Display OGC API Feature Collection

// [WriteFile Name=DisplayOgcApiFeatureCollection, Category=Layers]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "DisplayOgcApiFeatureCollection.h"

// ArcGIS Maps SDK headers
#include "CoreTypes.h"
#include "FeatureLayer.h"
#include "GeodatabaseTypes.h"
#include "Geometry.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "OgcFeatureCollectionTable.h"
#include "QueryParameters.h"
#include "SimpleLineSymbol.h"
#include "SimpleRenderer.h"
#include "SymbolTypes.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>

using namespace Esri::ArcGISRuntime;

DisplayOgcApiFeatureCollection::DisplayOgcApiFeatureCollection(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISTopographic, this))
{
  const QUrl serviceUrl = QUrl("https://demo.ldproxy.net/daraa");
  const QString collectionId = "TransportationGroundCrv";
  m_ogcFeatureCollectionTable = new OgcFeatureCollectionTable(serviceUrl, collectionId, this);

  // FeatureRequestMode::ManualCache specifies that features from the server will be stored locally for display and querying
  // In this mode, ServiceFeatureTable::populateFromService() must be called to populate the local cache
  m_ogcFeatureCollectionTable->setFeatureRequestMode(FeatureRequestMode::ManualCache);

  // m_ogcFeatureCollectionTable->load() will be automatically called when added to a FeatureLayer
  m_featureLayer = new FeatureLayer(m_ogcFeatureCollectionTable, this);
  m_featureLayer->setRenderer(new SimpleRenderer(new SimpleLineSymbol(SimpleLineSymbolStyle::Solid, Qt::blue, 3, this), this));
  m_map->operationalLayers()->append(m_featureLayer);
}

DisplayOgcApiFeatureCollection::~DisplayOgcApiFeatureCollection() = default;

void DisplayOgcApiFeatureCollection::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<DisplayOgcApiFeatureCollection>("Esri.Samples", 1, 0, "DisplayOgcApiFeatureCollectionSample");
}

MapQuickView* DisplayOgcApiFeatureCollection::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void DisplayOgcApiFeatureCollection::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);
  m_mapView->setViewpointAsync(Viewpoint(32.62, 36.10, 20'000));

  createQueryConnection();

  emit mapViewChanged();
}

void DisplayOgcApiFeatureCollection::createQueryConnection()
{
  connect(m_mapView, &MapQuickView::navigatingChanged, this, [this]()
  {
    if (m_mapView->isNavigating())
      return;

    QueryParameters queryParameters = QueryParameters();
    // Set the query area to what is currently visible in the map view
    queryParameters.setGeometry(m_mapView->currentViewpoint(ViewpointType::BoundingGeometry).targetGeometry());
    // SpatialRelationship::Intersects will return all features that are within and crossing the perimiter of the input geometry
    queryParameters.setSpatialRelationship(SpatialRelationship::Intersects);
    // Some services have low default values for max features returned
    queryParameters.setMaxFeatures(5000);

    // Populate the feature collection table with features that match the parameters, cache them locally, and store all table fields
    auto future = m_ogcFeatureCollectionTable->populateFromServiceAsync(queryParameters, false, {});
    Q_UNUSED(future)
  });
}

// [WriteFile Name=DisplayOgcApiFeatureCollection, Category=Layers]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef DisplayOgcApiFeatureCollection_H
#define DisplayOgcApiFeatureCollection_H

// ArcGIS Maps SDK headers
#include "QueryParameters.h"

// Qt headers
#include <QObject>

namespace Esri::ArcGISRuntime
{
class FeatureLayer;
class Map;
class MapQuickView;
class OgcFeatureCollectionTable;
class QueryParameters;
}

Q_MOC_INCLUDE("MapQuickView.h")

class DisplayOgcApiFeatureCollection : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)

public:
  explicit DisplayOgcApiFeatureCollection(QObject* parent = nullptr);
  ~DisplayOgcApiFeatureCollection();

  static void init();

signals:
  void mapViewChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);
  void createQueryConnection();

  Esri::ArcGISRuntime::FeatureLayer* m_featureLayer = nullptr;
  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::OgcFeatureCollectionTable* m_ogcFeatureCollectionTable = nullptr;
};

#endif // DisplayOgcApiFeatureCollection_H

// [WriteFile Name=DisplayOgcApiFeatureCollection, Category=Layers]
// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    DisplayOgcApiFeatureCollectionSample {
        id: model
        mapView: view
    }
}

// [Legal]
// Copyright 2021 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "DisplayOgcApiFeatureCollection.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("DisplayOgcApiFeatureCollection"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  DisplayOgcApiFeatureCollection::init();

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));

#ifdef ARCGIS_RUNTIME_IMPORT_PATH_2
  engine.addImportPath(ARCGIS_RUNTIME_IMPORT_PATH_2);
#endif

  // Set the source
  engine.load(QUrl("qrc:/Samples/Layers/DisplayOgcApiFeatureCollection/main.qml"));

  return app.exec();
}

// Copyright 2021 Esri.

// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0

// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    DisplayOgcApiFeatureCollection {
        anchors.fill: parent
    }
}
