Add ENC exchange set

// [WriteFile Name=AddEncExchangeSet, Category=Layers]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifdef PCH_BUILD
#include "pch.hpp"
#endif // PCH_BUILD

// sample headers
#include "AddEncExchangeSet.h"

// ArcGIS Maps SDK headers
#include "EncCell.h"
#include "EncDataset.h"
#include "EncEnvironmentSettings.h"
#include "EncExchangeSet.h"
#include "EncLayer.h"
#include "Envelope.h"
#include "Error.h"
#include "GeometryEngine.h"
#include "LayerListModel.h"
#include "Map.h"
#include "MapQuickView.h"
#include "MapTypes.h"
#include "Viewpoint.h"

// Qt headers
#include <QFuture>
#include <QStandardPaths>
#include <QtCore/qglobal.h>

using namespace Esri::ArcGISRuntime;

// helper method to get cross platform data path
namespace
{
  QString defaultDataPath()
  {
    QString dataPath;

  #ifdef Q_OS_IOS
    dataPath = QStandardPaths::writableLocation(QStandardPaths::DocumentsLocation);
  #else
    dataPath = QStandardPaths::writableLocation(QStandardPaths::HomeLocation);
  #endif

    return dataPath;
  }
} // namespace

AddEncExchangeSet::AddEncExchangeSet(QObject* parent /* = nullptr */):
  QObject(parent),
  m_map(new Map(BasemapStyle::ArcGISOceans, this))
{
  // set resource path
  EncEnvironmentSettings::setResourcePath(defaultDataPath() + "/ArcGIS/Runtime/Data/ENC/hydrography");

  // create ENC Exchange Set
  QStringList encPaths = { defaultDataPath() + "/ArcGIS/Runtime/Data/ENC/ExchangeSetwithoutUpdates/ENC_ROOT/CATALOG.031" };
  m_encExchangeSet = new EncExchangeSet(encPaths, this);
}

AddEncExchangeSet::~AddEncExchangeSet() = default;

void AddEncExchangeSet::init()
{
  // Register the map view for QML
  qmlRegisterType<MapQuickView>("Esri.Samples", 1, 0, "MapView");
  qmlRegisterType<AddEncExchangeSet>("Esri.Samples", 1, 0, "AddEncExchangeSetSample");
}

MapQuickView* AddEncExchangeSet::mapView() const
{
  return m_mapView;
}

// Set the view (created in QML)
void AddEncExchangeSet::setMapView(MapQuickView* mapView)
{
  if (!mapView || mapView == m_mapView)
    return;

  m_mapView = mapView;
  m_mapView->setMap(m_map);

  // connect to doneLoading signal of EncExchangeSet
  connect(m_encExchangeSet, &EncExchangeSet::doneLoading, this, [this](const Error& e)
  {
    if (!e.isEmpty())
      return;

    // loop through datasets
    const auto datasets = m_encExchangeSet->datasets();
    for (EncDataset* dataset : datasets)
    {
      // create an EncCell from each dataset
      EncCell* cell = new EncCell(dataset, this);

      // create an EncLayer from each cell
      EncLayer* encLayer = new EncLayer(cell, this);

      // connect to the doneLoading signal of the layer
      connect(encLayer, &EncLayer::doneLoading, this, [this, encLayer](const Error& e)
      {
        if (!e.isEmpty())
          return;

        m_extents << encLayer->fullExtent();

        if (m_extents.length() != m_encExchangeSet->datasets().length())
          return;

        // combine the extents
        Envelope fullExtent = GeometryEngine::combineExtents(m_extents);
        m_mapView->setViewpointAsync(Viewpoint{fullExtent});
      });

      // add the layer to the map
      m_map->operationalLayers()->append(encLayer);
    }
  });

  // load the EncExchangeSet
  m_encExchangeSet->load();

  emit mapViewChanged();
}

// [WriteFile Name=AddEncExchangeSet, Category=Layers]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

#ifndef ADDENCEXCHANGESET_H
#define ADDENCEXCHANGESET_H

// Qt headers
#include <QObject>

namespace Esri::ArcGISRuntime
{
class Map;
class MapQuickView;
class EncExchangeSet;
class Geometry;
}

Q_MOC_INCLUDE("MapQuickView.h")

class AddEncExchangeSet : public QObject
{
  Q_OBJECT

  Q_PROPERTY(Esri::ArcGISRuntime::MapQuickView* mapView READ mapView WRITE setMapView NOTIFY mapViewChanged)

public:
  explicit AddEncExchangeSet(QObject* parent = nullptr);
  ~AddEncExchangeSet();

  static void init();

signals:
  void mapViewChanged();

private:
  Esri::ArcGISRuntime::MapQuickView* mapView() const;
  void setMapView(Esri::ArcGISRuntime::MapQuickView* mapView);

  Esri::ArcGISRuntime::Map* m_map = nullptr;
  Esri::ArcGISRuntime::MapQuickView* m_mapView = nullptr;
  Esri::ArcGISRuntime::EncExchangeSet* m_encExchangeSet = nullptr;
  QList<Esri::ArcGISRuntime::Geometry> m_extents;
};

#endif // ADDENCEXCHANGESET_H

// [WriteFile Name=AddEncExchangeSet, Category=Layers]
// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

import QtQuick
import QtQuick.Controls
import Esri.Samples

Item {

    // add a mapView component
    MapView {
        id: view
        anchors.fill: parent

        Component.onCompleted: {
            // Set the focus on MapView to initially enable keyboard navigation
            forceActiveFocus();
        }
    }

    // Declare the C++ instance which creates the map etc. and supply the view
    AddEncExchangeSetSample {
        id: model
        mapView: view
    }
}

// [Legal]
// Copyright 2019 Esri.
//
// Licensed under the Apache License, Version 2.0 (the "License");
// you may not use this file except in compliance with the License.
// You may obtain a copy of the License at
// http://www.apache.org/licenses/LICENSE-2.0
//
// Unless required by applicable law or agreed to in writing, software
// distributed under the License is distributed on an "AS IS" BASIS,
// WITHOUT WARRANTIES OR CONDITIONS OF ANY KIND, either express or implied.
// See the License for the specific language governing permissions and
// limitations under the License.
// [Legal]

// sample headers
#include "AddEncExchangeSet.h"

// ArcGIS Maps SDK headers
#include "ArcGISRuntimeEnvironment.h"

// Qt headers
#include <QDir>
#include <QGuiApplication>
#include <QQmlApplicationEngine>

// Platform specific headers
#ifdef Q_OS_WIN
#include <Windows.h>
#endif

#define STRINGIZE(x) #x
#define QUOTE(x) STRINGIZE(x)

int main(int argc, char *argv[])
{
  Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setUseLegacyAuthentication(false);
  QGuiApplication app(argc, argv);
  app.setApplicationName(QString("AddEncExchangeSet"));

  // Use of ArcGIS location services, such as basemap styles, geocoding, and routing services,
  // requires an access token. For more information see
  // https://links.esri.com/arcgis-runtime-security-auth.

  // The following methods grant an access token:

  // 1. User authentication: Grants a temporary access token associated with a user's ArcGIS account.
  // To generate a token, a user logs in to the app with an ArcGIS account that is part of an
  // organization in ArcGIS Online or ArcGIS Enterprise.

  // 2. API key authentication: Get a long-lived access token that gives your application access to
  // ArcGIS location services. Go to the tutorial at https://links.esri.com/create-an-api-key.
  // Copy the API Key access token.

  const QString accessToken = QString("");

  if (accessToken.isEmpty())
  {
      qWarning() << "Use of ArcGIS location services, such as the basemap styles service, requires" <<
                    "you to authenticate with an ArcGIS account or set the API Key property.";
  }
  else
  {
      Esri::ArcGISRuntime::ArcGISRuntimeEnvironment::setApiKey(accessToken);
  }

  // Initialize the sample
  AddEncExchangeSet::init();

  QString arcGISRuntimeImportPath = QUOTE(ARCGIS_RUNTIME_IMPORT_PATH);

#if defined(LINUX_PLATFORM_REPLACEMENT)
  // on some linux platforms the string 'linux' is replaced with 1
  // fix the replacement paths which were created
  QString replaceString = QUOTE(LINUX_PLATFORM_REPLACEMENT);
  arcGISRuntimeImportPath = arcGISRuntimeImportPath.replace(replaceString, "linux", Qt::CaseSensitive);
#endif

  // Initialize application view
  QQmlApplicationEngine engine;
  // Add the import Path
  engine.addImportPath(QDir(QCoreApplication::applicationDirPath()).filePath("qml"));
  // Add the Runtime and Extras path
  engine.addImportPath(arcGISRuntimeImportPath);

  // Set the source
  engine.load(QUrl("qrc:/Samples/Layers/AddEncExchangeSet/main.qml"));

  return app.exec();
}

// Copyright 2019 ESRI
//
// All rights reserved under the copyright laws of the United States
// and applicable international laws, treaties, and conventions.
//
// You may freely redistribute and use this sample code, with or
// without modification, provided you include the original copyright
// notice and use restrictions.
//
// See the Sample code usage restrictions document for further information.
//

import QtQuick.Controls
import Esri.Samples

ApplicationWindow {
    visible: true
    width: 800
    height: 600

    AddEncExchangeSet {
        anchors.fill: parent
    }
}
