collection
usa_df.loc['Age']['analysisVariable'].unique()array(['Age.MALE0', 'Age.MALE5', 'Age.MALE10', 'Age.MALE15', 'Age.MALE20',
'Age.MALE25', 'Age.MALE30', 'Age.MALE35', 'Age.MALE40',
'Age.MALE45', 'Age.MALE50', 'Age.MALE55', 'Age.MALE60',
'Age.MALE65', 'Age.MALE70', 'Age.MALE75', 'Age.MALE80',
'Age.MALE85', 'Age.FEM0', 'Age.FEM5', 'Age.FEM10', 'Age.FEM15',
'Age.FEM20', 'Age.FEM25', 'Age.FEM30', 'Age.FEM35', 'Age.FEM40',
'Age.FEM45', 'Age.FEM50', 'Age.FEM55', 'Age.FEM60', 'Age.FEM65',
'Age.FEM70', 'Age.FEM75', 'Age.FEM80', 'Age.FEM85'], dtype=object)Analysis variables are typically represented as dataCollectionID.<analysis variable name> as seen above.
Analysis variables for DaytimePopulation data collection
usa_df.loc['DaytimePopulation']['analysisVariable'].unique()array(['DaytimePopulation.DPOP_CY', 'DaytimePopulation.DPOPWRK_CY',
'DaytimePopulation.DPOPRES_CY', 'DaytimePopulation.DPOPDENSCY'],
dtype=object)Data Collections for Another Country
Let's look at data collections for New Zealand. Data Browser can be used to examine the entire global listing of variables, and associated datasets for New Zealand.
In order to discover the data collections for a particular country, you may first access the reference variable to it using the country.get() method, and then fetch the data collections from country.data_collections property. Once we know the data collection we would like to use, we can look at analysisVariables available in that data collection.
# Get US as a country
nz = Country.get('New Zealand')
type(nz)arcgis.geoenrichment.enrichment.Country
nz_df = nz.data_collections
# print a few rows of the DataFrame
nz_df.head()| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| 5YearIncrementsStatsNZ | 5YearIncrementsStatsNZ.Age5year_Total | 2023 5-Year Age Groups: Total | 2023 Population by Age (Stats NZ) | 2023 |
| 5YearIncrementsStatsNZ | 5YearIncrementsStatsNZ.Age5year_0_4_years | 2023 5-Year Age Group: 0 to 4 Years | 2023 Population by Age (Stats NZ) | 2023 |
| 5YearIncrementsStatsNZ | 5YearIncrementsStatsNZ.Age5year_5_9_years | 2023 5-Year Age Group: 5 to 9 Years | 2023 Population by Age (Stats NZ) | 2023 |
| 5YearIncrementsStatsNZ | 5YearIncrementsStatsNZ.Age5year_10_14_years | 2023 5-Year Age Group: 10 to 14 Years | 2023 Population by Age (Stats NZ) | 2023 |
| 5YearIncrementsStatsNZ | 5YearIncrementsStatsNZ.Age5year_15_19_years | 2023 5-Year Age Group: 15 to 19 Years | 2023 Population by Age (Stats NZ) | 2023 |
nz_df.shape(718, 4)
Unique Data Collections for New Zealand
Let's get a list of unique data collections that are available for New Zealand.
nz_df.index.unique()Index(['5YearIncrementsStatsNZ', 'AccesstoAmenitiesStatsNZ',
'AccesstoTelecommunicationsStatsNZ', 'BirthplaceStatsNZ',
'DwellingDampnessStatsNZ', 'EducationalAttainmentStatsNZ',
'EmploymentStatusStatsNZ', 'EthnicityStatsNZ', 'FamilyStatsNZ',
'HealthStatsNZ', 'HeatingSourceStatsNZ', 'HomeOwnershipStatusStatsNZ',
'HoursWorkedStatsNZ', 'HouseholdIncomeStatsNZ', 'HousingbySizeStatsNZ',
'HousingCostsStatsNZ', 'ImmigrationPeriodStatsNZ', 'IndustryStatsNZ',
'JobSearchStatsNZ', 'KeyGlobalFacts', 'LabourForceStatusStatsNZ',
'LandlordTypeStatsNZ', 'LanguageSpokenStatsNZ',
'LifeCycleGroupsStatsNZ', 'MaoriDescentStatsNZ', 'MaritalStatusStatsNZ',
'MethodofTraveltoWorkStatsNZ', 'NumberofBornChildrenStatsNZ',
'OccupancyStatusStatsNZ', 'OccupationStatsNZ', 'PersonalIncomeStatsNZ',
'PopulationTotalsStatsNZ', 'ReligiousAffiliationStatsNZ',
'SmokingBehaviourStatsNZ', 'StructureTypeStatsNZ',
'StudyParticipationStatsNZ', 'TraveltoSchoolStatsNZ',
'UnpaidActivitiesStatsNZ', 'UsualResidenceStatsNZ', 'VehiclesStatsNZ'],
dtype='object', name='dataCollectionID')New Zealand has 40 unique data collections.
We can look at the fieldCategory column to understand each category better.
nz_df.fieldCategory.unique()array(['2023 Population by Age (Stats NZ)',
'2023 AccessToAmenities (Stats NZ)',
'2023 Access To Telecommunications (Stats NZ)',
'2023 Birthplace (Stats NZ)', '2023 Dwelling Dampness (Stats NZ)',
'2023 Dwelling Mould (Stats NZ)',
'2023 Educational Attainment (Stats NZ)',
'2023 Post-school Qualification Indicator (Stats NZ)',
'2023 Highest Secondary School Qualification (Stats NZ)',
'2023 Post-school Qualification (Stats NZ)',
'2023 Empolyment Status (Stats NZ)', '2023 Ethnicity (Stats NZ)',
'2023 Family Totals (Stats NZ)',
'2023 Dwelling by Family Type (Stats NZ)',
'2023 Number of People in Family (Stats NZ)',
'2023 Family Income (Stats NZ)',
'2023 Extended Family Totals (Stats NZ)',
'2023 Dwelling by Extended Family Type (Stats NZ)',
'2023 Extended Family Income (Stats NZ)',
'2023 Difficulty Seeing (Stats NZ)',
'2023 Difficulty Hearing (Stats NZ)',
'2023 Difficulty Walking (Stats NZ)',
'2023 Difficulty Remembering (Stats NZ)',
'2023 Difficulty Washing or Dressing (Stats NZ)',
'2023 Difficulty Communicating (Stats NZ)',
'2023 LGBTIQ+ Indicator (Stats NZ)',
'2023 Sexual Identity (Stats NZ)',
'2023 Disability Indicator (Stats NZ)',
'2023 Heating Source (Stats NZ)', '2023 Heating Fuel (Stats NZ)',
'2023 Households by Tenure (Stats NZ)',
'2023 Home Ownership Status (Stats NZ)',
'2023 Sector of Ownership (Stats NZ)',
'2023 Hours Worked (Stats NZ)', '2023 Household Income (Stats NZ)',
'2023 Dwelling By Number Of Rooms (Stats NZ)',
'2023 Dwelling By Number Of Bedrooms (Stats NZ)',
'2023 Household Crowding Index (Stats NZ)',
'2023 Household Composition (Stats NZ)',
'2023 Housing Costs (Stats NZ)',
'2023 Years Since Immigration (Stats NZ)',
'2023 Industry By Residence (Stats NZ)',
'2023 Industry by Workplace (Stats NZ)',
'2023 Job Search Methods (2023)', 'Key Demographic Indicators',
'2023 Labour Force Status (Stats NZ)',
'2023 Landlord Type (Stats NZ)',
'2023 Languages Spoken (Stats NZ)',
'2023 Life Cycle Group (Stats NZ)',
'2023 Māori Descent (Stats NZ)', '2023 Marital Status (Stats NZ)',
'2023 Partnership Status (Stats NZ)',
'2023 Travel To Work by Residence (Stats NZ)',
'2023 Travel To Work by Workplace (Stats NZ)',
'2023 Number Of Children (Stats NZ)',
'2023 Occupancy Status (Stats NZ)',
'2023 Occupation By Residence (Stats NZ)',
'2023 Occupation By Workplace (Stats NZ)',
'2023 Personal Income (Stats NZ)',
'2023 Source of Income (Stats NZ)',
'2023 Population Totals (Stats NZ)',
'2023 Sex at Birth (Stats NZ)',
'2023 Religious Affiliation (Stats NZ)',
'2023 Smoking Behaviour (Stats NZ)',
'2023 Dwelling Record Type (Stats NZ)',
'2023 Dwelling Structure Type (Stats NZ)',
'2023 Study Participation (Stats NZ)',
'2023 Travel To Education By Residence (Stats NZ)',
'2023 Travel To Education By Institution (Stats NZ)',
'2023 Unpaid Activities (Stats NZ)',
'2023 Years at Residence (Stats NZ)',
'2023 5-Year Residence History (Stats NZ)',
'2023 1-Year Residence History (Stats NZ)',
'2023 Number of Usual Residents (Stats NZ)',
'2023 Vehicles Available (Stats NZ)'], dtype=object)Looking at fieldCategory is a great way to clearly understand what the data collection is about. However, to query a data collection its unique ID (dataCollectionID) must be used.
Data Collections for Socio-demographic Factors
New Zealand has fewer data_collections compared to U.S. Let's look at data collections for Key Facts, Education and Family.
Data Collection for Key Facts
nz_df.loc['KeyGlobalFacts']| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| KeyGlobalFacts | KeyGlobalFacts.TOTPOP | Total Population | Key Demographic Indicators | NaN |
| KeyGlobalFacts | KeyGlobalFacts.TOTHH | Total Households | Key Demographic Indicators | NaN |
| KeyGlobalFacts | KeyGlobalFacts.TOTFEMALES | Female Population | Key Demographic Indicators | NaN |
| KeyGlobalFacts | KeyGlobalFacts.TOTMALES | Male Population | Key Demographic Indicators | NaN |
| KeyGlobalFacts | KeyGlobalFacts.AVGHHSZ | Average Household Size | Key Demographic Indicators | NaN |
Data Collection for Education
Let's take a look at the first 5 rows for this collection.
nz_df.loc['EducationalAttainmentStatsNZ'].head()| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| EducationalAttainmentStatsNZ | EducationalAttainmentStatsNZ.HighestQual_Total | 2023 Education Attainment: Total | 2023 Educational Attainment (Stats NZ) | 2023 |
| EducationalAttainmentStatsNZ | EducationalAttainmentStatsNZ.HighestQual_TStated | 2023 Education Attainment: Total Stated | 2023 Educational Attainment (Stats NZ) | 2023 |
| EducationalAttainmentStatsNZ | EducationalAttainmentStatsNZ.HighestQual_No_quali | 2023 Education Attainment: No Qualifications | 2023 Educational Attainment (Stats NZ) | 2023 |
| EducationalAttainmentStatsNZ | EducationalAttainmentStatsNZ.HighestQual_L1_Certi | 2023 Education Attainment: Level 1 Certificate | 2023 Educational Attainment (Stats NZ) | 2023 |
| EducationalAttainmentStatsNZ | EducationalAttainmentStatsNZ.HighestQual_L2_Certi | 2023 Education Attainment: Level 2 Certificate | 2023 Educational Attainment (Stats NZ) | 2023 |
Data Collection for Family
Let's take a look at the first 5 rows for this collection.
nz_df.loc['FamilyStatsNZ'].head()| analysisVariable | alias | fieldCategory | vintage | |
|---|---|---|---|---|
| dataCollectionID | ||||
| FamilyStatsNZ | FamilyStatsNZ.FamilyCount_Total | 2023 Count of Families: Total | 2023 Family Totals (Stats NZ) | 2023 |
| FamilyStatsNZ | FamilyStatsNZ.FamType_Total | 2023 Family Type: Total | 2023 Dwelling by Family Type (Stats NZ) | 2023 |
| FamilyStatsNZ | FamilyStatsNZ.FamType_CoupNoChildren | 2023 Family Type: Couple Without Children | 2023 Dwelling by Family Type (Stats NZ) | 2023 |
| FamilyStatsNZ | FamilyStatsNZ.FamType_CoupWithChildren | 2023 Family Type: Couple With Child(ren) | 2023 Dwelling by Family Type (Stats NZ) | 2023 |
| FamilyStatsNZ | FamilyStatsNZ.FamType_OneParent | 2023 Family Type: One Parent With Child(ren) | 2023 Dwelling by Family Type (Stats NZ) | 2023 |
Analysis variables for Data Collections
Once we know the data collection we would like to use, we can look at all the unique variables available in that data collection using its unique ID. Let's discover analysisVariables for some of the data collections we looked at earlier.
Analysis variables for KeyGlobalFacts data collection
nz_df.loc['KeyGlobalFacts']['analysisVariable'].unique()array(['KeyGlobalFacts.TOTPOP', 'KeyGlobalFacts.TOTHH',
'KeyGlobalFacts.TOTFEMALES', 'KeyGlobalFacts.TOTMALES',
'KeyGlobalFacts.AVGHHSZ'], dtype=object)Analysis variables for EducationalAttainmentStatsNZ data collection
nz_df.loc['EducationalAttainmentStatsNZ']['analysisVariable'].unique()array(['EducationalAttainmentStatsNZ.HighestQual_Total',
'EducationalAttainmentStatsNZ.HighestQual_TStated',
'EducationalAttainmentStatsNZ.HighestQual_No_quali',
'EducationalAttainmentStatsNZ.HighestQual_L1_Certi',
'EducationalAttainmentStatsNZ.HighestQual_L2_Certi',
'EducationalAttainmentStatsNZ.HighestQual_L3_Certi',
'EducationalAttainmentStatsNZ.HighestQual_L4_Certi',
'EducationalAttainmentStatsNZ.HighestQual_L5_Diplo',
'EducationalAttainmentStatsNZ.HighestQual_L6_Diplo',
'EducationalAttainmentStatsNZ.HighestQual_Bachelor',
'EducationalAttainmentStatsNZ.HighestQual_PostGrad',
'EducationalAttainmentStatsNZ.HighestQual_Masters',
'EducationalAttainmentStatsNZ.HighestQual_Doctorat',
'EducationalAttainmentStatsNZ.HighestQual_OSSecSch',
'EducationalAttainmentStatsNZ.HighestQual_NEI',
'EducationalAttainmentStatsNZ.PostIndicator_No',
'EducationalAttainmentStatsNZ.PostIndicator_NZ',
'EducationalAttainmentStatsNZ.PostIndicator_Overseas',
'EducationalAttainmentStatsNZ.PostIndicator_NEI',
'EducationalAttainmentStatsNZ.PostIndicator_Total',
'EducationalAttainmentStatsNZ.PostIndicator_Tstated',
'EducationalAttainmentStatsNZ.HighSecondQual_No_quali',
'EducationalAttainmentStatsNZ.HighSecondQual_L1_Certi',
'EducationalAttainmentStatsNZ.HighSecondQual_L2_Certi',
'EducationalAttainmentStatsNZ.HighSecondQual_L3L4_Certi',
'EducationalAttainmentStatsNZ.HighSecondQual_Overseas',
'EducationalAttainmentStatsNZ.HighSecondQual_NEI',
'EducationalAttainmentStatsNZ.HighSecondQual_Total',
'EducationalAttainmentStatsNZ.HighSecondQual_TStated',
'EducationalAttainmentStatsNZ.PostQual_Total',
'EducationalAttainmentStatsNZ.PostQual_TStated',
'EducationalAttainmentStatsNZ.PostQual_No_quali',
'EducationalAttainmentStatsNZ.PostQual_L1_Certi',
'EducationalAttainmentStatsNZ.PostQual_L2_Certi',
'EducationalAttainmentStatsNZ.PostQual_L3_Certi',
'EducationalAttainmentStatsNZ.PostQual_L4_Certi',
'EducationalAttainmentStatsNZ.PostQual_L5_Diplo',
'EducationalAttainmentStatsNZ.PostQual_L6_Diplo',
'EducationalAttainmentStatsNZ.PostQual_Bachelor',
'EducationalAttainmentStatsNZ.PostQual_PostGrad',
'EducationalAttainmentStatsNZ.PostQual_Masters',
'EducationalAttainmentStatsNZ.PostQual_Doctorat',
'EducationalAttainmentStatsNZ.PostQual_NotGiven',
'EducationalAttainmentStatsNZ.PostQual_NEI'], dtype=object)Analysis variables for FamilyStatsNZ data collection
nz_df.loc['FamilyStatsNZ']['analysisVariable'].unique()array(['FamilyStatsNZ.FamilyCount_Total', 'FamilyStatsNZ.FamType_Total',
'FamilyStatsNZ.FamType_CoupNoChildren',
'FamilyStatsNZ.FamType_CoupWithChildren',
'FamilyStatsNZ.FamType_OneParent', 'FamilyStatsNZ.NumberFam_Total',
'FamilyStatsNZ.NumberFam_Two', 'FamilyStatsNZ.NumberFam_Three',
'FamilyStatsNZ.NumberFam_Four', 'FamilyStatsNZ.NumberFam_Five',
'FamilyStatsNZ.NumberFam_Six', 'FamilyStatsNZ.NumberFam_SevenMore',
'FamilyStatsNZ.NumberFam_Average', 'FamilyStatsNZ.FamIncome_Total',
'FamilyStatsNZ.FamIncome_20kOrLess',
'FamilyStatsNZ.FamIncome_20kto30k',
'FamilyStatsNZ.FamIncome_30kto50k',
'FamilyStatsNZ.FamIncome_50kto70k',
'FamilyStatsNZ.FamIncome_70kto100k',
'FamilyStatsNZ.FamIncome_100kto150k',
'FamilyStatsNZ.FamIncome_150kto200k',
'FamilyStatsNZ.FamIncome_200korMore',
'FamilyStatsNZ.FamIncome_Median',
'FamilyStatsNZ.FamIncome_Tstated',
'FamilyStatsNZ.FamIncome_NotStated',
'FamilyStatsNZ.ExtFamilyCount_Total',
'FamilyStatsNZ.ExtFamType_Total',
'FamilyStatsNZ.ExtFamType_OneGen',
'FamilyStatsNZ.ExtFamType_TwoGen',
'FamilyStatsNZ.ExtFamType_ThreeMore',
'FamilyStatsNZ.ExtFamType_NotClassi',
'FamilyStatsNZ.ExtFamType_Tstated',
'FamilyStatsNZ.ExtFamIncome_Total',
'FamilyStatsNZ.ExtFamIncome_30kOrLess',
'FamilyStatsNZ.ExtFamIncome_30kto50k',
'FamilyStatsNZ.ExtFamIncome_50kto70k',
'FamilyStatsNZ.ExtFamIncome_70kto100k',
'FamilyStatsNZ.ExtFamIncome_100kto150k',
'FamilyStatsNZ.ExtFamIncome_150kto200k',
'FamilyStatsNZ.ExtFamIncome_200korMore',
'FamilyStatsNZ.ExtFamIncome_Median',
'FamilyStatsNZ.ExtFamIncome_Tstated',
'FamilyStatsNZ.ExtFamIncome_NotStated'], dtype=object)Perform Enrichment using Data Collections and Analysis Variables
Data Collections can be used to enrich various study areas. data_collections and analysis_variables can be passed in the enrich() method. Details about enriching study areas can be found in Enriching Study Areas section.
Let's look at a few similar examples of GeoEnrichment here.
Enrich using Data Collections
Enrich with Age data collection
Here we see an address being enriched by data from Age data collection.
# Enriching single address as single line imput
age_coll = enrich(study_areas=["380 New York St Redlands CA 92373"],
data_collections=['Age'])age_coll| source_country | x | y | area_type | buffer_units | buffer_units_alias | buffer_radii | aggregation_method | population_to_polygon_size_rating | apportionment_confidence | ... | fem45 | fem50 | fem55 | fem60 | fem65 | fem70 | fem75 | fem80 | fem85 | SHAPE | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | US | -117.194835 | 34.057242 | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | ... | 381.0 | 375.0 | 323.0 | 341.0 | 281.0 | 255.0 | 190.0 | 132.0 | 116.0 | {"rings": [[[-117.194835113918, 34.07175043587... |
1 rows × 48 columns
age_coll.columnsIndex(['source_country', 'x', 'y', 'area_type', 'buffer_units',
'buffer_units_alias', 'buffer_radii', 'aggregation_method',
'population_to_polygon_size_rating', 'apportionment_confidence',
'has_data', 'male0', 'male5', 'male10', 'male15', 'male20', 'male25',
'male30', 'male35', 'male40', 'male45', 'male50', 'male55', 'male60',
'male65', 'male70', 'male75', 'male80', 'male85', 'fem0', 'fem5',
'fem10', 'fem15', 'fem20', 'fem25', 'fem30', 'fem35', 'fem40', 'fem45',
'fem50', 'fem55', 'fem60', 'fem65', 'fem70', 'fem75', 'fem80', 'fem85',
'SHAPE'],
dtype='object')When a data collection is specified without specific analysis variables, all variables under the data collection are used for enrichment as can be seen above.
Enrich with Health data collection
Here we see a zip code being enriched by data from Health data collection.
redlands = usa.subgeographies.states['California'].zip5['92373']redlands_df = enrich(study_areas=[redlands], data_collections=['Health'] )redlands_df| std_geography_level | std_geography_name | std_geography_id | source_country | aggregation_method | population_to_polygon_size_rating | apportionment_confidence | has_data | rel65_hi2_oc | acscivnins | ... | pop85_cy | pop18up_cy | pop21up_cy | medage_cy | hhu18_c10 | medhinc_cy | s27_bus | s27_sales | s27_emp | SHAPE | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | US.ZIP5 | Redlands | 92373 | US | Query:US.ZIP5 | 2.191 | 2.576 | 1 | 1.0 | 32904.0 | ... | 1409.0 | 28175.0 | 27097.0 | 41.8 | 3805.0 | 105863.0 | 245.0 | 418153000.0 | 5296.0 | {"rings": [[[-117.12524300001411, 34.027986999... |
1 rows × 431 columns
redlands_df.columnsIndex(['std_geography_level', 'std_geography_name', 'std_geography_id',
'source_country', 'aggregation_method',
'population_to_polygon_size_rating', 'apportionment_confidence',
'has_data', 'rel65_hi2_oc', 'acscivnins',
...
'pop85_cy', 'pop18up_cy', 'pop21up_cy', 'medage_cy', 'hhu18_c10',
'medhinc_cy', 's27_bus', 's27_sales', 's27_emp', 'SHAPE'],
dtype='object', length=431)Enrich using Analysis Variables
Data can be enriched by specifying specific analysis variables of a data collection with which we want to enrich our data. In this example, we will look at analysis_variables for Age data_collection and then use specific analysis variables to enrich() a study area.
# Unique analysis variables for Age data collection
usa = Country.get('US')
usa.data_collections.loc['Age']['analysisVariable'].unique()array(['Age.MALE0', 'Age.MALE5', 'Age.MALE10', 'Age.MALE15', 'Age.MALE20',
'Age.MALE25', 'Age.MALE30', 'Age.MALE35', 'Age.MALE40',
'Age.MALE45', 'Age.MALE50', 'Age.MALE55', 'Age.MALE60',
'Age.MALE65', 'Age.MALE70', 'Age.MALE75', 'Age.MALE80',
'Age.MALE85', 'Age.FEM0', 'Age.FEM5', 'Age.FEM10', 'Age.FEM15',
'Age.FEM20', 'Age.FEM25', 'Age.FEM30', 'Age.FEM35', 'Age.FEM40',
'Age.FEM45', 'Age.FEM50', 'Age.FEM55', 'Age.FEM60', 'Age.FEM65',
'Age.FEM70', 'Age.FEM75', 'Age.FEM80', 'Age.FEM85'], dtype=object)Now, we will enrich our study area with Age.FEM45, Age.FEM55, Age.FEM65 variables
enrich(study_areas=["380 New York St Redlands CA 92373"],
analysis_variables=["Age.FEM45","Age.FEM55","Age.FEM65"])| source_country | x | y | area_type | buffer_units | buffer_units_alias | buffer_radii | aggregation_method | population_to_polygon_size_rating | apportionment_confidence | has_data | fem45 | fem55 | fem65 | SHAPE | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | US | -117.194835 | 34.057242 | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 1 | 381.0 | 323.0 | 281.0 | {"rings": [[[-117.194835113918, 34.07175043587... |
Enriching Spatially Enabled Dataframes
One of the most common use case for GeoEnrichment is enriching existing data in feature layers. As a user, you may need to analyze and enrich your data that already exists in feature layers. Spatially Enabled DataFrame (SeDF) helps us bring the data from layer into a dataframe which can then be GeoEnriched.
Let's look at an example using an existing layer of Covid-19 dataset. This feature layer includes latest Covid-19 Cases, Recovered and Deaths data for U.S. at the county level.
# Get the layer
gis = GIS(set_active=False)
covid_item = gis.content.get('628578697fb24d8ea4c32fa0c5ae1843')
print(covid_item)
covid_layer = covid_item.layers[0]
covid_layer<Item title:"COVID-19 Cases US" type:Feature Layer Collection owner:CSSE_covid19>
<FeatureLayer url:"https://services1.arcgis.com/0MSEUqKaxRlEPj5g/arcgis/rest/services/ncov_cases_US/FeatureServer/0">
We can query the layer as a dataframe and then use the dataframe for enrichment.
covid_df = covid_layer.query(as_df=True)
covid_df.shape(3272, 19)
covid_df.head()| OBJECTID | Province_State | Country_Region | Last_Update | Lat | Long_ | Confirmed | Recovered | Deaths | Active | Admin2 | FIPS | Combined_Key | Incident_Rate | People_Tested | People_Hospitalized | UID | ISO3 | SHAPE | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | 1 | Alabama | US | 2023-03-10 13:21:02 | 32.539527 | -86.644082 | 19790 | <NA> | 232 | <NA> | Autauga | 01001 | Autauga, Alabama, US | 35422.14824 | <NA> | <NA> | 84001001 | USA | {"x": -86.64408226999996, "y": 32.539527450000... |
| 1 | 2 | Alabama | US | 2023-03-10 13:21:02 | 30.72775 | -87.722071 | 69860 | <NA> | 727 | <NA> | Baldwin | 01003 | Baldwin, Alabama, US | 31294.516068 | <NA> | <NA> | 84001003 | USA | {"x": -87.72207057999998, "y": 30.727749910000... |
| 2 | 3 | Alabama | US | 2023-03-10 13:21:02 | 31.868263 | -85.387129 | 7485 | <NA> | 103 | <NA> | Barbour | 01005 | Barbour, Alabama, US | 30320.82962 | <NA> | <NA> | 84001005 | USA | {"x": -85.38712859999998, "y": 31.868263000000... |
| 3 | 4 | Alabama | US | 2023-03-10 13:21:02 | 32.996421 | -87.125115 | 8091 | <NA> | 109 | <NA> | Bibb | 01007 | Bibb, Alabama, US | 36130.21345 | <NA> | <NA> | 84001007 | USA | {"x": -87.12511459999996, "y": 32.996420640000... |
| 4 | 5 | Alabama | US | 2023-03-10 13:21:02 | 33.982109 | -86.567906 | 18704 | <NA> | 261 | <NA> | Blount | 01009 | Blount, Alabama, US | 32345.311797 | <NA> | <NA> | 84001009 | USA | {"x": -86.56790592999994, "y": 33.982109180000... |
To showcase GeoEnrichment, we will create a subset of the original data and then enrich() the subset.
# Create subset
test_df = covid_df.iloc[:100].copy()
test_df.shape(100, 19)
# Check geometry
test_df.spatial.geometry_type['point', None]
A dataframe can be passed as a value to study_areas parameter of the enrich() method. Here we are enriching our dataframe with specific variables from Age data collection.
# Enrich dataframe
new_df = enrich(study_areas=test_df.spatial,
analysis_variables=["Age.FEM45","Age.FEM55","Age.FEM65"])new_df.head()| source_country | area_type | buffer_units | buffer_units_alias | buffer_radii | aggregation_method | population_to_polygon_size_rating | apportionment_confidence | has_data | fem45 | fem55 | fem65 | SHAPE | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 0 | US | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 1 | 5.0 | 5.0 | 5.0 | {"rings": [[[-86.64408226999996, 32.5540396153... |
| 1 | US | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 1 | 0.0 | 0.0 | 0.0 | {"rings": [[[-87.72207057999998, 30.7422661988... |
| 2 | US | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 1 | 2.0 | 2.0 | 3.0 | {"rings": [[[-85.38712859999997, 31.8827767082... |
| 3 | US | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 0 | 0.0 | 0.0 | 0.0 | {"rings": [[[-87.12511459999996, 33.0109317454... |
| 4 | US | RingBuffer | esriMiles | Miles | 1.0 | BlockApportionment:US.BlockGroups;PointsLayer:... | 2.191 | 2.576 | 1 | 7.0 | 8.0 | 5.0 | {"rings": [[[-86.56790592999992, 33.9966179736... |
new_df.columnsIndex(['source_country', 'area_type', 'buffer_units', 'buffer_units_alias',
'buffer_radii', 'aggregation_method',
'population_to_polygon_size_rating', 'apportionment_confidence',
'has_data', 'fem45', 'fem55', 'fem65', 'SHAPE'],
dtype='object')# Check shape
new_df.shape(97, 13)
We can see that enrichment resulted in 97 records and 13 columns. There are some areas in our dataframe for which enrichment information is not available. Hence, we have 97 records instead of 100.
Visualize on a Map
Let's visualize the enriched dataframe on a map. We will use FEM65 column to classify our data for plotting on the map.
covid_map = gis.map('Alabama, USA')
covid_map
# Plot on a map
new_df.spatial.plot(covid_map)True
covid_map.basemap.basemap = 'arcgis-light-gray'Conclusion
In this part of the arcgis.geoenrichment module guide series, you saw how data_collections property of a Country object lists its available data_collections and analysis_variables. You explored different data collections, their analysis variables and then enriched study areas using the same. Towards the end, you experienced how spatially enabled dataframes can be enriched.
In the subsequent pages, you will learn about Generating Reports and Standard Geography Queries.
