Add dynamic entity layer

// [WriteFile Name=AddDynamicEntityLayer, Category=Layers]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "AddDynamicEntityLayer.h"

// ArcGIS Maps SDK headers
#include "ArcGISStreamService.h"
#include "ArcGISStreamServiceFilter.h"
#include "CalloutData.h"
#include "DynamicEntity.h"
#include "DynamicEntityChangedInfo.h"
#include "DynamicEntityDataSourcePurgeOptions.h"
#include "DynamicEntityLayer.h"
#include "DynamicEntityObservation.h"
#include "Envelope.h"
#include "Graphic.h"
#include "GraphicListModel.h"
#include "GraphicsOverlay.h"
#include "GraphicsOverlayListModel.h"
#include "IdentifyLayerResult.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Point.h"
#include "RealTimeTypes.h"
#include "SimpleLineSymbol.h"
#include "SimpleMarkerSymbol.h"
#include "SimpleRenderer.h"
#include "SpatialReference.h"
#include "SymbolTypes.h"
#include "TrackDisplayProperties.h"
#include "UniqueValue.h"
#include "UniqueValueRenderer.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>

using namespace Esri::ArcGISRuntime;

namespace
{
// This envelope is a limited region around Sandy, Utah. It will be the extent used by the `DynamicEntityFilter`.
const Envelope utahSandyEnvelope(
    Point(-112.110052, 40.718083, SpatialReference::wgs84()),
    Point(-111.814782, 40.535247, SpatialReference::wgs84()));
}

AddDynamicEntityLayer::AddDynamicEntityLayer(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISDarkGray, this))
{
  // Create a dynamic entity data source from a given URL
  const QUrl streamServiceUrl("https://realtimegis2016.esri.com:6443/arcgis/rest/services/SandyVehicles/StreamServer");
  m_dynamicEntityDataSource = new ArcGISStreamService(streamServiceUrl, this);

  // Create and set an ArcGISStreamServiceFilter to filter what data is received from the server
  ArcGISStreamServiceFilter* streamServiceFilter = new ArcGISStreamServiceFilter(this);
  streamServiceFilter->setGeometry(utahSandyEnvelope);
  streamServiceFilter->setWhereClause("speed > 0");
  m_dynamicEntityDataSource->setFilter(streamServiceFilter);

  // Set purge options to manage when entities are removed from the cache
  m_dynamicEntityDataSource->purgeOptions()->setMaximumDuration(300.0 /*seconds*/);

  // Handle signals emitted when connection status changes to update the UI
  connect(m_dynamicEntityDataSource, &ArcGISStreamService::connectionStatusChanged, this, &AddDynamicEntityLayer::connectionStatusChanged);

  // Create a dynamic entity layer to display on the map and set the properties
  m_dynamicEntityLayer = new DynamicEntityLayer(m_dynamicEntityDataSource, this);

  // Set the track display properties to change what is displayed to the user
  m_dynamicEntityLayer->trackDisplayProperties()->setShowTrackLine(true);
  m_dynamicEntityLayer->trackDisplayProperties()->setShowPreviousObservations(true);

  // Create renderers for observations and their tracklines to change how they are styled

  // Create a unique value renderer for the latest observations
  QList<UniqueValue*> entityValues;
  entityValues.append(new UniqueValue("","", {3}, new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::magenta, 8, this), this));
  entityValues.append(new UniqueValue("","", {4}, new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::green, 8, this), this));

  UniqueValueRenderer* entityRenderer = new UniqueValueRenderer("", new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::blue, 8, this), {"agency"}, entityValues, this);
  m_dynamicEntityLayer->setRenderer(entityRenderer);

  // Create a unique value renderer for the previous observations
  QList<UniqueValue*> previousObservationValues;

  previousObservationValues.append(new UniqueValue("","", {3}, new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::magenta, 3, this), this));
  previousObservationValues.append(new UniqueValue("","", {4}, new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::green, 3, this), this));

  UniqueValueRenderer* trackRenderer = new UniqueValueRenderer("", new SimpleMarkerSymbol(SimpleMarkerSymbolStyle::Circle, Qt::blue, 3, this), {"agency"}, previousObservationValues);
  m_dynamicEntityLayer->trackDisplayProperties()->setPreviousObservationRenderer(trackRenderer);

  // Use a simple renderer to change the style of the trackline
  m_dynamicEntityLayer->trackDisplayProperties()->setTrackLineRenderer(new SimpleRenderer(new SimpleLineSymbol(SimpleLineSymbolStyle::Solid, Qt::lightGray, 2, this)));

  m_map->operationalLayers()->append(m_dynamicEntityLayer);
}

AddDynamicEntityLayer::~AddDynamicEntityLayer() = default;

void AddDynamicEntityLayer::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<AddDynamicEntityLayer>("Esri.Samples", 1, 0, "AddDynamicEntityLayerSample");
}

MapQuickView* AddDynamicEntityLayer::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void AddDynamicEntityLayer::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  // Create and show a dashed line around the filter area
  GraphicsOverlay* borderOverlay = new GraphicsOverlay(this);
  borderOverlay->graphics()->append(new Graphic(utahSandyEnvelope, new SimpleLineSymbol(SimpleLineSymbolStyle::Dash, Qt::red, 2, this), this));
  m_mapView->graphicsOverlays()->append(borderOverlay);

  // Set the initial viewpoint to this area
  m_mapView->setViewpointAndWait(Viewpoint(utahSandyEnvelope));

  // Create a slot to listen for mouse clicks
  connect(m_mapView, &MapQuickView::mouseClicked, this, &AddDynamicEntityLayer::identifyLayerAtMouseClick);

  emit mapViewChanged();
}

void AddDynamicEntityLayer::setObservationsPerTrack(int observationsPerTrack)
{
  // Update the number of entity observations displayed using the value from the UI slider
  m_dynamicEntityLayer->trackDisplayProperties()->setMaximumObservations(observationsPerTrack);
}

void AddDynamicEntityLayer::showTrackLines(bool showTrackLines)
{
  // Show or hide the lines that connect previous observations
  m_dynamicEntityLayer->trackDisplayProperties()->setShowTrackLine(showTrackLines);
}

void AddDynamicEntityLayer::showPreviousObservations(bool showPreviousObservations)
{
  // Show or hide previous observations (if maximum observations is greater than 1)
  m_dynamicEntityLayer->trackDisplayProperties()->setShowPreviousObservations(showPreviousObservations);
}

QString AddDynamicEntityLayer::connectionStatus() const
{
  // Return the current dynamic entity data source connection status as a string to display in the UI
  switch (m_dynamicEntityDataSource->connectionStatus())
  {
    case ConnectionStatus::Disconnected:
      return "Disconnected";
    case ConnectionStatus::Connecting:
      return "Connecting";
    case ConnectionStatus::Connected:
      return "Connected";
    case ConnectionStatus::Failed:
      return "Failed";
    default:
      return "Unknown";
  }
}

void AddDynamicEntityLayer::enableDisableConnection()
{
  // Handle the UI connection switch and disable or enable connection
  switch (m_dynamicEntityDataSource->connectionStatus())
  {
    case ConnectionStatus::Disconnected:
    {
      auto future = m_dynamicEntityDataSource->connectDataSourceAsync();
      Q_UNUSED(future)
      break;
    }
    case ConnectionStatus::Connecting:
      // Do nothing and allow data source to finish connecting
      break;
    case ConnectionStatus::Connected:
    {
      auto future = m_dynamicEntityDataSource->disconnectDataSourceAsync();
      Q_UNUSED(future)
      break;
    }
    case ConnectionStatus::Failed:
      qWarning() << "Unable to connect to dynamic entity data source";
      break;
    default:
      break;
  }
}

void AddDynamicEntityLayer::purgeAllObservations()
{
  // Remove all current observations from the cache
  auto future = m_dynamicEntityDataSource->purgeAllAsync();
  Q_UNUSED(future)
}

void AddDynamicEntityLayer::identifyLayerAtMouseClick(const QMouseEvent& e)
{
  // Hide the callout (if it is already hidden this will do nothing)
  m_mapView->calloutData()->setVisible(false);

  m_mapView->identifyLayerAsync(m_dynamicEntityLayer, e.position(), 5, false, this)
      .then(this, [this](IdentifyLayerResult* result)
  {
    if (!result || result->geoElements().empty())
    {
      return;
    }

    if (DynamicEntityObservation* observation = dynamic_cast<DynamicEntityObservation*>(result->geoElements().constFirst()); observation)
    {
      DynamicEntity* dynamicEntity = observation->dynamicEntity();
      if (!dynamicEntity)
      {
        return;
      }
      m_mapView->calloutData()->setGeoElement(dynamicEntity);
      // Create a arcade expression for title to display the dynamic entity's attributes in the callout.
      const QString titleExpression = "concatenate($feature.vehiclename, \": \", $feature.speed, \" mph\")";
      m_mapView->calloutData()->setTitleExpression(titleExpression);

      // Create a arcade expression for detail to display the dynamic entity's attributes in the callout.
      const QString detailExpression = "concatenate(Round($feature.point_x,6), \",\", Round($feature.point_y,6),\" Heading: \",$feature.heading,\"°\")";
      m_mapView->calloutData()->setDetailExpression(detailExpression);

      // Show the callout when the title is available.
      connect(m_mapView->calloutData(), &CalloutData::titleChanged, this, [this]()
      {
        m_mapView->calloutData()->setVisible(true);
      }, Qt::SingleShotConnection);
    }
  });
}

// [WriteFile Name=AddDynamicEntityLayer, Category=Layers]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef ADDDYNAMICENTITYLAYER_H
#define ADDDYNAMICENTITYLAYER_H

// Qt headers
#include <QObject>

namespace Esri::ArcGISRuntime
{
class ArcGISStreamService;
class DynamicEntityLayer;
class Map;
class MapQuickView;
}

class QMouseEvent;

Q_MOC_INCLUDE("MapQuickView.h");

class AddDynamicEntityLayer : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)
  Q_PROPERTY(QString connectionStatus READ connectionStatus NOTIFY connectionStatusChanged)

public:
  explicit AddDynamicEntityLayer(QObject* parent = nullptr);
  ~AddDynamicEntityLayer() override;

  static void init();

  Q_INVOKABLE void purgeAllObservations();
  Q_INVOKABLE void setObservationsPerTrack(int observationsPerTrack);
  Q_INVOKABLE void showTrackLines(bool showTrackLines);
  Q_INVOKABLE void showPreviousObservations(bool showPreviousObservations);
  Q_INVOKABLE void enableDisableConnection();

signals:
  void mapViewChanged();
  void connectionStatusChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);

  QString connectionStatus() const;

  void identifyLayerAtMouseClick(const QMouseEvent& e);

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;

  Esri::ArcGISRuntime::ArcGISStreamService* m_dynamicEntityDataSource = nullptr;
  Esri::ArcGISRuntime::DynamicEntityLayer* m_dynamicEntityLayer = nullptr;
};

#endif // ADDDYNAMICENTITYLAYER_H

// [WriteFile Name=AddDynamicEntityLayer, Category=Layers]
// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples
import Esri.ArcGISRuntime.Toolkit

Item {
    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set and keep the focus on MapView to enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    AddDynamicEntityLayerSample {
        id: model
        mapView: view
        onConnectionStatusChanged: {
            // Enable switch if data stream is successfully disconnected or connected
            statusSwitch.enabled = (["Disconnected", "Connected"].indexOf(model.connectionStatus) !== -1)
        }
    }

    Callout {
        id: callout
        height: 60
        calloutData: view.calloutData
        accessoryButtonVisible: false
    }

    Rectangle {
        id: dynamicEntityLayerOptions
        anchors {
            top: parent.top
            right: parent.right
            margins: 10
        }
        width: (300 < parent.width - 20) ? 300 : parent.width - 20
        height: column.height + 20
        border.width: 1

        // Catch mouse signals so they don't propagate to the map
        MouseArea {
            anchors.fill: parent
            onClicked: mouse => mouse.accepted = true
            onWheel: wheel => wheel.accepted = true
        }

        Column {
            id: column
            anchors {
                top: parent.top
                left: parent.left
                right: parent.right
                margins: 10
            }

            Text {
                id: statusText
                anchors.horizontalCenter: parent.horizontalCenter
                text: "Status: " + model.connectionStatus
                font.pixelSize: 18
                horizontalAlignment: Text.AlignHCenter
                font.bold: true
            }

            Switch {
                id: statusSwitch
                anchors.horizontalCenter: parent.horizontalCenter
                checked: model.connectionStatus !== "Disconnected"
                onCheckedChanged: {
                    model.enableDisableConnection();
                    // Calls either of the following depending on the state
                    // m_dynamicEntityDataSource->connectDataSource();
                    // m_dynamicEntityDataSource->disconnectDataSource();
                }
            }

            CheckBox {
                id: trackLinesBox
                text: "Track lines"
                checked: true
                onCheckedChanged: {
                    model.showTrackLines(checked);
                    // Calls m_dynamicEntityLayer->trackDisplayProperties()->setShowTrackLine(showTrackLines);
                }
            }


            CheckBox {
                id: previousObservationsBox
                text: "Previous observations"
                checked: true
                onCheckedChanged: {
                    model.showPreviousObservations(checked);
                    // Calls m_dynamicEntityLayer->trackDisplayProperties()->setShowPreviousObservations(showPreviousObservations);
                }
            }

            Text {
                id: observationsSliderText
                topPadding: 10
                text: "Observations per track (" + observationsSlider.value + ")"
            }

            Slider {
                id: observationsSlider
                anchors {
                    left: parent.left
                    right: parent.right
                }
                value: 5
                stepSize: 1
                from: 1
                to: 16
                onValueChanged: {
                    model.setObservationsPerTrack(value)
                    // Calls m_dynamicEntityLayer->trackDisplayProperties()->setMaximumObservations(observationsPerTrack);
                }
            }

            Button {
                id: purgeButton
                anchors.horizontalCenter: parent.horizontalCenter
                text: "Purge all observations"
                onClicked: {
                    callout.visible = false;
                    model.purgeAllObservations();
                    // Calls m_dynamicEntityDataSource->purgeAll();
                }
            }
        }
    }
}

// [Legal]
// Copyright 2023 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "AddDynamicEntityLayer.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("AddDynamicEntityLayer"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  AddDynamicEntityLayer::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  // Set the source
  engine.load(QUrl("qrc:/Samples/Layers/AddDynamicEntityLayer/main.qml"));

  return app.exec();
}

// Copyright 2023 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    AddDynamicEntityLayer {
        anchors.fill: parent
    }
}
