Stretch renderer

// [WriteFile Name=RasterRgbRenderer, Category=Layers]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls

Row {
    anchors.horizontalCenter: parent.horizontalCenter

    property alias maxRange : slider.to
    property alias value: slider.value
    property alias label: text.text

    Text {
        id: text
    }

    Slider {
        id: slider
        width: 100
        from: 0
        to: maxRange

        onValueChanged: {
            if (spinBox.value !== value)
                spinBox.value = value;
        }
    }

    SpinBox {
        id: spinBox
        from: 0
        to: slider.to

        onValueChanged: {
            if (slider.value !== value)
                slider.value = value;
        }
    }
}

// [WriteFile Name=RasterStretchRenderer, Category=Layers]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "RasterStretchRenderer.h"

// ArcGIS Maps SDK headers
#include "Basemap.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapViewTypes.h"
#include "MinMaxStretchParameters.h"
#include "PercentClipStretchParameters.h"
#include "Raster.h"
#include "RasterLayer.h"
#include "StandardDeviationStretchParameters.h"
#include "StretchRenderer.h"

// Qt headers
#include <QStandardPaths>
#include <QtCore/qglobal.h>

using namespace Esri::ArcGISRuntime;

// helper method to get cross platform data path
namespace
{
  QString defaultDataPath()
  {
    QString dataPath;

  #ifdef Q_OS_IOS
    dataPath = QStandardPaths::writableLocation(QStandardPaths::DocumentsLocation);
  #else
    dataPath = QStandardPaths::writableLocation(QStandardPaths::HomeLocation);
  #endif

    return dataPath;
  }
} // namespace

RasterStretchRenderer::RasterStretchRenderer(QQuickItem* parent /* = nullptr */):
  QQuickItem(parent),
  m_dataPath(defaultDataPath() + "/ArcGIS/Runtime/Data/raster")
{
}

RasterStretchRenderer::~RasterStretchRenderer() = default;

void RasterStretchRenderer::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<RasterStretchRenderer>("Esri.Samples", 1, 0, "RasterStretchRendererSample");
}

void RasterStretchRenderer::componentComplete()
{
  QQuickItem::componentComplete();

  // find QML MapView component
  m_mapView = findChild<MapQuickView*>("mapView");
  m_mapView->setWrapAroundMode(WrapAroundMode::Disabled);

  // Create the raster and raster layer
  Raster* raster = new Raster(m_dataPath + "/Shasta.tif", this);
  m_rasterLayer = new RasterLayer(raster, this);

  // Add the raster to the map
  Basemap* basemap = new Basemap(m_rasterLayer, this);
  Map* map = new Map(basemap, this);
  m_mapView->setMap(map);
}

//! [RasterStretchRenderer cpp set renderers]
void RasterStretchRenderer::applyMinMax(double min, double max)
{
  MinMaxStretchParameters stretchParams(QList<double>{min}, QList<double>{max});
  QList<double> gammas;
  bool estimateStats = true;
  StretchRenderer* renderer = new StretchRenderer(stretchParams, gammas, estimateStats, PresetColorRampType::None, this);

  m_rasterLayer->setRenderer(renderer);
}

void RasterStretchRenderer::applyPercentClip(double min, double max)
{
  PercentClipStretchParameters stretchParams(min, max);
  QList<double> gammas;
  bool estimateStats = true;
  StretchRenderer* renderer = new StretchRenderer(stretchParams, gammas, estimateStats, PresetColorRampType::None, this);

  m_rasterLayer->setRenderer(renderer);
}

void RasterStretchRenderer::applyStandardDeviation(double factor)
{
  StandardDeviationStretchParameters stretchParams(factor);
  QList<double> gammas;
  bool estimateStats = true;
  StretchRenderer* renderer = new StretchRenderer(stretchParams, gammas, estimateStats, PresetColorRampType::None, this);

  m_rasterLayer->setRenderer(renderer);
}
//! [RasterStretchRenderer cpp set renderers]

// [WriteFile Name=RasterStretchRenderer, Category=Layers]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef STRETCHRENDERER_H
#define STRETCHRENDERER_H

// Qt headers
#include <QQuickItem>

namespace Esri::ArcGISRuntime
{
  class Map;
  class MapQuickView;
  class RasterLayer;
}

class RasterStretchRenderer : public QQuickItem
{
  Q_OBJECT

public:
  explicit RasterStretchRenderer(QQuickItem* parent = nullptr);
  ~RasterStretchRenderer() override;

  static void init();

  void componentComplete() override;

  Q_INVOKABLE void applyMinMax(double min, double max);
  Q_INVOKABLE void applyPercentClip(double min, double max);
  Q_INVOKABLE void applyStandardDeviation(double factor);

private:
  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::RasterLayer* m_rasterLayer = nullptr;
  QString m_dataPath;
};

#endif // STRETCHRENDERER_H

// [WriteFile Name=RasterStretchRenderer, Category=Layers]
// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

RasterStretchRendererSample {
    id: rootRectangle
    clip: true
    width: 800
    height: 600

    readonly property string minMax: "Min Max"
    readonly property string percentClip: "Percent Clip"
    readonly property string stdDeviation: "Standard Deviation"
    readonly property var stretchTypes: [minMax, percentClip, stdDeviation]
    property bool editingRenderer: false

    // add a mapView component
    MapView {
        anchors.fill: parent
        objectName: "mapView"

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    Rectangle {
        visible: editButton.visible
        anchors.centerIn: editButton
        radius: 8
        height: editButton.height + (16)
        width: editButton.width + (16)
        color: "lightgrey"
        border.color: "darkgrey"
        border.width: 2
        opacity: 0.75
    }

    Button {
        id: editButton
        anchors {
            bottom: parent.bottom
            horizontalCenter: parent.horizontalCenter
            margins: 32
        }
        visible: rendererBox.width === 0
        text: "Edit Renderer"
        onClicked: editingRenderer = true;
    }

    Rectangle {
        id: rendererBox
        clip: true
        anchors {
            right: parent.right
            top: parent.top
            bottom: parent.bottom
        }

        color: "white"
        opacity: 0.75
        width: editingRenderer ? parent.width : 0

        Column {
            anchors {
                top: parent.top
                bottom: parent.bottom
                margins: 24
            }
            width: parent.width
            spacing: 16

            ComboBox {
                id: stretchTypeCombo
                anchors.horizontalCenter: parent.horizontalCenter
                model: stretchTypes
                property int modelWidth: 0
                width: modelWidth + leftPadding + rightPadding + (indicator ? indicator.width : 10)
                Component.onCompleted : {
                    for (let i = 0; i < model.length; ++i) {
                        metrics.text = model[i];
                        modelWidth = Math.max(modelWidth, metrics.width);
                    }
                }

                // Add a background to the ComboBox
                Rectangle {
                    anchors.fill: parent
                    radius: 10
                    // Make the rectangle visible if a dropdown indicator exists
                    // An indicator only exists if a theme is set
                    visible: parent.indicator
                    border.width: 1
                }

                TextMetrics {
                    id: metrics
                    font: stretchTypeCombo.font
                }
            }

            InputWithLabel {
                id: minMaxMin
                visible: stretchTypeCombo.currentText === minMax
                spacing: 8
                label: "min value"
                maxRange: 255
                value: 0
            }

            InputWithLabel {
                id: minMaxMax
                visible: stretchTypeCombo.currentText === minMax
                spacing: 8
                label: "max value"
                maxRange: 255
                value: 255
            }

            InputWithLabel {
                id: percentClipMin
                visible: stretchTypeCombo.currentText === percentClip
                spacing: 8
                label: "min value"
                maxRange: 100
                value: 0
            }

            InputWithLabel {
                id: percentClipMax
                visible: stretchTypeCombo.currentText === percentClip
                spacing: 8
                label: "max value"
                maxRange: 100
                value: 100
            }

            InputWithLabel {
                id: sdFactor
                visible: stretchTypeCombo.currentText === stdDeviation
                spacing: 8
                label: "factor"
                maxRange: 25
                value: 0
            }

            Button {
                text: "Render"
                anchors.horizontalCenter: parent.horizontalCenter
                onClicked: {
                    editingRenderer = false;
                    applyRendererSettings();
                }
            }
        }

        Behavior on width { PropertyAnimation { duration: 500 } }
    }

    function applyRendererSettings(){
        if (stretchTypeCombo.currentText === minMax){
            applyMinMax(minMaxMin.value, minMaxMax.value);
        }
        else if (stretchTypeCombo.currentText === percentClip){
            applyPercentClip(percentClipMin.value, 100 - percentClipMax.value);
        }
        else if (stretchTypeCombo.currentText === stdDeviation){
            applyStandardDeviation(sdFactor.value);
        }
    }
}

// [Legal]
// Copyright 2017 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "RasterStretchRenderer.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QCommandLineParser>
#include <QDir>
#include <QGuiApplication>
#include <QQmlEngine>
#include <QQuickView>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("RasterStretchRenderer"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  RasterStretchRenderer::init();

  // Initialize application view
  QQuickView view;
  view.setResizeMode(QQuickView::SizeRootObjectToView);

  // Add the import Path
  view.engine()->addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

 #if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
 #endif

  // Add the Runtime and Extras path
  view.engine()->addImportPath(arcGISRuntimeImportPath);

  // Set the source
  view.setSource(QUrl("qrc:/Samples/Layers/RasterStretchRenderer/RasterStretchRenderer.qml"));

  view.show();

  return app.exec();
}
