Layers

Maps and scenes use a collection of layers to display geographic data from a variety of sources and formats. These can include several basemap layers and data layers from online or local sources.

Each layer in a map references geographic data, either from an online service or from a local dataset. There are a variety of layers that can be added to a map, each designed to display a particular type of data. Some layers display images, such as satellite photos or aerial photography, others are composed of a collection of features to represent real-world entities using point, line, or polygon geometries. In addition to geometry, features have attributes that provide details about the entity it represents.

Basemap layers

A basemap layer is a layer that provides the overall visual context for a map or scene. It typically contains geographic features such as continents, lakes, administrative boundaries, streets, cities, and place names. These features are represented with different styles provided by the basemap layer service such as streets, topographic, and imagery. The style you choose depends on the type of application and the visualization you would like to create.

A basemap layer provides the visual foundation for a mapping application. It typically contains data with global coverage and is the first layer added to a map or scene. The main data source for a basemap layer is the basemap layer service. When a view displays a map, a basemap layer is the first layer to draw, followed by data layers, and then graphics.

The Basemap layer service provides a number of vector tile and image tile basemap layers that you can use to build different types of mapping applications. Each of the basemap layer styles is defined in an enumeration. For example, you can use the Navigation style to create an application that supports driving directions, or you can use Imagery to create an application that displays a real-world view of the earth.

Add a vector tile basemap

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
// Fix blank line

ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);

FeatureLayer trailheadsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trailheads_Styled/FeatureServer/0"));

FeatureLayer trailsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trails_Styled/FeatureServer/0"));

FeatureLayer openSpacesLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Parks_and_Open_Space_Styled/FeatureServer/0"));

map.getOperationalLayers().addAll(Arrays.asList(openSpacesLayer, trailsLayer, trailheadsLayer));



ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);

FeatureLayer trailheadsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trailheads_Styled/FeatureServer/0"));

FeatureLayer trailsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trails_Styled/FeatureServer/0"));

FeatureLayer openSpacesLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Parks_and_Open_Space_Styled/FeatureServer/0"));

scene.getOperationalLayers().addAll(Arrays.asList(openSpacesLayer, trailsLayer, trailheadsLayer));


// ----- Basemap layer ----- //


ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_NAVIGATION);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_LIGHT_GRAY);
//ArcGISMap map = new ArcGISMap(BasemapStyle.OSM_LIGHT_GRAY);



ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_IMAGERY_STANDARD);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_HILLSHADE_LIGHT);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_HILLSHADE_DARK);


// -- ENC --


// set the path to the ENC resource directory
EncEnvironmentSettings.setResourcePath("path/to/hydrography");

// set the path to the directory used for processing cell data
EncEnvironmentSettings.setSencDataPath("path/to/sencDataPath");


// create a new exchange set
encExchangeSet =
  new EncExchangeSet(new ArrayList<>(Arrays.asList("../Data/ENC_ROOT/CATALOG.031")));

// load the exchange set
encExchangeSet.loadAsync();

// Asynchronous code run when exchange set loaded
encExchangeSet.addDoneLoadingListener(() -> {
  //loop through the datasets and add to the map
  for (EncDataset encDataset : encExchangeSet.getDatasets()) {
    EncLayer encLayer = new EncLayer(new EncCell(encDataset));
    map.getOperationalLayers().add(encLayer);
  }
});


EncExchangeSet encExchangeSetUpdate =
  new EncExchangeSet(new ArrayList<>(Arrays.asList("path/to/update", "path/to/original")));


// Enables display of seabed information for all ENC layers
EncEnvironmentSettings.getDisplaySettings().getTextGroupVisibilitySettings().setIsNatureOfSeabed(true);


// Perform an identify operation on the enc layer (you may want to loop through all layers)
ListenableFuture identifyLayerResultFuture =
  mapView.identifyLayerAsync(encLayerToIdentify, clickedPoint, 10, false);

// wait for the result
identifyLayerResultFuture.addDoneListener(() -> {
  try {
    // get the result
    IdentifyLayerResult identifyLayerResult = identifyLayerResultFuture.get();

    for (GeoElement geoElement : identifyLayerResult.getElements()) {
      // is it an enc feature?
      if (geoElement instanceof EncFeature) {
        EncFeature encFeature = (EncFeature) geoElement;

        // select the feature
        encLayerToIdentify.selectFeature(encFeature);
      }
    }

  } catch (InterruptedException e1) {
    e1.printStackTrace();
  } catch (ExecutionException e1) {
    e1.printStackTrace();
  }
});
Add an image tile basemap

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
// Fix blank line

ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);

FeatureLayer trailheadsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trailheads_Styled/FeatureServer/0"));

FeatureLayer trailsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trails_Styled/FeatureServer/0"));

FeatureLayer openSpacesLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Parks_and_Open_Space_Styled/FeatureServer/0"));

map.getOperationalLayers().addAll(Arrays.asList(openSpacesLayer, trailsLayer, trailheadsLayer));



ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);

FeatureLayer trailheadsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trailheads_Styled/FeatureServer/0"));

FeatureLayer trailsLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Trails_Styled/FeatureServer/0"));

FeatureLayer openSpacesLayer = new FeatureLayer(new ServiceFeatureTable("https://services3.arcgis.com/GVgbJbqm8hXASVYi/arcgis/rest/services/Parks_and_Open_Space_Styled/FeatureServer/0"));

scene.getOperationalLayers().addAll(Arrays.asList(openSpacesLayer, trailsLayer, trailheadsLayer));


// ----- Basemap layer ----- //


ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_NAVIGATION);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_TOPOGRAPHIC);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_LIGHT_GRAY);
//ArcGISMap map = new ArcGISMap(BasemapStyle.OSM_LIGHT_GRAY);



ArcGISRuntimeEnvironment.setApiKey("YOUR_API_KEY");

ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_IMAGERY_STANDARD);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_HILLSHADE_LIGHT);
//ArcGISMap map = new ArcGISMap(BasemapStyle.ARCGIS_HILLSHADE_DARK);


// -- ENC --


// set the path to the ENC resource directory
EncEnvironmentSettings.setResourcePath("path/to/hydrography");

// set the path to the directory used for processing cell data
EncEnvironmentSettings.setSencDataPath("path/to/sencDataPath");


// create a new exchange set
encExchangeSet =
  new EncExchangeSet(new ArrayList<>(Arrays.asList("../Data/ENC_ROOT/CATALOG.031")));

// load the exchange set
encExchangeSet.loadAsync();

// Asynchronous code run when exchange set loaded
encExchangeSet.addDoneLoadingListener(() -> {
  //loop through the datasets and add to the map
  for (EncDataset encDataset : encExchangeSet.getDatasets()) {
    EncLayer encLayer = new EncLayer(new EncCell(encDataset));
    map.getOperationalLayers().add(encLayer);
  }
});


EncExchangeSet encExchangeSetUpdate =
  new EncExchangeSet(new ArrayList<>(Arrays.asList("path/to/update", "path/to/original")));


// Enables display of seabed information for all ENC layers
EncEnvironmentSettings.getDisplaySettings().getTextGroupVisibilitySettings().setIsNatureOfSeabed(true);


// Perform an identify operation on the enc layer (you may want to loop through all layers)
ListenableFuture identifyLayerResultFuture =
  mapView.identifyLayerAsync(encLayerToIdentify, clickedPoint, 10, false);

// wait for the result
identifyLayerResultFuture.addDoneListener(() -> {
  try {
    // get the result
    IdentifyLayerResult identifyLayerResult = identifyLayerResultFuture.get();

    for (GeoElement geoElement : identifyLayerResult.getElements()) {
      // is it an enc feature?
      if (geoElement instanceof EncFeature) {
        EncFeature encFeature = (EncFeature) geoElement;

        // select the feature
        encLayerToIdentify.selectFeature(encFeature);
      }
    }

  } catch (InterruptedException e1) {
    e1.printStackTrace();
  } catch (ExecutionException e1) {
    e1.printStackTrace();
  }
});

Data layers

A data layer, also known as an operational layer, is a layer that can access geographic data from a data source. You use a data layer to display geographic data on top of a basemap layer in a map or scene. The data source for the layer can be a data service or a file such as a shapefile or GeoPackage.

A data layer provides access to geographic data that is displayed in a map or scene. Each layer references a file or service data source. The data source contains either as vector data (points, lines, polygons and attributes) or raster data (images). Different types of layers can access and display different types of data.

The data for a data layer is typically stored in the ArcGIS Platform as a data service. You can use feature services, vector tile services, and image tile services to host your data. Learn more in Data hosting.

A data layer can also be created from a dataset stored on the device. For example, data stored in a shapefile, mobile map package, or geodatabase. Learn more about using offline data in Offline maps, scenes, and data.

To add a data layer to a map or scene, you typically add imagery or tile layers first, and then polygons, lines, and points layers last. A map or scene controls the order of the layers, and the map or scene view combines the layers to create the final display.

Add data layers to a map
